Parts
7-27
Part 1126931_01
2018 Nordson Corporation
Recommended Spare Parts
Part Description
Hydraulic Parts
7402299 COUPLING, M24, DAN/NORMAL
7410580 SERVICE KIT,HEATER, 240V,800W,1/2 X 16L
7410581 SERVICE KIT,HEATER,240V,900W,1/2 X 9.0L
207932 SAFETY VALVE, 85 BAR, VB/DB
1058990 CORDSTOCK, 3 MM OD, VITON, 75D
7410545 GASKET,HOPPER,EZ,20L
7410543 GASKET,HOPPER,EZ,45L
7410582 SERVICE KIT,MOTOR,NDS-005 0.25KW
7410542 INSULATION,HOPPER,EZ,20L
7410540 INSULATION,HOPPER,EZ,45L
Electrical Parts
7411700 HARNESS, HOSE/GUN HC L1,EZ
1026662 CABLE ASSY,RIBBON,34 POS,3 HEADERS
7400352 RIBBON CABLE ASSY,20POS,2 HEATERS,400V
7411739 KEYPAD,MOTOR DRIVER,EZ
7411704 HARNESS, HOSE/GUN HC H5,EZ
7411705 HARNESS, HOSE/GUN HC H6,EZ
7411731 HARNESS, HOSE/GUN HC H5,240V,EZ
7411732 HARNESS, HOSE/GUN HC H6,240V,EZ
7411735 SERVICE KIT,MOTOR CONTROL,EZ
7411712 CIRCUIT BREAKER,32A 1-POLE
7411708 BOARD,BREAKOUT,RSMA-20D0CD,TB,20POS,EZ
7411710 CIRCUIT BREAKER,50A 3-POLES
7411711 CONTACTOR,40A
7410952 RELAY,DC24V
777630 BASE, RELAY (OMRON)
207396 SOLID-STATE RELAY, 100−260 VAC, 15 A,DC TRIGGER
7400070 SOLID-STATE RELAY, 100−260 VAC, 35 A,DC TRIGGER
7411713 CIRCUIT BREAKER,16A,1-POLE
1122064 SVCE KIT,DURABLUE,MAIN,PCA
1122974 SVCE KIT, DURABLUE, EXPANSION PCA
1031175 SVCE KIT, DURABLUE, 2H TO 4H CONVERSION
7400010 CLIP,RELAY
227569 JUMPER3/N/PE,AC 400-230V
Parts
7-28
Part 1126931_01
2018 Nordson Corporation
This page intentionally left blank.
Technical Data
8-1
Part 1126931_01
2018 Nordson Corporation
Section 8
Technical Data
General Data
Storage temperature - 45° C to + 75 ° C
- 49 ° F to + 167 ° F
Type of heating Cartridge‐type resistance heating elements
Temperature sensor
— Measuring precision
Ni120 " 1 °C
Material pressure 5 to 85 bar 0.5 to 8.5 MPa 72.5 to 1233 psi
Melting capacity 1 tank‐full per hour
Degree of protection IP 33
Noise emission 1 motor: 60 dBA
2 motors: 66 dBA
Motor type 3 ph AC motor
Gear box type Helical gear
Motor/pump speeds 94 rpm
Heatup time <45 min
Temperatures
Min. ambient temperature - 5 °C 23 °F
Max. ambient temperature 40 ° C 104 °F
Humidity 10 to 95 %, not condensing
Min. operating temperature
(setpoint)
40 ° C 100 °F
Max. operating
temperatures
230 ° C 450 °F
Overtemperature shutdown
by thermostat
260 ° C 500 °F
