12-Segm.Collect+Place head DLM1
Page 24 / 26 23.11.2021
Pos. Item no. Description Part marking
141 00320057S01 O-RING 3X1,2 NBR 70 B WEAR PART
142 00301001-01 PARALLEL PIN
143 00349432S01 VALVE DRIVE, REJECT SECTION Spare Part
144 00319455-05 MOTOR MOUNT
145 00201348-01 DIN 84-M1,6 X 4-A2
146 00845005-01 SOCKET HEX SCREW M2X10 DIN
912 8.8
147 00619841-01 PARALLEL PIN 3M5 X 8-ST
148 00319825-02 ACTUATING DRIVE
149 00349433S01 VALVE DRIVE, PLACEMENT SECTION Spare Part
150 00201462-01 DIN912-M3 X 10-A2-70
154 00319827S02 DISTRIBUTOR PIECE SPARE PART
159 00201179S01 O-RING 8*1 NBR 70B WEAR PART
160 00322506S01 CABLE HOLDER, SINGLE-SIDED SPARE PART
161 00095300S01 COUNTERSUNK SCREW M2*5
DIN965
162 00322507S01 CABLE HOLDER, DOUBLE-SIDED SPARE PART
163 00095300S01 COUNTERSUNK SCREW M2*5
DIN965
164 00337990-01 DIN912-M4 X 16-A2-70
165 00330648S08 INTERMEDIATE DISTRIBUTOR
SP6/12 DIGITAL
SPARE PART
166 00845013-01 HEXAGON SOCKET HEAD CAP
SCREW M3 X 6-8.8
167 00308541-01 SPACER BOLT, TYPE B I/A-M3X15-A2 STANDARD PARTS
168 00335990S06 DIGITALER ROTAY ENCODER C+P12
/ DLM
SPARE PART
169 00308108-01 DIN912-M2,5 X 8-A2-70
170 00334724-01 DISTANCE BOLT
171 00322562-01 DIN912-M2,5 X 4-A2-70
172 00341181S03 12-SEGM. STAR COMPL. DLM1-2 SPARE PART
174 00303338-01 DIN 6325 - 1,5M5 X 5-ST
175 00368211S02 DISTRIBUTOR DISK PAS-LX-12 ASSY SPARE PART
176 00320023S01 O-RING 2.5X1 NBR 70 B WEAR PART
177 03000896S01 AIR SUPPLY SPARE PART
178 00201348-01 DIN 84-M1,6 X 4-A2
180 00319774S05 VALVE F. SP-12 SPARE PART
12-Segm.Collect+Place head DLM1
Page 25 / 26 23.11.2021
Pos. Item no. Description Part marking
182 00351498-03 VALVE PLUNGER COMPLETE SP12
(PLASTIC)
WEAR PART
183 00351497-04 VALVE LIFTER SP-12
185 00345127-01 O-RING 3*1 VMQ 70 SHORE A RED
187 00319748S04 12ER-SEGMENT CPL. DLM2 SPARE PART
188 00322912-01 DIN912-M2 X 8-A2-70
189 00304316-01 DIN912-M2 X 3-A2-70
190 00341183S01 CONNECTION HOSE, DLM1 SPARE PART
192 00303193-01 DIN912-M3 X 8-A2-70
193 00336791S04 COMPONENTS CAMERA 24X24 Spare Part
194 00325049S01 PROTECTION COVER SPARE PART
195 00332915S01 CABLEHOLDER SPARE PART
196 00313069-01 DIN912-M4 X 10-A2-70
197 00350588S04 12ER- SLEEVE WITH BALL FIXING
COMP.
SPARE PART
199 00322602-06 NOZZLE TYPE 704/904/3004 CPL. /
CERAMIC
WEAR PART
200 00336427S01 ANTI-GLARE SHIELD FRONT
PANEL/DLM1
SPARE PART
201 00845001-01 HEXAGON SOCKET HEAD CAP
SCREW M2 X 4-A2
202 00336426S01 SHEET METAL COVER F. REAR PART
DLM1/12
SPARE PART
203 00845001-01 HEXAGON SOCKET HEAD CAP
SCREW M2 X 4-A2
00345365S03 ACCESSORIES /DLM1_S23 SPARE PART
205 00354836-01 BAG ADAPTER PLATE
206 00350975-01 EXTENSION VACUUM SLEEVE
CIRCLE S23
207 00351031-01 EXTENSION VACUUM SLEEVE
PLACEMENT CIRCLE S23
208 00351032-01 EXTENSION TUBE DETECTOR
PLACEMENT CIRCLE S23
209 00363164-01 RUBBER BONDED METAL BUFFER
(REWORK)
SPARE PART
210 00095105-01 HEXAGON SOCKET HEAD CAP
SCREW
211 00351063-01 CABLE:COMP.ILLUMI.MODULAR SPARE PART
212 00353198-02 HEAD BOARD COMPLETE S25 SPARE PART
12-Segm.Collect+Place head DLM1
Page 26 / 26 23.11.2021
Pos. Item no. Description Part marking
00344486-01 GANTRY - HEAD DISTRIBUTOR S23
218 00344485-09 PROCESSOR BOARD 80C515C SPARE PART
00344488S03 SM BOARD MODULAR SPARE PART
00344489-02 VISION BOARD MODULAR SPARE PART
213 00321550-03 GANTRY CABLE (CAMERAS) SPARE PART
214 00321553-03 GANTRY CABLE (HEAD AXES) SPARE PART
215 00321554-03 GANTRY CABLE (X-TRACK / CAN-
BUS)
SPARE PART
216 00321555-04 GANTRY CABLE (DP1-AXIS) SPARE PART
217 00321556-03 GANTRY CABLE (STAR / Z-AXES) SPARE PART
00116113S01 SET BALL SLEEVES FOR 12 NOZZLE
REV.-HEAD
SPARE PART
00116114S01 SET BALL SLEEVES FOR 6-NOZZLE
REV. HEAD
SPARE PART
