6.2.ｱｳﾄｷｬﾘｱ(DGQK) 6.2.Out carrier(DGQK) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 114 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE 115 H5263E BOLT, HEX SOCKET ﾎﾞﾙ…
6.2.ｱｳﾄｷｬﾘｱ(DGQK)
6.2.Out carrier(DGQK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
50 DCQK0350 1 JOINT ｼﾞｮｲﾝﾄ FE
52 CSQC6160 1 BKT, SENSOR BKT ｾﾝｻ FE
53 CSQC6211 1 BKT BKT FE
55 CSQC6340 1 RETAINER 押え FE
57 CSQC6440 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
58 DCQK3200 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
59 DGQK0270 1 JOINT ｼﾞｮｲﾝﾄ FE
62 CSQC5190 2 SPACER ｽﾍﾟｰｻ t=0.1 FE
63 CSQC5200 2 SPACER ｽﾍﾟｰｻ t=0.2 FE
64 CSQC5210 2 SPACER ｽﾍﾟｰｻ t=0.3 FE
65 CSQC5220 2 SPACER ｽﾍﾟｰｻ t=0.4 FE
66 CSQC5230 2 SPACER ｽﾍﾟｰｻ t=0.5 FE
67 CSQC5311 1
BOLT, ADJUSTING
ﾎﾞﾙﾄ ｾﾘ FE
68 CSQC5340 1 BKT BKT AL
69 DCQK0310 1 BKT BKT FE
70 DCQK3170 1 BKT, SENSOR BKT ｾﾝｻ FE
71 A1039X 2 AMPLIFIER ｱﾝﾌﾟ FS-V1 OT
72 CSQC5381 1 FIBER, UNIT ﾌｧｲﾊﾞ ﾕﾆｯﾄ FU-2254 OT
73 S3141B 2 SW, PHOTOELECTRIC SW 光電 DL-S3R OT
74 S31207 3 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX771A OT
75 Y3079N 8
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5 OT
76 S2209A 4 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDAS16X15-ZE202B1 OT
77 S31208 3 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX772A OT
84 DGQK3130 1 BKT BKT FE
85 DGQK0190 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
87 DGQK0180 1 SADDLE ｻﾄﾞﾙ FE
88 DCQK0230 1 BKT BKT FE
89 DCQK0180 1 BKT BKT FE
103 H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L FE
104 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L FE
105 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
106 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
107 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
108 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
109 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L FE
110 H5291A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X18L FE
111 H5292A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X20L FE
112 H5294A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X30L FE
113 H5297A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X8L FE
CP-743E,CP-742E PARTS LIST
6 - 6
6.2.ｱｳﾄｷｬﾘｱ(DGQK)
6.2.Out carrier(DGQK)
6.2.ｱｳﾄｷｬﾘｱ(DGQK)
6.2.Out carrier(DGQK)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
114 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
115 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
116 H5301A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X18L FE
117 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L FE
118 H5304A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X25L FE
119 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L FE
120 H5331A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X45L FE
121 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
122 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
123 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
124 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
125 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
126 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
127 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
128 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
129 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿 M-3-L FE
130 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿 M-4-L FE
131 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿 M-5-L FE
132 N4024A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M3X12L FE
135 K5255T
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X6L FE
136 K5256A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X8L FE
137 K5257A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L FE
138 N1076A
NUT, HEX
ﾅｯﾄ 六角 M3 P=0.5 FE
139 N1080A
NUT, HEX
ﾅｯﾄ 六角 M4 P=0.7 FE
140 N1077H NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 3ｼｭ FE
141 K5178Z SCREW, C/R PAN 小ﾈｼﾞ十穴鍋 M3X16L FE
142 H5321A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X12L FE
143 K5256H
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X12L FE
144 DCQK3180 1 COVER ｶﾊﾞｰ FE
146 W1002R
WASHER
ﾜｯｼｬ THA-271-1 FE
147 DCWM0350 1 SEAL ｼｰﾙ Japanese(Ref.32-7) OT
148 DCWM0550 1 SEAL ｼｰﾙ English(Ref.32-9) OT
149 DCWM0750 1 SEAL ｼｰﾙ French(Ref.32-11) OT
150 H5175A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
151 H5286A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X6L FE
152 H5304T
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X28L FE
CP-743E,CP-742E PARTS LIST
6 - 7
6.2.ｱｳﾄｷｬﾘｱ(DGQK)
6.2.Out carrier(DGQK)
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
x8
21
20
43
57
22
15
57
46
69
68
65
66
67
67
56
75
58
47
58
49
57
43
39
55
39
55
64
54
47
58
48
70
70
71
71
71
72
72
72
72
70
70
71
71
71
72
72
72
72
58
62
62
58
48
61
57
43
61
57
43
59
52
50
57
57
50
64
54
56
40
43
57
43
57
57
50
58
62
49
58
62
49
58
62
58
62
49
49
57
46
57
74
73
73
45
57
74
45
41
56
60
41
56
60
60
62
60
56
58
41
76
41
53
59
63
63
59
53
57
42
41
56
60
41
56
60
60
56
41
63
59
53
56
60
41
56
62
58
48
63
59
53
42
57
62
58
48
38
38
D
B
A
D
20
21
29
28
27
27
25
25
17
E
E
E
19
8
26
4
11
19
2
9
26
3
38
38
19
5
19
B
A
20
21
35
34
7
13
31
18
31
18
13
30
30
14
23
12
23
12
22
15
35
34
36
36
33
33
36
36
33
33
7
C
C
1
20
21
6
10
69
62
58
76
7 - 1
7.基板ローダ(DGQL)
7.Board loading unit(DGQL)
7.基板ローダ(DGQL)
7.Board loading unit(DGQL)
CP-743E,CP-742E PARTS LIST
