Installation 3-29 Part 1126931_01 2018 Nordson Corporation Table 3‐6 Input/Output Data (contd) Item Description Operating Parameter Control Options Terminals Notes 6 Standard output 2 41 Same as parameter 40 (Default=3…
Installation
3-28
Part 1126931_01
2018 Nordson Corporation
Set Up Inputs/Outputs (contd)
Item Description
Operating
Parameter
Control Options Terminals Notes
2 Standard input 2 31 0 - Input Disabled
1 - Standby On/Off (Default)
2 - Heaters On/Off
3 - Motor 1 Enable/Disable
4 - Hose/Applicator 1
Enable/Disable
5 - Hose/Applicator 2
Enable/Disable
6 - Hose/Applicator 3
Enable/Disable
7 - Hose/Applicator 4
Enable/Disable
8 - Hose/Applicator 5
Enable/Disable
9 - Hose/Applicator 6
Enable/Disable
11 - Motor 2 Enable/Disable
XI:3, XI:4
C
C
3 Standard input 3 32 Same as parameter 31
(Default=2)
XI:5, XI:6
4 Standard input 4 33 Same as parameter 31
(Default=4)
XI:7, XI:8
5 Standard output 1 40 0 - Output Disabled XI:9, XI:10 F
1 - Ready (Default) F
2 - Ready and the Motor is On F
3 - Fault G
4 - Tank Low Level
5 - Service LED is On
6 - Alert H
NOTE A: Parameter 30 has 12 control options. parameters 31, 32, and 33 each have only 11 control options.
B: Parameters 34 through 39 are reserved for the six inputs created when the optional I/O expansion card is installed. The
six optional inputs have the same control options as parameter 31.
C: Parameters are disabled in DuraBlue II adhesive melters. Refer to parameters 9-12 in this table.
D: If control option 10 is selected for input 1, a time must be set in parameter 24.
E: Refer to the instruction sheet provided with the optional I/O expansion card for wiring information.
F: When control option condition occurs, contacts close. Contacts are normally open when power is off.
G: When control option condition occurs, contacts open. Contacts are normally open when power is off.
H: Control option 6 provides an output signal when a potential fault is detected. If control option 3 and 6 are both used, then
both a fault output and an alert output signal will be present when the fault LED turns on.
I: For wiring information, refer to the instruction sheet that is provided with the optional I/O expansion card
Continued...
Installation
3-29
Part 1126931_01
2018 Nordson Corporation
Table 3‐6 Input/Output Data (contd)
Item Description
Operating
Parameter
Control Options Terminals Notes
6 Standard output 2 41 Same as parameter 40
(Default=3)
XI:11, XI:12
7 Standard output 3 42 Same as parameter 40
(Default=4)
XI:13, XI:14
8 Key‐to‐line
0-10V input
— XI:15 (+),
XI:16 (-)
Refer to Setting
Up Gear‐to‐Line
Operation
9 Motor 1
remote start
— XI:17, XI:18 Connect a
momentary,
normally open
contact to the
terminals.
10 Motor 1
remote stop
— XI:19, XI:20 Connect a
momentary,
normally open
contact to the
terminals.
11 Motor 2
remote start
— XI:21, XI:22 Connect a
momentary,
normally open
contact to the
terminals.
12 Motor 2
remote stop
— XI:23, XI:24 Connect a
momentary,
normally open
contact to the
terminals.
Continued...
Installation
3-30
Part 1126931_01
2018 Nordson Corporation
Set Up Inputs/Outputs (contd)
Table 3‐6 Input/Output Data
(contd)
Item Description
Operating
Parameter
Control Options Terminals Notes
13 Motor 3
remote start
(See Note J)
— XI:29, XI:30 Connect a
momentary,
normally open
contact to the
terminals.
14 Motor 3
remote stop
(See Note J)
— XI:31, XI:32 Connect a
momentary,
normally open
contact to the
terminals.
15 Motor 4
remote start
(See Note J)
— XI:33, XI:34 Connect a
momentary,
normally open
contact to the
terminals.
16 Motor 4
remote stop
(See Note J)
— XI:35, XI:36 Connect a
momentary,
normally open
contact to the
terminals.
17 Motor drive 1
running (optional)
— XI:25, XI:26 Refer to Setting
Up Motor Run
Status Monitoring.
18 Motor drive 2
running (optional)
— XI:27, XI:28
19 Motor drive 3
running (optional)
(See Note J)
— XI:37, XI:38 Refer to Setting
Up Motor Run
Status Monitoring.
20 Motor drive 4
running (optional)
(See Note J)
— XI:39, XI:40
J: Motors 3 and 4 are present only on three/four pump or 100L melters.
