5.4 Maintenance Spots 5.4.1 Description of Maintenance in Each Section Here the maintenance cycle for each section of the tape feeder. SL-48085 is given as the example in the description of the procedure. This procedure …
5.3 Maintenance Check List
5.3.1 Weekly Maintenance
Table E2
Location to be Maintained
Work Working Tools Check
Name
Reference
Drawing
Suppressor Section Component
Pick-up Unit
Fig. E2 Cleaning Air Gun
Cover Tape
Processing
Section
Fig. E2 Cleaning Air Gun
Suppressor Fig. E3 Cleaning Air Gun
Loading Unit
Loading
Suppressor
Fig. E5 Cleaning Air Gun
Preceding Tape
Travel Guide
Fig. E5 Cleaning Air Gun
5.3.2 Quarterly Maintenance
Table E3
Location to be Maintained
Work Working Tools Check
Name
Reference
Drawing
Suppressor Section Component
Pick-up Unit
Fig. E2 Cleaning Alcohol, Rag or Cotton Swab
Cover Tape
Processing
Section
Fig. E2 Cleaning Alcohol, Rag or Cotton Swab
Suppressor Fig. E3 Cleaning Alcohol, Rag or Cotton Swab
Chute
Fig. E3 Cleaning Alcohol, Rag or Cotton Swab
Cover Tape Take-up
Gear Section
Sprocket (1)
Fig. E8 Cleaning Alcohol, Rag or Cotton Swab
Lubrication
MOLYNOC GREASE AP1, Greasing Jig
Sprocket (2)
Fig. E8 Cleaning Alcohol, Rag or Cotton Swab
Lubrication
MOLYNOC GREASE AP1, Greasing Jig
Loading Unit
Loading
Suppressor
Fig. E5 Cleaning Alcohol, Rag or Cotton Swab
Preceding Tape
Travel Guide
Fig. E5 Cleaning Alcohol, Rag or Cotton Swab
Tape Present/
Adsent Sensor
Fig. E7 Cleaning Air Gun
Sprocket (3)
Fig. E6 Cleaning Alcohol, Rag or Cotton Swab
Lubrication
MOLYNOC GREASE AP1, Greasing Jig
Flat End Fig. E7 Cleaning
MOLYNOC GREASE AP1, Greasing Jig
Suppressor Section Pick-up
Position
Fig. E4 Adjustment Feeder Adjusting Jig JG-0209
(Purchase separately)
1504-001
5.3 Maintenance Check List
OM-1833
5-4
5.4 Maintenance Spots
5.4.1 Description of Maintenance in Each Section
Here the maintenance cycle for each section of the tape feeder.
SL-48085 is given as the example in the description of the procedure.
This procedure applies to almost all the tape feeders, except for those with special
descriptions.
How to Locate the Check, Cleaning, Lubrication and Adjustment Spots
Cover Tape Processing Section
Every Week Cleaning :
Remove debris and dust using the air gun.
[1]
[2] [3]
Remove any attachment using a rag
soaked in alcohol or cotton applicator.
Every Three Months Cleaning :
Component Pick-up Section
Every Week Cleaning :
Remove debris and dust using the air gun.
Remove any attachment using a rag
soaked in alcohol or cotton applicator.
Every Three Months Cleaning :
Fig. E1
[1]
: Maintenance Spot
[2]
: Maintenance Cycle and Contents
[3]
: Details of Maintenance
1504-001
5.4 Maintenance Spots
OM-1833
5-5
5.4.2 Suppressor Section
Cover Tape Processing Section
Every Week Cleaning :
Remove debris and dust using the air gun.
Remove any attachment using a rag
soaked in alcohol or cotton applicator.
Every Three Months Cleaning :
Component Pick-up Section
Every Week Cleaning :
Remove debris and dust using the air gun.
Remove any attachment using a rag
soaked in alcohol or cotton applicator.
Every Three Months Cleaning :
Fig. E2
Chute (located under the Suppressor)
Every Three Months Cleaning :
Remove any attachment using a rag
soaked in alcohol or cotton applicator.
Suppressor
Every Week Cleaning :
Remove debris and dust using the air gun.
Remove any attachment using a rag
soaked in alcohol or cotton applicator.
Every Three Months Cleaning :
Fig. E3
1504-001
5.4 Maintenance Spots
OM-1833
5-6
