Cylinder / Shaft
Cleaner Section
KLV-1505
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KGY-M3650-00 SHAFT,SPRING 1 /
39
92012-06016 BOLT BUTTON HEAD
8
2 KGY-M3652-00 OIL FREE BUSH 2 /
Í
40
92902-04200 WASHER,PLAIN
8
3 KGY-M3655-00 SHAFT21,SPRING 1 /
41
92902-05200 WASHER,PLAIN
4
4 KGY-M3663-00 PLATE,STOPPER 1 /
Í
42
95302-06600 NUT HEXAGON
4
5 KHT-M3608-00 SHAFT,CLEANER 1 /
Í
43
91312-06012 BOLT HEX,SOCKET HEAD
4
6 KHT-M3614-01 PLATE, CLYNDER L 1 /
Í
44
92902-05600 WASHER,PLAIN
2
7 KHT-M3617-01 SHAFT,LINEAR BUSH 2 /
Í
45
91312-05010 BOLT HEX,SOCKET HEAD
2
8 KHT-M3617-10 BUSH 2 /
Í
46
90990-28J020 WASHER,PLAIN
2
9 KHT-M3625-00 HOLDER, DRY BRG. 2 /
Í
47
10 KHT-M3647-00 SPRING 2 2 /
48
11 KKX-M3604-00 PLATE,BACK F 1 /
Í
49
12
KKX-M3605-00 BRKT.,BACK PLATE 2
/
Í
50
13 KLV-M3602-00 PLATE,SIDE L 1 /
Í
51
14 KLV-M3603-00 PLATE,SIDE R 1 /
Í
52
15 KLV-M3604-00 BRKT.,BOTTOM PLATE 1 /
Í
53
16 KLV-M3606-00 PLATE,SHAFT 1 /
Í
54
17 KLV-M3609-00 CYLINDER 2 B
Í
55
18 KLV-M3620-00 PLATE,SAFETY 1 1 /
Í
56
19 KLV-M3621-00 PLATE,SAFETY 2 1 /
Í
57
20 KLV-M3642-00 TUBE,SOLVENT 2 1 /
Í
58
21 KLV-M653S-00 SENSOR CL HI ASSY 1
JCN1 CL HI B
Í
59
22 KLV-M653S-10 SENSOR CL LOW ASSY 1
JCN2 CL LOW
B
Í
60
23 $NK-4N NYLON CLIP 4 61
24 $NK-2N NYLON CLIP 3 62
25 $SC4-M5A SPEED CONTROLLER 2 /
Í
63
26 $SL4-M5 JOINT 2 /
Í
64
27 90990-11J003 SCREW, PAN HEAD W/W 7 65
28 90990-28J017 WASHER,PLAIN 4 66
29 90990-28J094 WASHER,PLAIN 2 67
30 90990-28J146 WASHER,PLAIN 2 68
31 90990-28J151 WASHER,PLAIN 2 69
32 90990-28J152 WASHER,PLAIN 2 70
33 90990-41J141 COLLAR 2 /
Í
71
34 91312-03008 BOLT HEX,SOCKET HEAD 10 72
35 91312-04006 BOLT HEX,SOCKET HEAD 10 73
36
91312-04008 BOLT HEX,SOCKET HEAD
16 74
37
91312-05008 BOLT HEX,SOCKET HEAD
6 75
38
92012-05014 BOLT BUTTON HEAD
2 76
5
1
Cylinder / Shaft
