Ea - 22 ERROR MESSAGES LIST Ea Ea01237 Ea01238 Ea01239 Ea01240 Ea01241 Ea01242 Ea01243 Ea01251 Ea01252 Ea01253 ASCII data analyzing error . The following error occurs. 7:PCB Origin If the detected string do not have any …
Ea -21
ERROR MESSAGES LIST
Ea
Ea01205
Ea01206
Ea01207
Ea01208
/B
Ea01208
/A
Ea01209
Ea01210
Ea01211
Ea01212
WARNING:UFOS FLOPPY IN THE DRIVE IS NOT FAM-
ILY
The floppy in the drive seems to be UFOS type. The floppy
in the drive has unknown machine data. The floppy in
the drive is not a one made by this machine.
ERROR: This command is available during vios-mode.
Illegal machine selection:
Undefined machine can not be selected in VIOS mode.
A machine not UFOS can not be selected in UFOS mode.
Ready to remake SYSTEM DATA BACKUP DISK.
Please insert
SYSTEM DATA BACKUP DISK for MOUNTER
and hit [ENTER].
Ready to remake SYSTEM DATA BACKUP DISK.
Please insert
SYSTEM DATA BACKUP DISK for YVOS
and hit [ENTER].
Failed to complete to update SYSTEM DATA BACKUP
DISK.
You can not switch machine. The machine is decided by
PCB data disk in the floppy drive. To switch machine,
take out the PCB data disk from the floppy drive and se-
lect
[ A1 SEARCH DRIVE ] first.
ASCII DATA Pick Up error.
ERROR CODE1 : 2
Detail :1:Comp.Info.
2:Mark Info.
3:PCB Info.
0:Others. Refer to ERROR CODE2.
ERROR CODE2 : 5
Detail : 0:LocalBadMrk Info.
1:Pre Disp. Info.
2:Dot Disp. Info.
5:Local Fidu.Info.
6:Mount Info.
7:PCB Origin
8:Blk Repeat Info.
9:PCB Size
10:PCB Fiducial
11:BLOCK Fiducial
12:PCB Badmark
13:BLOCK Badmark
ASCII->VIOS Conversion error.
ERROR CODE1 : 3
Detail : 1:Comp.Info.
2:Mark Info.
3:PCB Info.
0:Others. Refer to ERROR CODE2.
ERROR CODE2 : 10
Detail : 0:LocalBadMrk Info.
1:Pre Disp. Info.
2:Dot Disp. Info.
5:Local Fidu.Info.
6:Mount Info.
7:PCB Origin
8:Blk Repeat Info.
9:PCB Size
10:PCB Fiducial
11:BLOCK Fiducial
12:PCB Badmark
13:BLOCK Badmark
(meaning) A UFOS floppy which has not been registered on the
YVOS2 has been detected in the floppy disk drive.
(cause)Same as above.
(remedy)In the PCB data control mode, shift to the UFOS data
directory and then create the PCB data disk.
(meaning)A command which can only be used in the VIOS mode
was used in the UFOS mode.
(cause)The screen does not match the operation.
(remedy) Eject the floppy disk from the drive and select the VIOS
mode. Then execute the command in the VIOS mode.
(meaning)The wrong machine number was selected
(cause) An attempt was made to select a VIOS machine in the
UFOS mode, or an attempt was made to use a machine which has
not been registered as a VIOS or UFOS machine.
(remedy) When selecting a UFOS machine, first eject the floppy
disk from the drive and shift to the UFOS mode. Then select the
machine.
(meaning)This notifies the user to insert the data disk contained on
the installation disk in the disk drive in order to back up system
data.
(cause) None
(remedy) Insert the specified floppy disk in the disk drive.
(meaning)System data could not be backed up.
(cause)There may be a problem with the disk.
(remedy)Contact the manufacturer for instructions.
(meaning)It cannot switch machine.
(cause)The machine decided by PCB disk in the floppy drive.
(remedy)Take out the PCB data disk from the floppy drive and se-
lect [ A1 SEARCH DRIVE ] first.
(meaning)It cannot find out the convert lines.
(cause)There is nothing inside the CAD data that inputed string of
search item.
(remedy)Look "Serch" over again.
(meaning)It cannot convert the data from CAD to VIOS.
(cause)There is no character inside the CAD data.
(remedy)Look "Data get" over again.
Ea01221
Ea01222
Ea01223
Ea01230
Ea01231
Ea01232
Ea01233
Ea01234
Ea01235
Ea01236
ASCII data analyzing error. The following error occurs.
1:Comp.Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
2:Mark Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
3:PCB Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
0:LocalBadMrk Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
1:Pre Disp.Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
2:Dot Disp.Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
3:Unknown
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
4:Unknown
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
5:Local Fidu.Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
6:Mount Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
(Meaning)During ASCII’VIOS conversion, a string picked up follow-
ing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
Ea -22
ERROR MESSAGES LIST
Ea
Ea01237
Ea01238
Ea01239
Ea01240
Ea01241
Ea01242
Ea01243
Ea01251
Ea01252
Ea01253
ASCII data analyzing error. The following error occurs.
