4.2.7 Continuous Feeding Operation
This operation repeats the minimum pitch feeding continuously.
Procedure
(1) Press the button to select the lane.
(2) Press the
button, and while holding it down, press the button.
While both the
button and button are being pressed at the same time,
the continuous feed is performed.
(3) Release your nger from either of the two buttons.
At that time, the minimum feed pitch operation is ended.
Note
In the case of slack cover tape, when the button is pressed (cover
tape tension detection sensor OFF), the cover tape take-up operation is
preceded.
4.2.8 Loading Operation
This operation is used to execute the tape automatic loading operation.
Set the end of the tape to be loaded, to the specied position and perform the
following operations.
Procedure
(1) Press the button to select the lane.
(2) Keep pressing the
button for one second.
When it is detected that the button has been held down for 1 second, the
loading operation starts.
The tape is taken in the feeder automatically and tape setup is completed.
The automatic tape setup work shortens the time it would have taken to do it
manually.
Note
Startup Conditions:
The tape detection sensor (2) has been turned ON.
The tape has not been setup.
1504-001
4.2 Operation of Operation Panel
OM-1833
4-7
4.2.9 Unloading Operation
This unloading operation retrieves the loaded tape for collection.
Pull the loading suppressor to this side on the lane where the tape is to be
unloaded, to release the stopper.
Procedure
(1) Press the button to select the lane.
(2) Press the
button, and while holding it down, press the button.
Note
Startup Conditions:
The tape detection sensor has been turned ON and the tape has been setup,
or the tape detection sensor has been turned OFF and the tape has been
setup.
The tape is retrieved and when the tape end is released from sprocket (1) and
sprocket (2), pull out the tape to this side by hand.
Note
Sufcient reverse rotation time of the tape feeding motor (servo-motor) has
been secured to enable the tape collection.
Pressing any operation switch button can forcibly end the unloading
operation after the tape has been collected.
While the teeth of sprocket (1) and sprocket (2) are engaged with the
perforations on the tape, do not pull the tape forcibly.
Doing so might deform the perforations and the tape cannot be setup in the
correct feeding position when the tape is attached again.
1504-001
4.2 Operation of Operation Panel
OM-1833
4-8
4.2.10 Forcible Feeding Operation
This function feeds forward the loaded tape forcibly.
In the condition that the tape end is in the feeder, with an empty pocket zone at the
tape end section, the tape is fed forward forcibly at high-speed.
Procedure
(1) Press the button to select the lane.
(2) Press the
button and while holding it down, press the button within 2
seconds. Hold down both buttons simultaneously for one second.
Note
(a) Startup Conditions:
The tape detection sensor (1) has been turned OFF.
The tape has not setup and the tape end detection is in the latch
condition.
What is the tape end detection (latch)?
The tape detection sensor (1) has been turned OFF when the tape
feeding operation is performed.
In the case that the conditions where that tape has not been setup,
continue (Even when the total feeding amount reaches 20mm, the
tape has not been setup during such time) the tape end detection (latch
memory) is turned ON, assuming that the tape end section has been
inserted into the feeder.
•
This memory is cleared in any of the following cases.
The forcible feeding operation is ended normally.
•
The remaining tape has been removed and both tape detection
sensors (1) and (2) do not detect any tape.
(b) During the operation, pressing any operation switch button stops the
forcible feeding operation.
4.2.11 Tape Feeding Deceleration Setup Clear
When the tape feeder speed deceleration has been set on the component library
data, the corresponding lane dot display
ashes, which disables the feeder
pitch setup operation.
In order to return to the normal condition, clearing the feeding acceleration setting
is required.
Procedure
(1) Press the button to select the lane.
(2) Press and hold the
button and within 2 seconds, press the button.
Hold both buttons simultaneously for two seconds.
After it has been conrmed that the button has been held down for 2 seconds,
the ashing dot display
changes to a continuously illuminating display,
which enables the feeding pitch setup operation.
