2.Y軸テーブル(2)(BTPT)
2.Y axis table(2)(BTPT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 BTPT0502 1 SLIDE, Y-AXIS ｽﾗｲﾄﾞ Y軸
2 BTPT0181 2 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ
3 BTPT0322 2 BKT, SW BKT SW
4 BTPT0330 1 PLATE ﾌﾟﾚｰﾄ
5 BTPT0342 1 DOG ﾄﾞｯｸﾞ
7 BTPT0400 4 GUIDE ｶﾞｲﾄﾞ
8 BTPT0430 4 BKT BKT
9 BTPT0441 1 JOINT ｼﾞｮｲﾝﾄ
10 BTPT0451 1 JOINT ｼﾞｮｲﾝﾄ
11 BTPT0460 1 ROD, JOINT ﾛｯﾄﾞ ｼﾞｮｲﾝﾄ
12 BTPT0470 2 PIN ﾋﾟﾝ
13 BTPT0512 1 JOINT ｼﾞｮｲﾝﾄ
15 BTPT0590 1 BKT BKT
17 BTPT0630 2 SCREW, ADJUSTING ﾈｼﾞ 調整
18 BTPT0640 4 BKT BKT
19 BTPT0652 2 HOLDER ﾎﾙﾀﾞ
20 BTPT0911 2 HOLDER ﾎﾙﾀﾞ
21 BTPT1091 4 PIN ﾋﾟﾝ
22 BTPT0681 1 LOCATOR 当金
23 BTPT0691 1 LOCATOR 当金
24 BTPT0701 1 LOCATOR 当金
25 A4043A 2 ELBOW ｴﾙﾎﾞ PL6-01
26 BTPT0752 1 PLATE, VACUUM ﾌﾟﾚｰﾄ ﾊﾞｷｭｰﾑ
27 BTPT0762 1 PLATE ﾌﾟﾚｰﾄ
28 BTPT0770 2 PLATE ﾌﾟﾚｰﾄ
29 BTPT0780 1 PLATE ﾌﾟﾚｰﾄ
30 BTPT0811 4 PLATE, RUBBER ﾌﾟﾚｰﾄ ｺﾞﾑ
31 BTPT0820 2 SCREW, ADJUSTING ﾈｼﾞ 調整
32 BTPT0830 1 PLATE, TERMINAL ﾌﾟﾚｰﾄ ﾀｰﾐﾅﾙ
33 BTPT0840 1 PLATE, TERMINAL ﾌﾟﾚｰﾄ ﾀｰﾐﾅﾙ
34 BTPT0850 1 ADAPTER ｱﾀﾞﾌﾟﾀ
35 BTPT1170 1 JOINT ｼﾞｮｲﾝﾄ
36 BTPT0862 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ
37 BTPT0873 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ
38 BTPT1050 4 COLLAR ｶﾗｰ
39 BTPT1060 4 COLLAR ｶﾗｰ
41 BTPT0480 1 PIN ﾋﾟﾝ
GL-541E PARTS LIST ver08
2 - 2
2.Y軸テーブル(2)(BTPT)
2.Y axis table(2)(BTPT)
2.Y軸テーブル(2)(BTPT)
2.Y axis table(2)(BTPT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
42 NPT1290 2 BKT BKT
43 K4162A 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ HPU203-R30 20LINK
44 S4040X 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX306-W2A
46 H4388A 4 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA1220Z
47 H4407T 1 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA1015Z
48 H4403A 1 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TLA810Z
49 H4452M 4 BEARING, ROLLER ﾍﾞｱﾘﾝｸﾞ ﾛｰﾗ NART5UUR
50 H4286H 4 BEARING, SLIDE ﾍﾞｱﾘﾝｸﾞ ｽﾗｲﾄﾞ LMK10LUU
51 S1024A 6 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-6
52 Y3025A 1 UNION ﾕﾆｵﾝ PMF8-02
53 Y3024A 2 UNION ﾕﾆｵﾝ PMF6-01
54 K5342D 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-06S(ｼﾛ)
55 BTPT1040 1 BKT BKT
56 K5255T SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X6L
57 K5256A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X8L
58 K5256H SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X12L
59 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
60 H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
61 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L
63 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
64 H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
66 H5305A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X30L
67 N1085A NUT, HEX ﾅｯﾄ 六角 M6P=1.0
68 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
69 W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
70 W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
71 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
72 W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
73 W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
74 N1088A NUT, HEX ﾅｯﾄ 六角 M6-L
75 S1022A 4 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-4
77 K1053A 1 FIXTURE 金具 HPU2-MAOS
78 N4015A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X4L
79 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L
80 W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
81 JQC0842 3 HOLDER 受け
82 JQC0852 3 HOLDER 受け
GL-541E PARTS LIST ver08
2 - 3
2.Y軸テーブル(2)(BTPT)
2.Y axis table(2)(BTPT)
2.Y軸テーブル(2)(BTPT)
2.Y axis table(2)(BTPT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
83 NPT0791 6 CLAMPER ｸﾗﾝﾊﾟ
84 A5103A 6 O RING O ﾘﾝｸﾞ P22
85 A5095A 3 O RING O ﾘﾝｸﾞ P12
86 H1190A 3 PAD ﾊﾟｯﾄ VP-20RS
87 H1189A 3 PAD ﾊﾟｯﾄ VP-15RS
88 JQC1090 6 CLAMPER ｸﾗﾝﾊﾟ
89 H20135 1 PIN ﾋﾟﾝ IY-G004
90 S1031A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ STW-10
91 A4045Z 1 ELBOW ｴﾙﾎﾞ PL8-01
93 A4034A 1 ELBOW ｴﾙﾎﾞ GPL-63
94 PPT1490 194 PLUG ﾌﾟﾗｸﾞ
95 BTPT1101 4 PIN ﾋﾟﾝ
96 BTPT1130 4 SPRING ｽﾌﾟﾘﾝｸﾞ
97 H5341A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X20L
98 W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
99 W1052A WASHER, FLAT ﾜｯｼｬ 平 8M/MX1.6X17(1W-8)
101 BTPT2520 1 BKT BKT
102 K4164M 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ HPU204-R38 16Link
103 K1049A 1set FIXTURE 金具 HPU2-FA0
104 K1052A 1set FIXTURE 金具 HPU2-MA0
105 BTPT1081 1 BKT BKT
106 Y3085T 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQ2H08-02S
107 BTPT1160 1 BKT BKT
108 W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H
109 S2125Z 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CQ2D40-40DCM
100 H5275A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X8L
110 K1050A 1 FIXTURE 金具 HPU2-FAOS ･
