Ea - 33 ERROR MESSAGES LIST Ea Ea05031 Ea05032 Ea05033 Ea05034 Ea05035 Ea05036 Ea05037 Ea05038 Ea05040 Ea05041 Ea05042 Ea05043 Ea05044 Ea05045 Ea05046 Ea05080 Ea05081 Ea05082 Ea05083 Ea05084 Ea05085 Ea05086 Ea05087 Ea050…

Ea -32

ERROR MESSAGES LIST

Ea05004

Ea05005

Ea05006

Ea05007

Ea05008

Ea05010

Ea05011

Ea05012

Ea05013

Ea05014

Ea05015

Ea05016

Ea05017

Ea05018

Ea05019

Ea05020

Ea05021

Ea05022

Ea05023

Ea05024

Ea05025

Ea05026

Ea05027

Ea05028

Ea05029

Ea05030

Ea03632

Ea03651

Ea03652

Ea03653

Ea03654

Ea03655

Ea03656

Ea03657

Ea03658

Ea03659

Ea03660

Ea03661

Ea03662

Ea03663

Ea03664

Ea03665

Ea03666

Ea03667

Ea05000

Ea05001

Ea05002

Ea05003

PCB DATA ERROR

The “Pick Height” is too deep for Flip component.

Machine *

Component data *** Name ***

INTERLOCK ERROR

Wafer LXY axes can not move because the hook unit is

down. Check the up-down sensor for the hook unit.

INTERLOCK ERROR

Wafer LXY axes can not move because a pallet is not on

the proper position. Check the pallet position and the pallet

sensor.

INTERLOCK ERROR

Wafer LXY axes can not move because LP axis position

is lower than safe position. Check the position of wafer

LP axis.

INTERLOCK ERROR

Wafer LXY axes can not move because LU axis position

is higher than safe position. Check the position of wafer

LU axis.

INTERLOCK ERROR

Wafer LXY axes can not move because the pallet is not

fixed. Check the fixation and the sensor of the pallet.

INTERLOCK ERROR

Wafer LXY axes can not move because the target posi-

tion interfere with wafer ring. Move down the ejector unit.

INTERLOCK ERROR

Wafer LH axis can not move because the LXY axes are

not on the proper position.

Check the position of wafer LXY axes.

INTERLOCK ERROR

Wafer LZ axis can not move because a pallet is out of the

magazine. Check the pallet position and the sensor.

INTERLOCK ERROR

Wafer LZ axis can not move because the latch is open.

Check the latch sensor.

INTERLOCK ERROR

Wafer LT axis can not perform quick action because the

LP axis position is too low. Check the position of wafer

LP axis.

INTERLOCK ERROR

Wafer LT axis can not move because the LP axis posi-

tion is too low. Check the position of wafer LP axis.

INTERLOCK ERROR

Wafer LT axis can not move because the LS axis posi-

tion is too high. Check the position of wafer LS axis.

INTERLOCK ERROR

Wafer LR axis can not perform quick action because the

LP axis position is too low. Check the position of wafer

LP axis.

INTERLOCK ERROR

Wafer LR axis can not move because the LP axis posi-

tion is too low. Check the position of wafer LP axis.

INTERLOCK ERROR

Wafer LS axis can not move because the LT axis posi-

tion is above the LS axis.

Check the position of wafer LT axis.

INTERLOCK ERROR

Wafer LU axis can not move because the LXY axes are

moving. Check the status of wafer LXY axes.

INTERLOCK ERROR

Wafer LU axis can not move because the ejector unit is

down. Check the ejector unit sensor.

SYNTAX ERROR

A grammar mistake exists in the program.

DATA ERROR

There is a mistake in the input data format.

NUMBER ERROR

There is a mistake in the input number. There is a mis-

take in the value of the expression.

BIT NUMBER ERROR

A bit number is outside the range 1 to 16

PORT NUMBER ERROR

There is a mistake in the input/output port number.

Can not use 'I' and 'O' as the port number.

