8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DGSS0580 1 RAIL ﾚｰﾙ AL
2 DGSS0022 1 RAIL ﾚｰﾙ AL
3 S3084A 2 SLEEVE ｽﾘｰﾌﾞ 40-13 OT
4 DGSS0150 1 BKT BKT FE
5 DGSS0101 1 BKT BKT FE
6 DGSS0091 1 BKT BKT FE
7 DGSS0050 1 HOLDER ﾎﾙﾀﾞ AL
8 DGSS0040 1 HOLDER ﾎﾙﾀﾞ AL
9 DGSS0180 1 BKT BKT FE
10 DGSS0260 1 SEAL ｼｰﾙ PL
11 DGSS0560 1 WASHER ﾜｯｼｬ PL
12 DGSS0320 1 BKT, SENSOR BKT ｾﾝｻ FE
13 DGSS0330 1 DOG ﾄﾞｯｸﾞ FE
14 DGSS0550 46 JAW 爪 FE
15 DGSS0540 1 BKT BKT FE
16 DGSS0290 1 BKT BKT FE
20 DGSS0210 1 COLLAR ｶﾗｰ FE
21 DGSS0190 1 COLLAR ｶﾗｰ FE
22 DGSS0200 1 COLLAR ｶﾗｰ FE
23 DGSS0480 1 BKT, SENSOR BKT ｾﾝｻ HELPS FE
24 DGSS0490 1 BKT, SENSOR BKT ｾﾝｻ HELPS FE
25 DGSS0300 1 BKT BKT FE
26 DGSS0080 3 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ OT
27 DGSS0060 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
28 DGSS0070 1 BKT BKT FE
29 DGSS0220 1 LEVER ﾚﾊﾞｰ FE
30 DGSS0231 1 LEVER ﾚﾊﾞｰ FE
31 DGSS0240 1 LEVER ﾚﾊﾞｰ FE
32 DGSS0250 1 LEVER ﾚﾊﾞｰ FE
33 DGSS0161 1 SHAFT ｼｬﾌﾄ FE
34 DGSS0172 1 SHAFT ｼｬﾌﾄ FE
37 DGSS0380 1 BKT, WIPING BKT 配線 FE
40 DGSS0340 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ AL
48 DGSS0390 4 CLAMPER ｸﾗﾝﾊﾟ FE
50 DCSS0250 2 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ AL
52 AWSS8710 2 PISTON ﾋﾟｽﾄﾝ OT
53 CSSS0121 3 PIN ﾋﾟﾝ FE
54 CSSS1001 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ OT
55 CSSS0291 2 COLLAR ｶﾗｰ FE
56 CSSS0970 1 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ FE
57 CSSS0111 3 BOLT ﾎﾞﾙﾄ FE
58 CSSS1400 1 VALVE, MANUAL ﾊﾞﾙﾌﾞ 手動 OT
59 CSSS1291 1 BKT, HOLDER BKT ﾎﾙﾀﾞ FE
60 CSSS0730 1 SPACER ｽﾍﾟｰｻ FE
61 CSSS0951 1 WASHER ﾜｯｼｬ PL
62 CSSS0960 1 WASHER ﾜｯｼｬ FE
63 CSSS1040 1 COLLAR ｶﾗｰ FE
64 CSSS1051 1 SPRING ｽﾌﾟﾘﾝｸﾞ FE
CP-743E,CP-742E PARTS LIST
8 - 3
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
73 CSSS0141 4 WASHER ﾜｯｼｬ PL
84 CSSS0130 1 WASHER ﾜｯｼｬ OT
85 CSSS0150 1 WASHER ﾜｯｼｬ FE
86 CSSS0170 41 COLLAR ｶﾗｰ FE
87 CSSS0191 1 WASHER ﾜｯｼｬ PL
88 CSSS0200 1 WASHER ﾜｯｼｬ OT
89 CSSS0210 1 WASHER ﾜｯｼｬ FE
90 CSSS0321 2 SEAL ｼｰﾙ PL
91 CSSS1330 46 RETAINER 押え FE
92 YSS0540 2 WASHER ﾜｯｼｬ FE
93 YSS0570 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
94 WSS5300 2 STOPPER ｽﾄｯﾊﾟ FE
95 A40682 6
ELBOW
ｴﾙﾎﾞ M-5HL-6 OT
96 K5077A 4
CONNECTOR
ｺﾈｸﾀ M-5J OT
97 K5345D 1
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2211F-01-06S(ｼﾛ) OT
104 H4401A 1
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA69Z FE
106 S1023A 6
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-5 FE
107 S4045C 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX870A OT
