Page HANWHA TECHWIN 19 SLM120/110 Conveyor Ass’y (3/5) No. LEVEL P ART No. P ART NAME Q'TY TYPE Old No. St o ck Apply Reference
Page
HANWHA TECHWIN
18
SLM120/110
Conveyor Ass’y (3/5)
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
26 J71531374A ap5-04-clamp_plate_f_new J71531374A 4
27 J71531375A ap5-04-clamp_plate_m_new J71531375A 4
28 J71531376A ap5-04-clamp_plate_rib_new J71531376A 2
29 J71531377A ap5-04-clamp_stopper J71531377A 4
30 J71531384A ap5-04-pcb_guide_end_l J71531384A 1
31 J71531385A ap5-04-pcb_guide_end_r J71531385A 1
32 J7253008B STOPPER[J7253008B] 8
33 HP06-900047 ELBOW FITTING 2
34 HP03-900015 STOPPER_CYLINDER1 1
35 J70531029A STOPPER_POST J70531029A 1
36 SHCS[M4*18] 1
37 FC09-000397C BRACKET-FEEDER_UNLOCK_SENS 2 FC09-000397A FC09-000397A/ FC09-000397B
Page
HANWHA TECHWIN
19
SLM120/110
Conveyor Ass’y (3/5)
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
Page
HANWHA TECHWIN
20
SLM120/110
Conveyor Ass’y (4/5)
9
16
3
5
4
13
3
8
8
14
17
11
11
15
10
6
12
18
7
1
19