TABLE NUMBER ERROR

A table number is outside the range 0 to 9.

DIGIT NUMBER ERROR

The digit of a binary numeral has exceeded 16 digits.

The decimal numeral has exceeded 7 digits. The hexa-

decimal numeral has exceeded 4 digits.

ILLEGAL AXIS NAME

There is a mistake in the axis name.

ILLEGAL ORDER

There is a mistake in bit designation to the input/output

port. Change to ascending order starting from right.

OVERFLOW

The value for the "SPEED" command/the parameter set-

ting command is outside the allowable range.

STACK OVERFLOW

A parenthesis was used 6 times or more in succession in

an expression. A stack area for checking grammar/ex-

ecution overflowed.

ILLEGAL VARIABLE

In "SEND" command, a variable other than a global vari-

able was used.

TYPE MISMATCH

Both sides of expression do not match. Numeral/variable/

expression of the type which was not allowed was used.

FOR VARIABLE ERROR

NEXT statement variable terms corresponding to FOR

statement does not match.

WEND WITHOUT WHILE

No WHILE statement corresponding to WEND statement.

WHILE WITHOUT WEND

No WEND statement corresponding to WHILE statement.

NEXT WITHOUT FOR

No FOR statement corresponding to NEXT statement.

"NEXT" command was executed without "FOR" com-

mand.

FOR WITHOUT NEXT

No NEXT statement corresponding to FOR statement.

ENDIF WITHOUT IF

No IF statement corresponding to ENDIF statement.

ELSE WITHOUT IF

No IF statement corresponding to ELSE statement.

IF WITHOUT ENDIF

No ENDIF statement corresponding to IF statement.

ELSE WITHOUT ENDIF

No ENDIF statement corresponding to ELSE statement.

END SUB WITHOUT SUB

No SUB statement corresponding to END SUB statement.

"END SUB" command was executed without "SUB" com-

mand.

SUB WITHOUT END SUB

No END SUB statement corresponding to SUB statement.

DUPLICATED VARIABLE

Two or more array variables of the same name were de-

fined

DUPLICATED IDENTIFIER

Two or more identifiers of the same name were defined.

DUPLICATED LABEL

Two or more the same labels were defined.

UNDEFINED ARRAY

Assignment/reference was done for undefined array.

UNDEFINED IDENTIFIER

An undefined identifier was used.

UNDEFINED LABEL

Reference made to undefined label.

Ea -33

ERROR MESSAGES LIST

Ea05031

Ea05032

Ea05033

Ea05034

Ea05035

Ea05036

Ea05037

Ea05038

Ea05040

Ea05041

Ea05042

Ea05043

Ea05044

Ea05045

Ea05046

Ea05080

Ea05081

Ea05082

Ea05083

Ea05084

Ea05085

Ea05086

Ea05087

Ea05088

Ea05089

Ea05090

Ea05091

Ea05092

Ea05093

Ea05094

Ea05095

Ea05096

Ea05100

Ea05101

Ea05102

Ea05103

Ea05120

Ea05121

Ea05122

Ea05123

Ea05130

Ea05131

Ea05132

Ea05133

Ea05134

Ea05135 \

Ea05136

Ea05137

Ea05138

Ea05140

Ea05141

Ea05142

Ea05150

Ea05151

Ea05152

TOO MANY DIMENSIONS

An array exceeding 3 dimensions was defined.

DIMENSION MISMATCH

The number of array dimensions does not match that de-

fined by the DIM statement.

ARGUMENT MISMATCH

The number of SUB statement arguments does not cor-

respond with the CALL statement.

ILLEGAL IDENTIFIER

A reserved word was used as an identifier.

LLEGAL COMMAND IN PROCEDURE

Execution of command is impossible within procedure

(between SUB-END SUB statements).

ILLEGAL COMMAND OUTSIDE PROCEDURE

Execution of command is impossible outside of proce-

dure (between SUB-END SUB statements).

