33.3.Pneumatic circuit diagram(DGPI)[English Edition]
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DGSD0160 1 VALVE, SOL OT
2 DGSD0170 1 VALVE, SOL OT
3 DGSD0830 2 CYLINDER, AIR FE
4 DGSD5190 2 CYLINDER, AIR OT
5 S2110K 4 CYLINDER, AIR CDQ2B50-15D-A93VL OT
6 K5342W 4 CONTROLLER, SPEED AS2201F-01-08S(ｼﾛ) OT
7 K5348K 4 CONTROLLER, SPEED AS3001F-08(ｼﾛ) OT
8 Y30812 2 UNION, ELBOW KQ2W08-99 OT
9 H1024K 2 VALVE 80-IN-334-61 OT
10 Y3071T 2 UNION KQ2T08-06 OT
11 Y3083A 2 UNION, HALF KQ2H06-01S OT
12 K5347Y 8 CONTROLLER, SPEED AS2301F-02-08S(ｼﾛ) OT .
CP-743E,CP-742E PARTS LIST
33 - 14 33.3.Pneumatic circuit diagram(DGPI)[English Edition]
35
40
A
139
x30
62
69
66
64
61
63
67
68
65
83
82
84
Ref.28-1
Ref.30-1
21
20
19
11
13
17
12
18
16
15
14
3
2
1
5
7
6
10
9
8
22
28
23
29
27
26
25
24
62
30
69
66
61
63
67
68
65
64
50
51
47
99
98
100
46
49
48
52
45
70
80
79
81
80
79
81
31
91
89
90
4
54
57
60
53
56
59
55
58
71
32
33
34
74
73
75
72
78
76
77
88
85
85
87
85
86
87
87
85
111
110
109
108
107
106
96
95
97
93
92
94
93
93
92
92
94
凡例
Example
94
44
43
42
41
40
44
43
42
41
39
38
36
101
37
103
102
104
105
34.防音シール(742E)(DGPZ)
34.Noise redaction seal(742E)(DGPZ)
34.防音シール(742E)(DGPZ)
34.Noise redaction seal(742E)(DGPZ)
34 - 1
CP-743E,CP-742E PARTS LIST
34.防音ｼｰﾙ(742E)(DGPZ,DGAF)
34.Noise redaction seal(742E)(DGPZ,DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 ADGPZ8052 1 COVER ｶﾊﾞｰ OT
2 DGPZ0023 1 COVER ｶﾊﾞｰ FE
3 DGPZ0532 1 SEAL ｼｰﾙ OT
4 ADGPZ8062 1 COVER ｶﾊﾞｰ OT
5 DGPZ0032 1 COVER ｶﾊﾞｰ FE
6 DCPZ0220 1 SEAL ｼｰﾙ OT
7 DGPZ0522 1 SEAL ｼｰﾙ OT
8 ADGPZ8072 1 COVER ｶﾊﾞｰ OT
9 DGPZ0042 1 COVER ｶﾊﾞｰ FE
10 DGPZ0510 1 SEAL ｼｰﾙ OT
11 ADGPZ8180 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ OT
12 DGPZ1540 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
13 DGPZ2190 1 SEAL ｼｰﾙ OT
14 DGPZ2180 1 SEAL ｼｰﾙ OT
15 DGPZ2170 1 SEAL ｼｰﾙ OT
16 DGPZ2160 1 SEAL ｼｰﾙ OT
17 DGPZ2010 1 SEAL ｼｰﾙ OT
18 DGPZ2150 1 SEAL ｼｰﾙ OT
19 ADGPZ8091 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ OT
20 DGPZ1171 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
21 DGPZ2080 1 SEAL ｼｰﾙ OT
22 ADGPZ8102 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ OT
23 DGPZ1182 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
24 DGPZ2040 1 SEAL ｼｰﾙ OT
25 DGPZ2050 1 SEAL ｼｰﾙ OT
26 DGPZ2060 1 SEAL ｼｰﾙ OT
27 DGPZ2070 1 SEAL ｼｰﾙ OT
28 ADGPZ8111 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ OT
29 DGPZ1192 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
30 DGPZ2031 1 SEAL ｼｰﾙ OT
31 ADGAF8100 1 COVER ｶﾊﾞｰ OT
32 DCAF0120 1 COVER ｶﾊﾞｰ FE
33 DCAF1160 1 SEAL ｼｰﾙ OT
34 DCAF1170 1 SEAL ｼｰﾙ OT
35 ADGAF8580 1 COVER, REAR ｶﾊﾞｰﾘﾔ- OT
36 DGAF5200 1 COVER ｶﾊﾞｰ FE
37 DGAF5740 1 SEAL ｼｰﾙ OT
38 DGAF5750 1 SEAL ｼｰﾙ OT
39 DGAF5760 1 SEAL ｼｰﾙ OT
CP-743E,CP-742E PARTS LIST
34 - 2
34.防音ｼｰﾙ(742E)(DGPZ,DGAF)
34.Noise redaction seal(742E)(DGPZ,DGAF)
