23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DGSD0101 1 GUIDE ｶﾞｲﾄﾞ FE
2 DGSD0111 1 GUIDE ｶﾞｲﾄﾞ FE
3 DGSD0142 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ OT
4 DCSD1032 4 ROLLER ﾛｰﾗ FE
5 DGSD0300 1 BKT BKT FE
6 DGSD0310 1 BKT BKT FE
7 DGSD5751 12 COLLAR ｶﾗｰ FE
8 R5001M 12 ROLLER ﾛｰﾗ EB-20 OT
9 DGSD1020 1 BKT BKT FE
10 DGSD0380 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
11 DGSD0411 1 BKT BKT FE
12 DGSD0420 1 BKT, SW BKT SW FE
13 DGSD5742 12 COLLAR ｶﾗｰ OT
14 DGSD0450 1 BKT BKT FE
15 DGSD0611 4 BKT BKT OT
16 DGSD0640 2 BKT BKT FE
17 DGSD0650 1 BKT BKT FE
18 DGSD0660 4 SHAFT ｼｬﾌﾄ OT
19 DGSD0690 2 BLOCK, STOPPER ﾌﾞﾛｯｸ ｽﾄｯﾊﾟ FE
20 DGSD0700 2 STOPPER ｽﾄｯﾊﾟ PL
21 DGSD0710 2 COLLAR ｶﾗｰ FE
22 DGSD0751 4 SPRING ｽﾌﾟﾘﾝｸﾞ FE
23 DGSD0870 1 BKT, SW BKT SW FE
24 DGSD0880 1 BKT, SW BKT SW FE
25 DGSD0921 1 BKT, SW BKT SW FE
26 ADGSD8013 1 COVER, SIDE ｶﾊﾞｰ ｻｲﾄﾞ OT
27 DGSD5731 12 PIN ﾋﾟﾝ FE
28 DCSD0350 2 STOPPER ｽﾄｯﾊﾟ PL
29 DCSD0360 2 PIN ﾋﾟﾝ FE
30 DCSD0370 1 GUIDE ｶﾞｲﾄﾞ FE
31 DCSD0561 4 HOOK ﾌｯｸ FE
32 DCSD0571 4 HOOK ﾌｯｸ FE
33 DCSD0580 1 PIN ﾋﾟﾝ FE
34 DCSD0590 1 STOPPER ｽﾄｯﾊﾟ FE
35 DCSD0650 1 BKT BKT FE
36 DCSD0680 4 FLANGE ﾌﾗﾝｼﾞ FE
37 DCSD0690 4 SHAFT ｼｬﾌﾄ FE
38 DCSD0710 4 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ FE
39 DCSD0720 4 HOOK, SPRING ﾌｯｸ ｽﾌﾟﾘﾝｸﾞ FE
CP-743E,CP-742E PARTS LIST
23 - 11
23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
40 DCSD0760 4 STOPPER ｽﾄｯﾊﾟ PL
41 DCSD0800 4 SCREW, SET ﾈｼﾞ 止め FE
42 DCSD0820 4 SPRING ｽﾌﾟﾘﾝｸﾞ FE
43 DCSD0830 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ OT
44 DGSD1010 1 PLATE, SW ﾌﾟﾚｰﾄ SW FE
45 DCSD0871 28 ROLLER ﾛｰﾗ PL
46 DCSD0881 36 PIN ﾋﾟﾝ FE
47 DCSD0891 4 SHIM ｼﾑ 注1.Note.1 FE
48 DCSD0960 1 PLATE ﾌﾟﾚｰﾄ PL
50 DCSD0622 3 PLATE ﾌﾟﾚｰﾄ FE
51 K5342W 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-08S(ｼﾛ) OT
52 S4045F 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX871A OT
53 S31147 3 SW, PROXIMITY SW 近接 APM-D3A1-05 OT
54 H4429H 4
BEARING, BALL
ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMK16UU FE
55 K10911 4 CAM FOLLOWER ｶﾑﾌｫﾛｱ CF10-A OT
56 K1108H 4 CAM FOLLOWER ｶﾑﾌｫﾛｱ CF4-A OT
57 S30203 1 SPRING ｽﾌﾟﾘﾝｸﾞ WR6-60 FE
58 DCSD1020 1 BKT BKT FE
59 DGSD5013 1 TABLE ﾃｰﾌﾞﾙ AL
61 DGSD5111 1 BKT BKT FE
63 DGSD5140 1 BKT BKT FE
64 DGSD5150 1 DOG ﾄﾞｯｸﾞ FE
65 DGSD5230 2 CASE ｹｰｽ FE
66 DGSD5240 1 BKT, SW BKT SW FE
67 DGSD5280 1 PIN, LOCATING ﾋﾟﾝ 位置決め FE
68 DGSD5290 1 PIN, LOCATING ﾋﾟﾝ 位置決め FE
69 DGSD5350 1 BKT, SENSOR BKT ｾﾝｻ FE
70 DGSD5410 2 GUIDE ｶﾞｲﾄﾞ FE
71 DGSD5420 2 CAP ｷｬｯﾌﾟ FE
72 DGSD5430 2 SHAFT ｼｬﾌﾄ FE
73 DGSD5441 2 PIN ﾋﾟﾝ FE
74 DGSD5450 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ OT
75 DGSD5460 2 COVER 蓋 FE
76 DGSD5470 2 HOOK ﾌｯｸ FE
77 DGSD5480 2 LEVER ﾚﾊﾞｰ FE
78 DGSD5491 2 BKT BKT FE
79 DGSD5501 2 PIN ﾋﾟﾝ FE
80 DGSD5510 2 COLLAR ｶﾗｰ FE
81 DGSD5520 2 PIN ﾋﾟﾝ FE
CP-743E,CP-742E PARTS LIST
23 - 12
23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
23.3.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.3.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
82 DGSD5530 1 BKT BKT AL
83 DGSD5540 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
84 DGSD5550 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
85 DGSD5560 2 ROLLER ﾛｰﾗ FE
86 DGSD5571 2 PIN ﾋﾟﾝ FE
87 DGSD5590 1 PLATE, SW ﾌﾟﾚｰﾄ SW FE
88 DGSD5600 1 DOG ﾄﾞｯｸﾞ FE
89 DGSD5610 4 SHIM ｼﾑ 注2.Note.2 FE
90 DGSD5700 1 PLATE, SW ﾌﾟﾚｰﾄ SW FE
91 K1093A 2
CAM FOLLOWER
ｶﾑﾌｫﾛｱ NAST06 OT
92 H4292A 2
BEARING, SLIDE
ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ LM13UU FE
93 K4150D 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ TKP0130-06R20 102L OT
94 H4144D 4 BEARING ﾍﾞｱﾘﾝｸﾞ MR126ZZ FE
95 S1028A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ STW 6 FE
96 S1021A 4
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-3 FE
97 S1022A 2
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-4 FE
99 H30632 8 BUSHING ﾌﾞｼｭ SPB-162220 OT
100 S3148L 1 SW, PHOTOELECTRIC SW 光電 HPJ-D21-L05 OT
101 H5269A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.6X5L FE
102 H5271A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.6X8L FE
103 H5273A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L FE
104 H5274A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X6L FE
105 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L FE
106 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L FE
107 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
108 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE
109 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
110 H5294A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X30L FE
111 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
112 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
113 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
114 H5301A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18L FE
115 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L FE
116 H5311A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X60L FE
117 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L FE
118 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
119 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
120 H5323A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18L FE
121 H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L FE
CP-743E,CP-742E PARTS LIST
23 - 13
