8.2.基板ｸﾗﾝﾌﾟ(DGSS) 8.2.Board clamping unit(DGSS) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 131 K5357H SCREW, HEX SOCKET COUNTERSUNK 小ﾈｼﾞ 六角穴皿 M3X5L FE 132 K5256A…
8.2.基板ｸﾗﾝﾌﾟ(DGSS)
8.2.Board clamping unit(DGSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
3 DGSS0032 1 GUIDE ｶﾞｲﾄﾞ AL
11 DGSS0310 1 SPACER ｽﾍﾟｰｻ AL
17 DGSS0420 1 BKT, SENSOR BKT ｾﾝｻ FE
18 DGSS0430 1 BKT, SENSOR BKT ｾﾝｻ FE
19 DGSS0530 1 BKT BKT FE
35 DGSS0350 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ AL
36 DGSS0360 1 BKT BKT FE
38 DGSS0111 1 BKT, VALVE BKT ﾊﾞﾙﾌﾞ FE
39 DGSS0370 1 HOLDER ﾎﾙﾀﾞ FE
41 DGSS0120 1 BKT BKT FE
44 DGSS0440 2 PIN, LOCATING ﾋﾟﾝ 位置決め φ3 FE
45 DGSS0450 2 PIN, DIAMOND-SHAPED ﾋﾟﾝ ﾀﾞｲﾔ φ3 FE
46 DGSS0460 2 PIN, LOCATING ﾋﾟﾝ 位置決め φ4 FE
47 DGSS0470 2 PIN, DIAMOND-SHAPED ﾋﾟﾝ ﾀﾞｲﾔ φ4 FE
49 DCSS0370 1 BKT BKT FE
51 DCSS0330 1 BKT, RETAINER BKT 押え FE
65 ACSSS8020 4 DOG ﾄﾞｯｸﾞ OT
66 CSSS1200 3 PIN, PIVOT ﾋﾟﾝ 支点 FE
67 CSSS1150 2 SLIDER ｽﾗｲﾀﾞ FE
68 CSSS1180 1 SLIDER ｽﾗｲﾀﾞ FE
69 CSSS1160 2 LEVER ﾚﾊﾞｰ FE
70 CSSS1190 1 LEVER ﾚﾊﾞｰ FE
71 CSSS1170 1 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ FE
72 CSSS1140 2 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ FE
74 WSS4884 1 CLAMPER ｸﾗﾝﾊﾟ FE
75 WSS4874 1 CLAMPER ｸﾗﾝﾊﾟ FE
76 WSS4921 1 COVER 蓋 FE
77 WSS4934 1 COVER 蓋 FE
78 WSS4892 1 BLOCK ﾌﾞﾛｯｸ FE
79 WSS4742 2 PLATE ﾌﾟﾚｰﾄ FE
80 WSS4351 2 PLATE, STOPPER ﾌﾟﾚｰﾄ ｽﾄｯﾊﾟ FE
81 WSS5330 3 SPRING ｽﾌﾟﾘﾝｸﾞ FE
82 WSS4312 2 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ FE
83 WSS4302 2 HOLDER, PIN ﾎﾙﾀﾞ ﾋﾟﾝ FE
98 H10661 2
VALVE, SOL
ﾊﾞﾙﾌﾞ SOL F15T4-F4-PL3-DC24V OT
99 Y30491 4
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJW06-01S OT
100 Y3049W 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-01S OT
101 S1056A 4 SILENCER ｻｲﾚﾝｻ AN101-01 OT
102 H5056M 2 HOLDER ﾎﾙﾀﾞ TM-06 OT
103 K53474 1
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2311F-01-06S(ｼﾛ) OT
105 H2047A 4 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ ﾟ3X8 FE
108 S4032T 2
SENSOR
ｾﾝｻ UM-T50TV OT
110 Y3079N 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-M5 OT
111 Y3086Y 3
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KQ2S06-M5 OT
112 K4150F 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ TKP0130-2B-R18-19L(BKT付) OT
123 S1021A 3
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-3 FE
124 H1063T 1
VALVE, MECHANICAL
ﾊﾞﾙﾌﾞ ﾒｶﾆｶﾙ VM133-M5-01 OT
130 K5169X SCREW, C/R COUNTERSUNK 小ﾈｼﾞ 十穴皿 M2.5X5L FE
CP-743E,CP-742E PARTS LIST
8 - 7
8.2.基板ｸﾗﾝﾌﾟ(DGSS)
8.2.Board clamping unit(DGSS)
8.2.基板ｸﾗﾝﾌﾟ(DGSS)
8.2.Board clamping unit(DGSS)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
131 K5357H
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X5L FE
132 K5256A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X8L FE
133 K5255T
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X6L FE
134 H5283H
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X40L FE
135 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L FE
136 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L FE
137 H5285A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X5L FE
138 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
139 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
140 H5293A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X25L FE
141 K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L FE
142 H5304A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X25L FE
143 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L FE
144 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
145 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
146 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
147 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
148 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
149 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L FE
150 N1085A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0 FE
151 DGSS0500 1 BKT BKT AL
152 DGSS0510 2 BOLT, ADJUSTING ﾎﾞﾙﾄ ｾﾘ FE
153 WSS4911 4 COVER ｶﾊﾞｰ FE
154 DGWM0330 1 NAMEPLATE, SOL 銘板 SOL Japanese(Ref.32-7) OT
155 DGWM0530 1 NAMEPLATE, SOL 銘板 SOL English(Ref.32-9) OT
156 DGWM0730 1 NAMEPLATE, SOL 銘板 SOL French(Ref.32-11) OT
157 K5257A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L FE
158 W1041A WASHER, FLAT ﾜｯｼｬ 平 1W-4 FE
159 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
4X12L FE
160 H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L FE
161 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
CP-743E,CP-742E PARTS LIST
8 - 8
8.2.基板ｸﾗﾝﾌﾟ(DGSS)
8.2.Board clamping unit(DGSS)
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
x9.4
29
34
78
71
33
76
58
57
76
42
42
32
78
71
41
85
43
2
12
67
82
22
14
5
13
76
59
45
91
84
74
84
87
84
89
87
49
36
48
25
83
71
31
76
61
16
88
15
35
77
69
84
87
16
88
15
35
77
69
63
81
17
3
21
21
21
56
85
82
66
83
72
83
71
4
92
73
3
83
72
70
78
40
65
77
8
77
66
70
78
90
90
80
77
67
9
38
78
71
51
51
20
76
59
55
75
39
7
76
60
55
75
39
7
76
60
62
76
26
85
56
27
27
28
82
67
1
83
72
11
79
76
59
37
76
60
11
79
76
60
62
76
60
85
26
50
10
76
59
30
81
60
29
68
77
35
18
19
84
89
87
68
77
35
18
19
24
66
82
46
23
47
6
84
86
52
52
