GL-541E P ARTS LIST ver08 1 8 . Y 軸テーブル( ローラ搬送) ( オプション) ( B T P T ) 1 8 . Y a x i s t a b l e ( R o l l e r g u i d e d ) ( O p t i o n ) ( B T P T ) 1 8 - 1 1 8 . Y 軸テーブル( ローラ搬送) ( オプション) ( B T P T ) 1 8 . Y a x i s t …

100%1 / 90
17.ニードル一覧表(BTRG)
17.Needle chart(BTRG)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 AHRG-0671 1 NEEDLE ﾆｰﾄﾞﾙ Note.1
2 AHRG-0859 1 NEEDLE ﾆｰﾄﾞﾙ Note.2
3 AHRG-1332 1 NEEDLE ﾆｰﾄﾞﾙ Note.3
4 AHRG-0698 1 NEEDLE ﾆｰﾄﾞﾙ Note.4
5 AHRG-0702 1 NEEDLE ﾆｰﾄﾞﾙ Note.5
6 AHRG-1352 1 NEEDLE ﾆｰﾄﾞﾙ Note.6
7 AHRG-1322 1 NEEDLE ﾆｰﾄﾞﾙ Note.7
8 AJRG-0832 1 NEEDLE ﾆｰﾄﾞﾙ Note.8
9 ANRG-2013 1 NEEDLE ﾆｰﾄﾞﾙ Note.9
10 ANRG-2022 1 NEEDLE ﾆｰﾄﾞﾙ Note.10
11 ANRG-2032 1 NEEDLE ﾆｰﾄﾞﾙ Note.11
12 ANRG-2041 1 NEEDLE ﾆｰﾄﾞﾙ Note.12
13 AHRG-0753 1 NOZZLE TOOL, ASSY ﾉｽﾞﾙ工具ASSY ﾉｽﾞﾙ清掃工具
Note.1 : Needle inside diameterφ0.4, Stopper diameterφ0.5, Needle-to-board gap 0.1mm
Note.2 : Needle inside diameterφ0.4, Stopper diameterφ1.3, Needle-to-board gap 0.1mm
Note.3 : Needle inside diameterφ0.6, Stopper diameterφ0.7, Needle-to-board gap 0.3mm
Note.4 : Needle inside diameterφ0.5, Stopper diameterφ0.5, Needle-to-board gap 0.2mm
Note.5 : Needle inside diameterφ0.6, Stopper diameterφ0.5, Needle-to-board gap 0.3mm
Note.6 : Needle inside diameterφ0.7, Stopper diameterφ0.7, Needle-to-board gap 0.4mm
Note.7 : Needle inside diameterφ0.5, Stopper diameterφ1.3, Needle-to-board gap 0.1mm
Note.8 : Needle inside diameterφ0.3, Stopper diameterφ1.0, Needle-to-board gap 0.1mm
Note.9 : Needle inside diameterφ0.3, Stopper diameterφ0.5, Needle-to-board gap 0.1mm
Note.10 : Needle inside diameterφ0.4, Stopper diameterφ0.5, Needle-to-board gap 0.1mm
Note.11 : Needle inside diameterφ0.6, Stopper diameterφ0.7, Needle-to-board gap 0.15mm
Note.12 : Needle inside diameterφ0.4, Stopper diameterφ0.5, Needle-to-board gap 0.15mm ･
GL-541E PARTS LIST ver08
17 - 2
17.ニードル一覧表(BTRG)
17.Needle chart(BTRG)
GL-541E PARTS LIST ver08
18.Y軸テーブル(ローラ搬送)(オプション)(BTPT)
18.Y axis table(Roller guided)(Option)(BTPT)
18 - 1
18.Y軸テーブル(ローラ搬送)(オプション)(BTPT)
18.Y axis table(Roller guided)(Option)(BTPT)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
x3.4
1
2
1
2
1
1
2
1
2
1
3
4
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
6
6
208
176
165
175
161
175
161
175
161
183
162
176
167
175
161
13
13
B
A
139
26
18.Y軸テーブル(ローラ搬送)(オプション)(BTPT)
18.Y axis table(Roller guided)(Option)(BTPT)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1 BTPT6010 6 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
2 BTPT6020 4 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ
3 BTPT6030 1 PLATE ﾌﾟﾚｰﾄ
4 BTPT6040 1 PLATE ﾌﾟﾚｰﾄ
5 MQC1292 8 PULLEY ﾌﾟｰﾘ
6 H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M3X8L ･
