13.2.ﾌｨｰﾀﾞﾍﾞﾘﾌｧｲ(DGGZ) 13.2.Feeder verification(DGGZ) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 41 W1045A 3 WASEHR, FLAT ﾜｯｼｬ 平 4W-6 FE 42 H5290A 5 BOLT, HEX SO…
13.2.ﾌｨｰﾀﾞﾍﾞﾘﾌｧｲ(DGGZ)
13.2.Feeder verification(DGGZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 ADGGZ7511 2 SENSOR ｾﾝｻ OT
2 DGGZ7030 2 BKT, SENSOR BKT ｾﾝｻ FE
3 DGGZ7040 2 COVER ｶﾊﾞｰ FE
4 K5170T 40 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
5 DGGZ4140 2 COVER, DUSTPROOF ｶﾊﾞｰ 防塵 S10用 PL
6 DCGZ3050 4 COVER, DUSTPROOF ｶﾊﾞｰ 防塵 S30用 OT
7 S40571 2 SENSOR ｾﾝｻ K96-P-FK-S10 ｾﾝｻ基板 OT
8 S40573 4 SENSOR ｾﾝｻ K96-P-FK-S30 ｾﾝｻ基板 OT
9 S32273 40 SPACER ｽﾍﾟｰｻ ESB-305 OT
10 S3227H 40 SPACER ｽﾍﾟｰｻ ASB-315 OT
11 ADGGZ7520 2 SENSOR ｾﾝｻ OT
12 DGGZ7070 2 PLATE ﾌﾟﾚｰﾄ FE
13 H5291A 14 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X18 FE
14 W1022A 14 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
15 W1043A 14 WASEHR, FLAT ﾜｯｼｬ 平 4W-4 FE
16 DGGZ7080 2 COVER, PROTECTIVE ｶﾊﾞｰ 保護 FE
17 H5286A 12 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X6 FE
18 DGGZ4150 2 PLATE, INSULATING ﾌﾟﾚｰﾄ 絶縁 L10用 PL
19 DCGZ3140 4 PLATE, INSULATING ﾌﾟﾚｰﾄ 絶縁 L30用 PL
20 S4057M 4 SENSOR ｾﾝｻ K96-P-FK-L30R LED基板 OT
21 S4057H 2 SENSOR ｾﾝｻ K96-P-FK-L10 LED基板 OT
22 S3227Z 20 SPACER ｽﾍﾟｰｻ C-305 OT
23 K5171D 20 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X12 FE
24 ADGGZ7531 4 SENSOR ｾﾝｻ OT
25 DGGZ4110 4 PLATE ﾌﾟﾚｰﾄ FE
26 H5287A 8 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8 FE
27 W1022A 8 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
28 DCGZ3120 4 COVER ｶﾊﾞｰ FE
29 K5170T 16 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
31 S4057X 4 SENSOR ｾﾝｻ K96-P-FK-R30 通信基板 OT
32 S3227L 16 SPACER ｽﾍﾟｰｻ ASB-319 OT
33 S32273 16 SPACER ｽﾍﾟｰｻ ESB-305 OT
34 S3227Z 4 SPACER ｽﾍﾟｰｻ C-305 OT
35 K5171D 4 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X12 FE
36 DGGZ7010 1 BKT BKT FE
37 N1082A 3 NUT, HEX ﾅｯﾄ 六角 M5 P=0.8 FE
38 H5179G 3 BOLT, HEX ﾎﾞﾙﾄ 六角 M5X50 FE
39 H5323A 3 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18 FE
40 W1024A 3 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
CP-743E,CP-742E PARTS LIST
13 - 7
13.2.ﾌｨｰﾀﾞﾍﾞﾘﾌｧｲ(DGGZ)
13.2.Feeder verification(DGGZ)
13.2.ﾌｨｰﾀﾞﾍﾞﾘﾌｧｲ(DGGZ)
13.2.Feeder verification(DGGZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
41 W1045A 3 WASEHR, FLAT ﾜｯｼｬ 平 4W-6 FE
42 H5290A 5 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15 FE
