3-35
3
Board Editor
2.10.3 Function of Replacing Data with Note
Thefunctionof“NoteDataisReplace”isasfollows.
Replace Screen
64360-S0-00
“NoteDataisReplace”checkboxisaddedtotheconventionalreplacedialog.AlsoletNoteDatabethe
object of replace by selection of this item.
3-36
3
Board Editor
n
Note Data is Replace
ItoperatesitforNoteDataisReplaceasfollows.
●
The display of a Replace screen
Select“Replace”in“Edit”menutoopenReplacescreen.
“Edit” - “Replace” Menu
64361-S0-00
Replace Screen opens
64362-S0-00
●
Replace Screen
AsetupofNotedataReplacecanbeperformedfromareplacescreen.
Replace Dialog
64363-S0-00
3-37
3
Board Editor
●
Replace condition setup
When“NoteDataisReplace”checkboxischecked(ON),NoteDataissetastheobjectofReplace.However,
whenfollowing“2.1.3.1Replaceobjectinformation”
•
“2.1.3.2Replaceobjectitem”isnotappliedto
conditions, gray out of Note Data is carried out and it cannot be chosen. The conditions from which Note Data
is set as the object of replace are as follows.
[Replace object information]
• Mount
• Offset
• Fiducial
• Badmark
• Dot Dispense
• Sequence
• Height
[Replace object item]
• X(X1
•
X2:Fiducial)
• Y(Y1
•
Y2:Fiducial)
• R
• Z(Sequence)
• XOffset(X1Offset
•
X2Offset:Fiducial)
• YOffset(Y1Offset
•
Y2Offset:Fiducial)
• ROffset
• Z Offset(Sequence)
• XSignReverse(X1SignReverse
•
X2SignReverse:Fiducial)
• YSignReverse(Y1SignReverse
•
Y2SignReverse:Fiducial)
• RSignReverse
• ZSignReverse(Sequence)
