Page
HANWHA TECHWIN
46
SLM120/110
Head Ass’y (8/12)
24
2
48
39
44
31
30
17
33
35
50
6
40
46
14
26
32
3
9
44
45
29
10
1
42
34
47
11
19
4
43
21
12
41
20
48
5
23
22
38
25
25
16
13
15
15
8
18
7
51
27
36
28
37
Page
HANWHA TECHWIN
47
SLM120/110
Head Ass’y (8/12)
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
A SPINDLE_MODULE1_ASSY 1
1 J71551837A T_MOTOR_PULLEY J71551837A 1
2 J71551840A Z_MOTOR_PULLEY J71551840A 1
3 FC18-901422 O_RING ID7 X WD0.5 1
4 J71551841A Z_ROD_HOUSING1 J71551841A 1
5 J72551103A SPRING_BASE J72551103A 1
6 J67131038A COIL_TUBE J67131038A 1
7 J90551508A BALL_SPLINE_ASSY J90551508A 1
8 J71551838A T_MOTOR_CABLE_BRACKET J71551838A 1
9 J70551867A PACKING_HOUSING J70551867A 1
10 J70551868A PACKING_COLLAR J70551868A 1
11 J70551869A Z_BELT_CLAMP J70551869A 1
12 J70551873A Z_BEARING_PLATE J70551873A 1
13 J70551874A Z_IDLE_SHAFT J70551874A 1
14 J70551899A Z_SENSOR_DOG_1 J70551899A 1
15 J70551901A SPINDLE_SPRING 2
16 J70551947A Z_IDLER_CAP J70551947A 1
17 J70551948A Z_SENSOR_GUIDE_2 J70551948A 1
18 J70551952A T_CABLE_CLAMP_1 J70551952A 1
19 J71551847A Z_BELT_FITTING J71551847A 1
20 J71551890A Z_MOTOR_PLATE J71551890A 1
21 J71551891A HEAD_FIDUCIAL_SHAFT J71551891A 1
22 J72551120A SPRING_COLLAR J72551120A 1
23 J72551121A SPRING_TOP_BASE J72551121A 1
24 J72551122A Z_CABLE_CLAMP J72551122A 1
25 MC03-900127 BEARING 2
Page
HANWHA TECHWIN
48
SLM120/110
Head Ass’y (8/12)
No. LEVEL PART No. PART NAME Q'TY TYPE Old No. Stock Apply Reference
26 J70551419A LOCK_NUT_Z_2 J70551419A 1
27 M2*6(BL/ZN)
28 J70551452A Z_SPACER J70551452A 1
29 J70551951A Z_STOP_PLATE_2 J70551951A 1
30 J70551980A Z_STOP_PLATE_3 J70551980A 1
31 J70551894A Z_SENSOR_BRACKET_1 J70551894A 1
32 J71551846A Z_CAP J71551846A 1
33 J71551827A SPINDLE_HOUSING1 J71551827A 1
34 J71551862A T_MOTOR_BRACKET_1 J71551862A 1
35 J71551889A Z_CABLE_BKT_1 J71551889A 1
36 J7255021B SILICON TUBE(BLACK ??) [J7255021B] 1
37 HP07-900278 Y_PACKING KSYN-4 1
38 J71551848A Z_IDLER_PULLEY J71551848A 1
39 EP19-900119 MICRO PHOTO SENSOR[PM-L24] 1
40 MC13-900113 LM_GUIDE SEBS5BYUU1-70P 1
41 AM03-014928A CABLE ASSY-LEFT_Z_MOTOR_AS 1 EP08-900149
42 MC05-900171 TIMING_BELT 129-1.5GT-3 1
43 MC05-900191 TIMING_BELT 339-1.5GT-5 1
44 MC03-900066 BALL_BEARING 693ZZ 2
45 HP06-900228 FITTING PL3-M3M 1
46 EP19-900134 MICRO_PHOTO_SENSOR PM-F24 1
47 EP08-000007 MOTOR,STEP;5 PHASE,ET1:ETC. 1
48 J71551840A SOCKET SET SCREW M3*3(BL/ZN) 2
49
50 M2*8(BL/ZN) 2
51 M2*4 4