7:PCB Origin
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
8:Blk Repeat Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
9:PCB Size
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
10:PCB Fiducial
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
11:BLOCK Fiducial
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
12:PCB Badmark
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII data analyzing error. The following error occurs.
13:BLOCK Badmark
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
1:Comp.Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
2:Mark Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
3:PCB Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
(Meaning)During ASCII’VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
Ea01260
Ea01261
Ea01262
Ea01263
Ea01264
Ea01265
Ea01266
Ea01267
Ea01268
Ea01269
ASCII->VIOS Conversion error. The following error oc-
curs.
0:LocalBadMrk Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
1:Pre Disp.Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
2:Dot Disp.Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
3:Unknown
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
4:Unknown
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
5:Local Fidu.Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
6:Mount Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
7:PCB Origin
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
8:Blk Repeat Info.
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
9:PCB Size
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
(Meaning)During ASCII’VIOS conversion, a string picked up follow-
ing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not con-
tains any other character. Or no data line suit to the search condi-
tions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
Ea -23
ERROR MESSAGES LIST
Ea
Ea01270
Ea01271
Ea01272
Ea01273
Ea01400
Ea01401
Ea01402
Ea01403
Ea01404
Ea01406
Ea01407
ASCII->VIOS Conversion error. The following error oc-
curs.
10:PCB Fiducial
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
11:BLOCK Fiducial
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
12:PCB Badmark
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
ASCII->VIOS Conversion error. The following error oc-
curs.
13:BLOCK Badmark
If the detected string do not have any characters, this
error happens.
If any data do not fit with search keyword, also this error
happens.
Specified machine number has a machine data and some
status files.
NUMBER: 1
NAME: SM112_NO1
TYPE: VIOS
Press [ENTER] key to setup them again.
Press [ESC] key to use them.
To create machine needs the backup disk made on the
machine. Please insert it to floppy drive. And then press
[ENTER] key.
NUMBER: 1
NAME: SM112_NO1
TYPE: VIOS
This procedure will copy some files from the backup disk
to hard disk. Press [ESC] key to abort.
Please wait a moment.
Machine data and some status files are being copied to
hard disk.
FILE CHECK ERROR
There aren't enough files on the backup disk. One of these
is displayed down. Press any key to abort.
FILE COPY ERROR
The files cannot be copied from the backup disk to hard
disk. One of these is displayed down.
Press any key to abort.
NOT READY ERROR
There is a machine information which isn't completed. If
you abort, this system deletes such machine. Press [EN-
TER] key to return command menu. To continue editing,
press [ESC] key. To complete the creation of machine,
please press [F8] key to load machine files.
DELETE MACHINE
NUMBER:
NAME:
TYPE:
Press the [ENTER] key to delete.
Press the [ESC] key to abort.
This command deletes all PCB data in the selected ma-
chine.
(Meaning)During ASCII’VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font is
not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(Meaning)During ASCII→VIOS conversion, a string picked up fol-
lowing to the conversion font, is completely SPACE and do not
contains any other character. Or no data line suit to the search
conditions indicated in the conversion font.
(Cause)qIllegal source file for the conversion.wConversion font
is not for the source file.
(Remedy)qCorrect source file, or conversion font file.
(meaning)A machine information file already exists for the machine
number being registered.
(cause)None
(remedy)To register the machine again, press the Enter key. To
use data which has already been registered without changing any-
thing, simply press the ESC key.
(meaning)This is a message indicating that a machine is being reg-
istered for the first time.
(cause)None
(remedy)Insert the backup disk created for the registered machine
in the disk drive and press the Enter key.
(meaning) Machine is currently being registered. This does not in-
dicate an error.
(cause) None
(remedy) Please wait.
(meaning)An error occurred when registering a machine.
(cause)The floppy disk used for the registration does not contain
enough of the necessary machine information files.
(remedy)Update the system data backup disk for that machine and
then try the registration again, using that disk.
(meaning)An error occurred when registering a machine.
(cause) The machine information files may have been destroyed.
(remedy) Update the system data backup disk for that machine
and then try the registration again, using that disk.
(meaning)There is a machine for which registration has not yet been
completed.
(cause)There is a machine for which the F8 key has not been
pressed on the machine registration screen to complete the regis-
tration.
(remedy)To register the machine, press the F8 key on the machine
registration screen and follow the displayed instructions to com-
plete the registration. Pressing the ESC key deletes the machine
without completing the registration.
(meaning) This cancels a machine registration. This is not an error.
(cause) None
(remedy) To abort the cancellation, press [ENTER]. To continue,
press [ESC].