ILLEGAL COMMAND INSIDE IF

Execution of command is impossible inside of IF state-

ment.

ILLEGAL DIRECT

Independent execution of command is impossible.

TOO MANY IDENTIFIERS

Number of identifiers exceeds 500.

CASE WITHOUT SELECT

No SELECT statement corresponding to CASE state-

ment.

END SELECT WITHOUT SELECT

No SELECT statement corresponding to END SELECT

statement

SELECT WITHOUT END SELECT

No END SELECT statement corresponding to SELECT

statement

CASE WITHOUT END SELECT

No END SELECT statement corresponding to CASE

statement.

ILLEGAL COMMAND LINE

The command statement between SELECT and CASE

statement cannot be executed.

COMMAND DOESN'T EXIST

The line is not a command statement.

ILLEGAL COMMAND

Execution of a nonsupported and nonexecutable com-

mand was attempted.

ILLEGAL FUNCTION CALL

An expression of "ON <expression> GOTO"/"ON <ex-

pression> GOSUB" command was a negative value.

DEVIDE BY 0

Division command by 0(/0) was attempted.

NO POINT

Point does not exist.

COORDINATES TYPE ERROR

Arithmetic operations of joint coordinate point data and

cartesian point data were attempted.

SUBSCRIPT OUT OF RANGE

A subscript of an array variable has exceeded the range

which was defined in DIM statement.

RETURN WITHOUT GOSUB

"RETURN" command was executed without executing

"GOSUB" command.

END SUB WITHOUT CALL

"END SUB" command was executed without executing

"CALL" command.

EXIT SUB WITHOUT CALL

"EXIT SUB" command was executed without executing

"SUB" command.

ILLEGAL COMMAND IN ERROR ROUTINE

Within an error processing routine a command which

could not be executed was attempted.

EXIT FOR WITHOUT FOR

"EXIT FOR" command was executed without executing

"FOR" command.

SUB WITHOUT CALL

"SUB" command was executed without executing

"CALL" command.

NOT EXECUTE CALL

"CALL" command was not executed.

PROGRAM TERMINATED BY HALT

Program execution was completed by "HALT" command.

PROGRAM SUSPENDED BY HOLD

Program execution was interrupted by "HOLD" command.

SOFT LIMIT OVER

Target position exceeds soft limit position.

SEARCH FOR ORIGIN is not performed yet. Select

SEARCH ORIGIN first by using the COMMAND LISTS.

NO PCB DATA

PCB data does not exist.

PCB NOT SELECLED

PCB name is not selected. Please select PCB name by

"PCBNAME" statement.

MACHINE DATA SAVE ERROR

Failed to save HDdata to file.

PCB DATA LOAD ERROR

Failed to LOAD BDdata from file.

NO ENOUGH MEMORY

Cannot execute because of memory insufficiency.

ILLEGAL PROGRAM DATA DURING RUNNING

Illegal program data during running.

ILLEGAL POINT DATA DURING RUNNING

Illegal point data during running.

ILLEGAL OBJECT CODE

An object program has been destroyed.

OBJECT PROGRAM OPEN ERROR

Failed to open object program ***.

OBJECT PROGRAM SAVE ERROR

Failed to save object program ***.

OBJECT PROGRAM LOAD ERROR

Failed to LOAD object program ***.

OBJECT PROGRAM NAME ERROR

Failed to get object program name.

OBJECT PROGRAM VERSION DISAGREEMENT

Object program SpDat[STRing_inf0] version number dis-

agrees with APL-EXE.FILE version number. Please save

the program again.

Program checking up error. A grammar mistake exsits in

the program.

ILLEGAL OBJECT CODE

An object program SpDat[STRing_inf0] has been de-

stroyed. Please save the program again.

OBJECT PROGRAM ERROR

Source program SpDat[STRing_inf0] was updated.

Please save the program again in oder to update object

program.

NO SUCH OBJECT PROGRAM

Please save the program in oder to make object program.