43 W1022A 5 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
44 W1043A 5 WASEHR, FLAT ﾜｯｼｬ 平 4W-4 FE
45 DGGZ7020 1 BKT BKT FE
46 N1082A 3 NUT, HEX ﾅｯﾄ 六角 M5 P=0.8 FE
47 H5179G 3 BOLT, HEX ﾎﾞﾙﾄ 六角 M5X50 FE
48 H5323A 3 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X18 FE
49 W1024A 3 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
50 W1045A 3 WASEHR, FLAT ﾜｯｼｬ 平 4W-6 FE
51 H5290A 5 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15 FE
52 W1022A 5 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
53 W1043A 5 WASEHR, FLAT ﾜｯｼｬ 平 4W-4 FE
54 DGGZ7050 2 COVER, PROTECTIVE ｶﾊﾞｰ 保護 FE
55 K5170T 12 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
56 DGGZ7060 2 PLATE ﾌﾟﾚｰﾄ AL
57 H5301A 16 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X18 FE
58 W1023A 16 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
59 W1044A 16 WASEHR, FLAT ﾜｯｼｬ 平 4W-5 FE
60 DGGZ4150 2 PLATE, INSULATING ﾌﾟﾚｰﾄ 絶縁 L10用 PL
61 DCGZ3140 4 PLATE, INSULATING ﾌﾟﾚｰﾄ 絶縁 L30用 PL
62 S4057H 2 SENSOR ｾﾝｻ K96-P-FK-L10 LED基板 OT
63 S4057M 4 SENSOR ｾﾝｻ K96-P-FK-L30R LED基板 OT
64 S3227Z 20 SPACER ｽﾍﾟｰｻ C-305 OT
65 K5171D 20 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X12 FE
66 ADGGZ7540 2 SENSOR ｾﾝｻ OT
67 DGGZ4110 2 PLATE ﾌﾟﾚｰﾄ FE
68 H5287A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8 FE
69 W1022A 4 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
70 DCGZ3120 2 COVER ｶﾊﾞｰ FE
71 K5170T 8 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
72 S4057T 2 SENSOR ｾﾝｻ K96-P-FK-R10 通信基板 OT
74 S3227L 8 SPACER ｽﾍﾟｰｻ ASB-319 OT
75 S32273 8 SPACER ｽﾍﾟｰｻ ESB-305 OT
76 S3227Z 2 SPACER ｽﾍﾟｰｻ C-305 OT
77 K5171D 2 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X12 FE
78 DCGZ3150 1 TAPE ﾃｰﾌﾟ OT
CP-743E,CP-742E PARTS LIST
13 - 8
13.2.ﾌｨｰﾀﾞﾍﾞﾘﾌｧｲ(DGGZ)
13.2.Feeder verification(DGGZ)
Ref.33-7
Ref.13-1
二次元バーコードカメラオプション
2-D Barcode Camera(Option)
x6
63
69
B
40
15
63
75
69
33
31
52
20
19
21
39
38
39
21
32
6
66
71
77
23
87
69
89
71
96
95
86
94
85
107
84
69
62
79
71
79
67
72
59
68
69
61
59
68
75
69
62
58
68
A
A
B
54
54
55
37
17
17
3
9
9
41
41
64
70
76
8
83
68
49
63
69
75
25
108
70
76
75
13
12
10
11
5
46
46
59
68
30
27
79
71
29
28
45
80
79
71
44
47
66
71
26
47
18
16
48
48
43
43
53
53
4
24
50
22
42
22
42
2
1
91
81
56
C
82
70
78
57
74
68
60
75
69
61
34
36
35
14
90
68
68
109
109
0.5 1 2
64
75
69
98
70
76
70
76
101
70
76
100
99
105
97
106
103
104
102
D
C
51
