DuraBlue II Customer Product Manual - 第157页
Parts 7-19 Part 1126931_01 2018 Nordson Corporation This page intentionally left blank.
Parts
7-18
Part 1126931_01
2018 Nordson Corporation
Melter Back Panel Parts ‐ 400V
See Figure 7‐12.
Item Part Description Quantity Note
— ‐ ‐ ‐ ‐ ‐ ‐ ‐ 400V ASSEMBLY, ELECTRICAL, PANEL, BACK,
ONE/TWO‐PUMP
—
1 ‐ ‐ ‐ ‐ ‐ ‐ ‐ PLATE ASSY,ELEC CABINET,BACK, EZ 1
2 7411713 CIRCUIT BREAKER 16A 1‐POLE 1
3 7411735 SERVICE KIT,MOTOR CONTROL,EZ 1 or 2
4 ‐ ‐ ‐ ‐ ‐ ‐ ‐ TERMINAL BLOCK, ZDU, 2.5 8
5 ‐ ‐ ‐ ‐ ‐ ‐ ‐ EW35 4
6 ‐ ‐ ‐ ‐ ‐ ‐ ‐ TERMINAL BLOCK, END PLATE ZAP/TW1 1
7 ‐ ‐ ‐ ‐ ‐ ‐ ‐ TERMINAL CONNECTOR, ZQV2, 5/2 2
8 ‐ ‐ ‐ ‐ ‐ ‐ ‐ HEXNUT, FLANGED, SERRATED, M5 2
01
05
030802
DETAIL A
07
05
04 06
DETAIL A
Figure 7‐12 Melter back panel assembly parts (400V melter shown)
Parts
7-19
Part 1126931_01
2018 Nordson Corporation
This page intentionally left blank.
Parts
7-20
Part 1126931_01
2018 Nordson Corporation
Melter Right Panel Parts ‐ 400V
See Figure 7‐12.
Item Part Description Quantity Note
— ‐ ‐ ‐ ‐ ‐ ‐ ‐ 400V ASSEMBLY, ELECTRICAL, PANEL, BACK,
ONE/TWO‐PUMP
—
1 ‐ ‐ ‐ ‐ ‐ ‐ ‐ PLATE ASSY,ELEC CABINET,BACK, EZ 1
2 1122064 SVCE KIT,MAIN,PCA 1
3 1122974 SVCE KIT, DURABLUE, EXPANSION PCA 1
4 1031175 SVCE KIT, DURABLUE, 2H TO 4H CONVERSION 1
5 7410952 RELAY,DC24V 1
6 777630 BASE, RELAY (OMRON) 1
7 7400010 CLIP,RELAY 2
8 227569 Jumper3/N/PE,AC 400-230V 1
9 - - - - - - - TERMINAL BLOCK,28POS,I/O 1
10 - - - - - - - terminal block ZDK 2,5/1,5 PE 1
11 - - - - - - - terminal-end-plate ZAP/TW ZDK2,5/1,5 1
12 - - - - - - - TERMINAL BLOCK,ZPE 4 1
13 - - - - - - - TERMINAL BLOCK,END PLATE,ZAP/TW 4 DB 1
14 - - - - - - - EW35 1
15 - - - - - - - HARNESS,1PH PWR,EXP-LE,ADVANTAGE 1
16 - - - - - - - HARNESS,RELAY PWR,EXP-LE,DURABLUE 1
17 7400352 RIBBON CABLE ASSY,20POS,2 HEATERS,400V 1
18 - - - - - - - HARNESS,ENABLE RELAY TO EXP J1,ALTABLUE 1
19 - - - - - - - HARNESS I/O,EZ 1
20 - - - - - - - HARNESS XT2 TO J4 J5,6HG,EZ 1
21 - - - - - - - EXPANSION BOARD XT5 WIRES ASSY. EZ 1
22 - - - - - - - FERRULE,WIRE,22AWG,INS,WHITE 18
23 - - - - - - - SCR,PAN,REC,W/WASHER,M4X10,ZN 4
24 - - - - - - - SCR,PAN,REC,M3X8,ZN 7
25 - - - - - - - LOCKWSHRM,EXT,M3,STL,ZN 7
26 - - - - - - - SCR,PAN,REC,M4X10,ZN 4
27 - - - - - - - WASHER,LK,M,EXT,M4,STL,ZN 4
28 - - - - - - - HEXNUT,FLANGED,SERRATED,M5 2
29 - - - - - - - SCR,PAN,SLT,M3X10,ZN 2
30 - - - - - - - WASHER,FLT,M,REG,M3,ZINC PLATE 2
