10.2 Applicable machines (units) and software upgrades
10.2 Applicable machines (units) and software upgrades
Machines (units) compatible with SL feeders: SIGMA-G5, SIGMA-F8, SIGMA-
G5S
In order to use SL feeders with the above compatible machines, the machine unit
itself must be modied, and the machine unit's software and the NT software must
be upgraded.
Special specications for modied machine units
In order to use the SL feeders, the unit (F8/G5S: cutter guide) and cart (G5: cutter
guide, F8/G5S: feeder cover) require special design modications.
Table J2
No.
Applicable
machine
Unit
Special-order
number
Remarks
1 SIGMA-G5 Cart GS-S198-01 Improved maintainability
2
SIGMA-F8
Unit retrot GS-S199-05
3 Cart GS-S199-06
4
SIGMA-G5S
Unit retrot GS-S199-01
Units shipped before
April 2014
5
Unit (tray)
retrot
GS-S199-02
Units shipped before
April 2014
6 Cart GS-S199-03
7 Cart (tray) GS-S199-04
