Page HANWHA TECHWIN 96 SLM120/110 Cover Ass’y (3/3) 1 4 3 7 7 10 10 8 8 13 5 10 9 10 2 9 11 6 11 13 12 12
Page
HANWHA TECHWIN
95
SLM120/110
Cover Ass’y (2/3)
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
A J90521048A KEYBOARD_MOUSE_ASSY 1
A-1 CD04-900026 MINI_KEYBOARD 5510UH 1
A-2 J70521450A KEYBOARD_BASE J70521450A 1
A-3 CD04-000013 COMPUTER MOUSE-MS622;OPTICAL MOUSE,330mm 1 CD04-
900005
A-4 J70521241A MOUSE_BRACKET J70521241A 1
A-5 FC28-901099 TRIMS-2 1
B J90521099A AP5_OP_PANEL_ASSY 1
B-1 PT03-900161A STICKER-EMERGENCY PT03-900161A 2
B-2 EP20-900127 EMERGENCY S/W[704.075.2] 2
B-3 EP20-900029 ILLUMINATED PUSHBUTTON ACTUATOR 5
B-4 J71521015A BUTTON_CAP 1
B-5 J70521673A AP5_OP_PANEL_PLATE J70521673A 1
C AM03-900154 AP5_ACRYL_DOOR_STD_ASSY AM03-900154 1
C-1 FC09-000706A BRACKET-GAS_SPRING_BRACKET_MOVE 4
C-2 FC07-000271A BLOCK-GAS_SPRING_BRACKET_SPACER 2
C-3 FC29-900147 HANDLE[AP-2 BLACK] 2
C-4 FC07-000270A BLOCK-JOINT_BLOCK_MIDDLE 3
C-5 J70521087A WINDOW_HINGE J70521087A 3
Page
HANWHA TECHWIN
96
SLM120/110
Cover Ass’y (3/3)
1
4
3
7
7
10
10
8
8
13
5
10
9
10
2
9
11
6
11
13
12
12
Page
HANWHA TECHWIN
97
SLM120/110
Cover Ass’y (3/3)
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
1 FC15-000747A COVER-SLM_DOWN_SIDE_COVER_L 1 J70521703A
2 FC15-000748A COVER-SLM_DOWN_SIDE_COVER_R 1 J70521704A
3 FC15-000746A COVER-SLM_COVER_DOWN_BACK 1 J70521706A
4 J70521714A AP5_COVER_DOWN_LEFT J70521714A 1
5 J70521713A AP5_COVER_DOWN_RIGHT J70521713A 1
6 FC15-000745A SLM_COVER_LFM 1 J70521696A
7 EP07-901508 COOLING FAN[4715MS-22T-B50] 2
8 FC29-900158 COVER_PULL 4
9 FC12-900009 MAGNETIC C-179 1
10 FC29-900197 B-530-1_HINGE B-530-1 4
11 EP07-901528 FAN_FILTER 120MM(NMB) 2 HP04-900010
12 HP04-000075 FILTER,AIR-fan filter_ metal_120mm 2
