Operating Parameters
B-7
Part 1126931_01
2018 Nordson Corporation
26
Manual Standby Time
Description:
The amount of time that the melter will remain in the standby mode after the
standby key is pressed.
Value:
0 to 180 minutes
Resolution:
1 minute
Default Value:
0
Format:
—
Use:
Set the standby time when you want the operator to be able to place the melter
into the standby mode for a limited period of time (break, lunch, etc.). When
manual standby is enabled (value greater than 0 minutes), the standby LED
blinks.
Set the standby delta (parameter 23) to the desired value before setting
parameter 26.
Note: When a time value equal to or greater than 1 minute is entered, the
standby LED will flash to indicate that the manual standby timer is counting
down.
27
Hose Standby Delta
Description:
The number of degrees by which all heated hoses will be decreased when
the applicator is placed into the standby mode.
Value:
1 C to 190 C (1 F to 350 F)
Resolution:
1 C
1 F
Default Value:
0
Format:
—
Use:
This parameter functions like parameter 23 except when it is set to 0, in
which case it reverts to the setting for parameter 23.
NOTE: The standby delta does not affect the under temperature delta
(parameter 22).
28
Applicator Standby Delta
Description:
The number of degrees by which all heated guns will be decreased when
the applicator is placed into the standby mode.
Value:
1 C to 190 C (1 F to 350 F)
Resolution:
1 C
1 F
Default Value:
0
Format:
—
Use:
This parameter functions like parameter 23 except when it is set to 0, in
which case it reverts to the setting for parameter 23.
NOTE: The standby delta does not affect the under temperature delta
(parameter 22).
Operating Parameters
B-8
Part 1126931_01
2018 Nordson Corporation
Standard (contd)
29
Internal Zone Temperature Offset
Description:
The difference in the number of degrees by which the melter's internal
zones will operate. If this parameter is used, the primary internal zone will
operate at a lower temperature than the secondary internal zone as
determined by the value of this parameter.
Value:
0 C to ‐15 C (0 F to ‐30 F)
Resolution:
1 C
1 F
Default Value:
0
Format:
—
Use:
Melter internal zones are designated as follows:
DuraBlue D10/D16: primary=tank; secondary=pump
DuraBlue D4L/D10L/D16L: primary=tank; secondary=pump
AltaBlue TT: primary=tank; secondary=pump
DuraBlue 25/50/100: primary=grid; secondary=reservoir
AltaBlue 15/30/50/100: primary=grid; secondary=reservoir
DuraBlue II Melter: primary=grid; secondary=reservoir
DuraDrum: primary=platen; secondary=pump
Operating Parameters
B-9
Part 1126931_01
2018 Nordson Corporation
Input Setup
30
Input 1
Description:
Control options that determine the function of input 1.
Value:
0 - Input Disabled
1 – Standby On/Off
2 – Heaters On/Off
3 – Motor 1 Enable/Disable
4 – Hose/Applicator 1 Enable/Disable
5 – Hose/Applicator 2 Enable/Disable
6 – Hose/Applicator 3 Enable/Disable
7 – Hose/Applicator 4 Enable/Disable
8 – Hose/Applicator 5 Enable/Disable
9 – Hose/Applicator 6 Enable/Disable
10 – Automatic standby
11 - Motor 2 Enable/Disable
Resolution:
1
Default Value:
10
Format:
Use:
If Motor Enable/Disable (3) is selected, the motor will turn on whenever voltage
is present on the input contacts. To require that the pump key be pressed (pump
enabled) and that there be voltage on the input contacts before the motor can
turn on, set the value of parameter 8, Automatic Pump On to 0 (disabled).
Refer to Installing Melter Inputs in Section 3, Installation, for information about
setting up inputs.
NOTE: Only Input 1 offers control option 10.
Multiple inputs can be set to the same input value. After one or more inputs that
have the same input value are energized, the input functionality will not be
considered inactive (off) until all of the inputs with the same input value are
de‐energized (Multiple inputs set to the same input value are logical ORed.).