108 S4032T 2
SENSOR
ｾﾝｻ UM-T50TV HELPS OT
109 N1067A 1 NUT, U ﾅｯﾄ U M6X1.0 FE
110 Y3079N 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5 OT
111 Y3086Y 4
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KQ2S06-M5 OT
113 H3119A 2 PLUG ﾌﾟﾗｸﾞ PF OT
114 S2147A 2
JOINT
ｼﾞｮｲﾝﾄ BF6 OT
115 H4402D 2
BEARING, NEEDLE
ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA79Z FE
116 H4386A 2 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA0815Z FE
117 H4128R 2 BEARING ﾍﾞｱﾘﾝｸﾞ L-1790 FE
118 W10012 2 WASHER ﾜｯｼｬ 70W-1000 FE
119 W1001Y 1 WASHER ﾜｯｼｬ 70W-0815 FE
120 R2074C 1 RING, LOCKING ﾘﾝｸﾞ 締結 UM-6X18 OT
121 H1167H 2
PACKING
ﾊﾟｯｷﾝ MY-24 OT
122 H1162T 2
PACKING
ﾊﾟｯｷﾝ MY-7 OT
130 H5268T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2.5X6L FE
131 K5256A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M3X8L FE
132 K5255T
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M3X6L FE
133 H5274A
BOLT, HEX SOCKET
M3X6L FE
134 H5275A
BOLT, HEX SOCKET
M3X8L FE
135 H5276A
BOLT, HEX SOCKET
M3X10L FE
136 H5277A
BOLT, HEX SOCKET
M3X12L FE
137 H5281A
BOLT, HEX SOCKET
M3X25L FE
138 K5359H
SCREW, HEX SOCKET COUNTERSUNK
M4X10L FE
140 H5286A
BOLT, HEX SOCKET
M4X6L FE
141 H5287A
BOLT, HEX SOCKET
M4X8L FE
142 H5288A
BOLT, HEX SOCKET
M4X10L FE
143 H5289A
BOLT, HEX SOCKET
M4X12L FE
144 H5290A
BOLT, HEX SOCKET
M4X15L FE
145 H5304A
BOLT, HEX SOCKET
M5X25L FE
146 H5298A
BOLT, HEX SOCKET
M5X10L FE
CP-743E,CP-742E PARTS LIST
8 - 4
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
147 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
148 H5302A
BOLT, HEX SOCKET
M5X20L FE
149 W1020H
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2.5M/M FE
150 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
151 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
152 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
153 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
154 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4) FE
155 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
156 W1010A
WASHER, CONICAL
M-3-L FE
157 W1011A
WASHER, CONICAL
M-4-L FE
158 W1012A
WASHER, CONICAL
M-5-L FE
159 N1080A
NUT, HEX
M4 P=0.7 FE
160 N1081T
NUT, HEX
M4 3ｼｭ FE
161 N1086A
NUT, HEX
M6 P=1.0 3ｼｭ FE
162 DGSS0270 2 LOCATR 当金 FE
163 DGSS0520 1 BKT BKT FE
164 DCSS0420 1 GUIDE ｶﾞｲﾄﾞ FE
165 DCSS0430 1 GUIDE ｶﾞｲﾄﾞ FE
166 H5264T BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M2X4L FE
167 H5293A
BOLT, HEX SOCKET
M4X25L . FE
CP-743E,CP-742E PARTS LIST
8 - 5
8.1.基板ｸﾗﾝﾌﾟ(DGSS)
8.1.Board clamping unit(DGSS)