Now writing program. Please wait a moment....

Now reading program. Please wait a moment....

Nom proram checking up. Please wait a moment....

FILE ALREADY OPEN

File was already opened by “FOPEN” command.

FILE NOT OPEN

File was not open by “FOPEN” command.

FILE CLOSE ERROR

Failed to close the file.

TOO MANY DIMENSIONS

An array exceeding 3 dimensions was defined.

Ea -34

ERROR MESSAGES LIST

Ea05153

Ea05154

Ea05160

Ea05161

Ea05162

Ea05163

Ea06004

Ea06005

Ea06006

Ea06007

Ea06010

Ea06011

Ea06012

Ea06014

Ea06015

Ea06016

Ea06020

Ea06021

Ea06022

Ea06023

Ea06025

Ea06026

Ea06029

Ea06030

Ea06031

Ea06032

Ea06033

Ea06034

Ea06035

Ea06036

Ea06037

Ea06038

FILE SAVE ERROR

Failed to save the file.

ILLEGAL COMMAND

Can not execute while a file was opened by “FOPEN”

command.

EMURATOR PROGRAM ERROR

Error occured in emulator program. Please modify emu-

lator program.

NOT ALLOCATE MEMORY

Memoy for robot language program is not allocated.

ROBOT LANGUAGE PROGRAM ALREADY RUNNING

Can not execute while robot language program is runninig.

NOT SET UP EMUTATION

Can not change the input variables,because those are

not set up for emulation.

PROGRAM DESTROYED

POINT DESTROYED

SECOND LIMIT OVER

* MOTOR DRIVER ERROR

CANNOT EXECUTE

RUNNING

REMOTE STOP

FAN STOPPED

TEMP. ALARM

WATCH-DOG

NUMBER ERROR

PORT NUMBER ERROR

TOO MANY CHARACTERS

TOO MANY PARAMETERS

PLEASE WAIT A MOMENT

PLEASE INPUT HEAD Z OFFSET

EMG.STOP ON

CHECK COVER OR AIR OR FEEDER

DO LOCKED

ORIGIN INCOMPLETE

NO STD. COORDINATE

* BAD POSITION

DRIFT CHECK

ARM LOCKED

HEAD LOWER POS. SENSOR OFF!

NOZZLE ST. IS UPPER POSITION!

Ea06039

Ea06060

Ea06061

Ea06063

Ea06064

Ea06065

Ea06066

Ea06067

Ea06068

Ea06069

Ea06070

Ea06071

Ea06072

Ea06073

Ea06074

Ea06075

Ea06076

Ea06077

Ea06078

Ea06079

Ea06080

Ea06081

Ea06082

Ea06083

Ea06090

Ea06091

Ea06095

Ea06098

Ea06099

Ea06101

Ea06102

Ea06105

Ea06107

Ea06108

ORIGIN COMPLETE

PCB INF. DESTROYED

PRODUC. INF. DESTROYED

WARNING: OVERFLOW

TOO MANY PCB

PAUSE !

SELECT DATUM POINT

VISION HEAD MULTI DEFINED

ANC HEAD MULTI DEFINED

NO SUCH PCB

PCB EXISTS

HEAD NUMBER ERROR

PARTS NUMBER ERROR

CANNOT DELETE

UNDEFINED PCB NAME

TOP CHARACTER MUST BE A-Z

INPUT ORIGIN POINT

PLEASE TEACH 2ND POINT

CANNOT DELETE. PLEASE RESET

OPERATION INTERRUPTED

WHILE WITHOUT WEND

WEND WITHOUT WHILE

ILLEGAL FUNCTION CALL

ILLEGAL CHARACTER

NO “DIM” COMMAND

TOO MANY ON COMMANDS

BAD SOFT LIMIT DATA

ARRAY EXISTS

OUT OF RANGE

FORMAT ERROR

DATA ERROR

ILLEGAL CODE

DIGIT NUMBER ERROR

SPEC. DISAGREEMENT