Ea01408
Ea01409
Ea01411
Ea01412
Ea01413
Ea01414
Ea01418
Ea01470
Ea01471
Ea01472
Ea01500
Ea01501
Ea01502
Ea01503
Ea01504
Ea01505
DELETE LINE
NUMBER: 2
NAME: SM112&YVL80
Press [ENTER] key to delete. Press [ESC] key to abort.
Failed to read local badmark data from floppy disk. Please
check this.
(1)Inserted floppy disk.
(2) No available data in floppy disk.
You cannot select this mode, because no machine has
been registerd to YVOS2. It is necessary to register ma-
chine to YVOS2 in
[3/MAINTE/M]-[3/LINE_CONFIG]-[B1 SET MACHINE
INF.].
Fixed component not used.
This fixed component not used.
Now machine has been registered.
You check the Serial No. and M.type in
[3/MAINTE/M]-[1/OPTION CONFIG.].
If machine is HYPER type,
FILE COPY ERROR
There is no line recorded serial number. Your machine
may be old version. press any key to abort.
Ready to calibrate the PCB on digitizer.
Teach 2 position parallel to X axis, which Y coordinate of
2 position is same.
Teach 2 position parallel to X axis, which Y coordinate of
2 position is same.
Please teach 2nd position(P2).
CALIBARATION ERROR
Illegal XY data for calibration.
Please try calibration again.
FILETABLE READ ERROR
A file table cannot be read from a machine.
To read the file table, operation mode must be in
RUNNNING mode.
COMMUNICATION ERROR
Error cause may be one of the followings:
*Time out when sending
*Framing error
*Parity error
*Received data overrun
In case YVOS with digitizer on WINDOWS, COM1 and
COM2 are not available
CANSEL CODE RECIEVED
Cancel code (0x03) is received from machine.
PCBFILE OPEN ERROR
Pcb data file cannot be open for communication. Or sys-
tem cannot make temporary file for communication.
ABORT COMMUNICATION
Communication stopped due to the input of [ESC] key.
To send/receive PRODUCTION HISTORY, PCB data
should be already defined at receiving side.
ERROR CODE RECIEVED
Error code or illegal code was received from machine.
(meaning)The registered line is being deleted. This is not an error
message.
(cause)None
(remedy)To delete the line, press the Enter key. To cancel the op-
eration without deleting the machine, press the ESC key.
Please check floppy disk is already inserted or not. If floppy disk is
inserted normally, data format may be wrong. Check the data in
floppy disk
[Please register machine to YVOS2 in
[3/MAINTE/M]-[3/LINE_CONFIG]-[B1 SET MACHINE INF.].
Check the "Serial No." and "M.type" in
[3/MAINTE/M]-[1/OPTION CONFIG.].
If the machine is HYPER type, check the setting of
[1/OPTION CONFIG.].
(meaning)An error occurred when registering a machine.
(cause)The machine may be old version.
(remedy)Update the system data backup disk for that machine and
then try the registration again, using that disk.
(meaning) This calibrates in the X direction. This is not an error.
(cause) None
(remedy) Place digitizer cursor on PCB home position, and turn on
digitizer switch or press [F10] on keyboard.
(meaning) This enters second calibration point. This is not an error.
(cause) None
(remedy) Place digitizer cursor on PCB home position, and turn on
digitizer switch or press [F10] on keyboard.
(meaning) Calibration error
(cause) For calibration points (x1, y1) and (x2, y2), x1 >= x2
(remedy) Redo calibration.
(meaning) An error occurred when receiving the file table.
(cause) The machine is not in the automatic operation mode, or the
communications circuit was disturbed by noise or another problem
during reception of the file table.
(remedy) Change the machine to the automatic mode, or check the
communications circuit.
(meaning) Error occurred in RS232C communication.
(cause) Transmission time may have been exceeded, parity error
may have occurred, or overrun error may have occurred in data
being received.
(remedy) Machine and YVOS2 communication parameter settings
are not the same. Also check communication circuit connections.
(meaning)A cancel code was received from the machine.
(cause)During communication of an operation being carried out on
the machine, a code was received by the YVOS2 which interrupted
the communication.
(remedy)Execute the command again.
(meaning)The data file to be used in the communications could not
be opened.
(cause)The hard disk is full and the data file for the communica-
tions could not be created; or the data file to be transferred, such as
the PCB data file, has been destroyed, so that it was not possible to
create a data file for communications.
(remedy) Check the amount of space available on the hard disk,
and the data to be transferred.
(meaning) Communication was interrupted by use of [ESC] key.
(cause) [ESC] key was pressed during communication.
(remedy) Do not press [ESC] key during communication.
(meaning) An error code was received from the machine.
(cause) When an attempt was made to execute the communica-
tions command, the machine returned an error code indicating that
the command could not be executed.
(remedy) Follow the error message instructions from the machine
to eliminate the problem.
