Page HANWHA TECHWIN 232 SLM120/110 Electric Circuit Diagram 120 (1/5)
Page
HANWHA TECHWIN
231
SLM120/110
Safety Interlock Interface 110 (2/2)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 J90834178A FDR_BASE_PWR_CABEL_ASSY AP5_FD006 1
2 J90834148A CONV_IF_BD_POWER_CABLE_ASSY AP5_CV004 1
3 J90834082A AXIS_SEN_BD_PW_CABLE_ASSY AP5_AX001 1
4 J90834314A SC_CN22_AXIO_1_PWR_CABLE_ASSY AP5_SC007 2
5 AM03-013461B HEAD_MOTOR_IF_BD_1_PW_CABLE_ASSY 1 J90834316A/AM03-013461A
6 J90611826A FLAT_CABLE_ASSY AP5_FL001 2
7 AM03-013462B HEAD_MOTOR_IF_BD_2_PW_CABLE_ASSY 1 J90834317A/AM03-013462A
8 J90834169A FDR_IO_PWR_CABLE_ASSY AP5_FD001 1
Page
HANWHA TECHWIN
232
SLM120/110
Electric Circuit Diagram 120 (1/5)
Page
HANWHA TECHWIN
233
SLM120/110
Electric Circuit Diagram 120 (1/5)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
