Calculating Melter Power Requirements
A-4
Part 1126931_01
2018 Nordson Corporation
Operating Parameters
B-1
Part 1126931_01
2018 Nordson Corporation
Appendix B
Operating Parameters
Operating parameters are organized in this appendix according to the logical
groups listed in Table B‐1. For information about selecting and editing
operating parameters, refer to Section 3, Installation, Setting Up the Melter.
NOTE: Parameter numbers that are reserved or that are not used do not
appear in this appendix.
Table B-1 Parameter Groups
Group
Parameters Description
Standard 0 to 13 Frequently used parameters
Temperature
Control
20 to 29 Control heater function
Input Setup 30 to 33 Configure the inputs
Output Setup 40 to 42 Configure the outputs
Seven‐day
Clock
50 to 77 Configure the clock feature
PID Selection 80 to 91 Change preset PID settings
Operating Parameters
B-2
Part 1126931_01
2018 Nordson Corporation
Standard
0 Enter Password
Description:
A user‐defined password that prevents unauthorized changes to set‐point
temperatures and operating parameters.
Value:
0 to 9999
Resolution:
1
Default Value:
4000
Format:
—
Use:
This parameter only appears if a password is created using parameter 11 and
then enabled using parameter 10.
NOTE: The melter remains in the password‐protected mode for two minutes
after the last key press. After exiting the setup mode, attempting to re‐enter the
setup mode, even before two minutes has elapsed, will require you to re‐enter
the password.
1 Total Hours with Heaters On (Noneditable)
Description:
A non editable value that indicates the total number of hours that the heaters
have been on.
Value:
9999 (control panel) and 999,999 on the web browser
Resolution:
1 hour
Default Value:
0
Format:
—
Use:
The display registers up to 9999 hours and then rolls over to 0000.
2 Fault Log (Noneditable)
Description:
Stores a record of the last ten faults.
Value:
—
Resolution:
—
Default Value:
_‐F0 (unused log entry)
Format:
F1, F2, F3, and F4
Use:
Use the right‐display scroll keys to review the log entries for the last ten faults.
Empty log entries are indicated by “_‐F0.” Refer to Monitor the Melter in Section
4, Operation.
