Page HANWHA TECHWIN 10 SLM120/110 Conveyor Ass’y (1/5) 30 21 3 31 7 20 18 6 3 37 37 35 35 35 35 35 29 39 A A A 19 14 13 17 16 32 27 6 36 24 23 11 2 2 2 B 33 33 34 15 15 35 35 35 1 5 B 8 12 26 25 10 D 17 14 13 25 10 4 B C…
Page
HANWHA TECHWIN
9
SLM120/110
Feeder Base Ass’y
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
A J90571071A FEEDER_BASE_ASSY 1
1 FC14-000876 COUPLER 16 HP06-900169
2 J70571024A BODY_FEEDER_BASE J70571024A 1
3 FC15-000121B COVER-FEEDER_BASE_TOP_PLATE 1 J70571057A
4 J70571058A VERTICAL_PLATE J70571058A 1
5 HP06-900027 FITTING [KQ2L04-M5/PL4-M5M/SQL04-M5] 1
6 J41041067A SCM_FEEDER_BASE_COVER J41041067A 1
7 J70571059A FB_FRONT_COVER J70571059A 1
8 FC15-003011A SIDE CABLE COVER-FB[J7057213A] 2 J7057213A
9 J91741280A SCM_FEEDER_BASE_ASSY REV 1.0 1
Page
HANWHA TECHWIN
10
SLM120/110
Conveyor Ass’y (1/5)
30
21
3
31
7
20
18
6
3
37
37
35
35
35
35
35
29
39
A
A
A
19
14
13
17
16
32
27
6
36
24
23
11
2
2
2
B
33
33
34
15
15
35
35
35
1
5
B
8
12
26
25
10
D
17
14
13
25
10
4
B
C
C
4
36
B
B
A
22
28
28
D
C
D
D
5
9
6
12
40
6
Page
HANWHA TECHWIN
11
SLM120/110
Conveyor Ass’y (1/5)
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
A MOVE_RAIL_ASSY 1
1 J71531379A ap5-04-conv_rear_frame J71531379A 1
2 J7153373A FIDUCIAL DISK[J7153373A] 3
3 FC18-902629 BUTTON HEAD SOCKET SCREW M3*8 (NI/ZN) 24
4 MC05-900189 FLAT-BELT_MAM_5P_1815_02 2
5 J7053047A IDLER SPACER-S 10
6 J7053184A SQUARE NUT M4 15
7 J70532005A ap5-04-pcb_guide_rc_bottom_3 J70532005A 2
8 J7253007A IDLER2 6
9 J7253006A IDLER1 4
10 EP08-900073 STEP_MOTOR 2S56Q-01842SR2 2
11 EP03-000038 CABLEVEYOR-HSP0130-1BN-37R-15LINK 1 EP03-
900058
12 FC18-000740A IDLER SHAFT-S [0135-641105] 10
13 J70531083A ALT_MOTOR_SUPPORT J70531083A 8
14 J70531106A BRACKET_BELT_MOTOR_S J70531106A 2
15 J70531739A MOVE_STAND J70531739A 2
16 J70531992A ap5-04-adjust_shaft J70531992A 4
17 J70531995A ap5-04-clamp_plate_new J70531995A 2
18 J70531996A ap5-04-clamp_plate_spring_new J70531996A 8
19 J70531997A ap5-04-clamp_shaft J70531997A 4
20 FC30-001099A PLATE-PLATE-PCB_CLAMPING_EXT 12 J70532001A
21 J70532003A ap5-04-pcb_guide_rc_bottom J70532003A 2
22 J70532004A ap5-04-pcb_guide_rc_bottom_2 J70532004A 2
23 J70532039A CABLEVEYOR_BKT J70532039A 1
24 FC30-001100A PLATE-SENSOR_DOG_EXT 1 J70532112A
25 FC07-000686A STEP MOTOR PULLEY 2
