CP-743E-03 - 第234页
3 5 4 0 A 1 3 9 x 3 0 6 2 6 9 6 6 6 4 6 1 6 3 6 7 6 8 6 5 8 3 8 2 8 4 R e f . 2 8 - 1 R e f . 3 0 - 1 2 1 2 0 1 9 1 1 1 7 1 2 1 8 1 6 1 5 1 4 1 4 1 4 1 3 1 8 3 2 1 5 7 6 1 0 9 8 2 2 2 8 2 3 2 9 2 7 2 6 2 5 2 4 6 2 3 …
40.ｶﾊﾞｰ前部(743E)(DGPZ)
40.Cover front(743E)(DGPZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Material
106 H5343A BOLT, HEX ﾎﾞﾙﾄ 六角 M8X30L FE
107 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
108 H5286A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6L FE
109 ADGPZ8170 1 COVER,FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743E Use only when no external parts monitor. OT
110 DCPZ1550 1 BKT BKT 743E FE
111 DCGC0470 1 DISPLAY, LIQUID CRYSTAL ﾃﾞｨｽﾌﾟﾚｲ 液晶 743E OT
112 DCPZ1500 1 SPACER ｽﾍﾟｰｻ 743E AL
113 DCPZ1510 1 BKT BKT 743E FE
114 H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
115 DCPZ1520 1 BKT BKT 743E FE
116 DCGC0470 1 DISPLAY, LIQUID CRYSTAL ﾃﾞｨｽﾌﾟﾚｲ 液晶 743E OT
117 ZG827DCEM9850 1 BOX, SERVO BOX ｻｰﾎﾞ 743E FE .
CP-743E,CP-742E PARTS LIST
40 - 4
40.ｶﾊﾞｰ前部(743E)(DGPZ)
40.Cover front(743E)(DGPZ)
35
40
A
139
x30
62
69
66
64
61
63
67
68
65
83
82
84
Ref.28-1
Ref.30-1
21
20
19
11
17
12
18
16
15
14
14
14
13
18
3
2
1
5
7
6
10
9
8
22
28
23
29
27
26
25
24
62
30
69
66
61
63
67
68
65
64
50
51
47
99
98
100
46
49
48
52
45
70
80
79
81
80
79
81
31
91
89
90
112
4
54
57
60
53
56
59
55
58
71
32
33
34
74
73
75
72
78
76
77
88
85
85
87
85
86
87
87
85
111
110
109
108
107
106
96
95
97
93
92
94
93
93
92
92
94
凡例
Example
94
44
43
42
41
40
44
43
42
41
39
38
36
101
37
103
102
104
105
41.防音シール(743E)(DGPZ)
41.Noise redaction seal(743E)(DGPZ)
41.防音シール(743E)(DGPZ)
41.Noise redaction seal(743E)(DGPZ)
41 - 1
CP-743E,CP-742E PARTS LIST
41.防音ｼｰﾙ(743E)(DGPZ)(DGAF)
41.Noise redaction seal(743E)(DGPZ)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 ADGPZ8052 1 COVER ｶﾊﾞｰ OT
2 DGPZ0023 1 COVER ｶﾊﾞｰ FE
3 DGPZ0532 1 SEAL ｼｰﾙ OT
4 ADGPZ8062 1 COVER ｶﾊﾞｰ OT
5 DGPZ0032 1 COVER ｶﾊﾞｰ FE
6 DCPZ0220 1 SEAL ｼｰﾙ OT
7 DGPZ0522 1 SEAL ｼｰﾙ OT
8 ADGPZ8072 1 COVER ｶﾊﾞｰ OT
9 DGPZ0042 1 COVER ｶﾊﾞｰ FE
10 DGPZ0510 1 SEAL ｼｰﾙ OT
11 ADGPZ8130 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743E OT
12 DGPZ1540 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
13 DGPZ2130 1 SEAL ｼｰﾙ 743E OT
14 DGPZ2120 3 SEAL ｼｰﾙ 743E OT
15 DGPZ1490 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ 743E Use only when no external parts monitor. FE
16 DCPZ1860 1 SEAL ｼｰﾙ 743E Use only when no external parts monitor. OT
17 DGPZ2010 1 SEAL ｼｰﾙ OT
18 DGPZ2150 2 SEAL ｼｰﾙ 743E OT
19 ADGPZ8091 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ OT
20 DGPZ1171 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
21 DGPZ2080 1 SEAL ｼｰﾙ OT
22 ADGPZ8102 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ OT
23 DGPZ1182 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
24 DGPZ2040 1 SEAL ｼｰﾙ OT
25 DGPZ2050 1 SEAL ｼｰﾙ OT
26 DGPZ2060 1 SEAL ｼｰﾙ OT
27 DGPZ2070 1 SEAL ｼｰﾙ OT
28 ADGPZ8111 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ OT
29 DGPZ1192 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
30 DGPZ2031 1 SEAL ｼｰﾙ OT
31 ADGAF8100 1 COVER ｶﾊﾞｰ OT
32 DCAF0120 1 COVER ｶﾊﾞｰ FE
33 DCAF1160 1 SEAL ｼｰﾙ OT
34 DCAF1170 1 SEAL ｼｰﾙ OT
35 ADGAF8580 1 COVER, REAR ｶﾊﾞｰﾘﾔ- OT
36 DGAF5200 1 COVER ｶﾊﾞｰ FE
37 DGAF5740 1 SEAL ｼｰﾙ OT
38 DGAF5750 1 SEAL ｼｰﾙ OT
39 DGAF5760 1 SEAL ｼｰﾙ OT
CP-743E,CP-742E PARTS LIST
41 - 2
41.防音ｼｰﾙ(743E)(DGPZ)(DGAF)
41.Noise redaction seal(743E)(DGPZ)(DGAF)
