Page HANWHA TECHWIN 207 SLM120/110 Motor IF Board Interface 120 (4/8) NO. Lev . P ART NO. P ART NAME Q'TY Old No. Supply Su pply L T Reference 1 AM03-00476 6A CABLE ASSY -LE FT_Z4_MOTOR 1 2 J90834358A HEAD_Z5_HOME_S…
Page
HANWHA TECHWIN
206
SLM120/110
Motor IF Board Interface 120 (4/8)
^4`
^5`
^6`
^7`
^8`
^9`
Page
HANWHA TECHWIN
207
SLM120/110
Motor IF Board Interface 120 (4/8)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-004766A CABLE ASSY-LEFT_Z4_MOTOR 1
2 J90834358A HEAD_Z5_HOME_SENSOR_CABLE_ASSY 1
3 J90834223A P_MOTOR_CABLE_ASSY AP5_MD037 1
4 J90834359A HEAD_P_HOME_CABLE_ASSY AP5_MD069 1
5 J90834349A HEAD_Z3_HOME_SENSOR_CABLE_ASSY 1
6 J90834362A HEAD_R3_HOME_CABLE_ASSY AP5_MD072 1
Page
HANWHA TECHWIN
208
SLM120/110
Motor IF Board Interface 120 (5/8)
^4`
^5`
^6` ^7`
^:`
^8`
^4`
^;`
^9`
^:`
