Ea - 38 ERROR MESSAGES LIST Ea Ea07902 PCB DA T A ERROR There is a pin beyond the PCB Y size. Pin Pos.Row *** Col ***

Ea -37

ERROR MESSAGES LIST

Ea07606

Ea07607

Ea07700

Ea07800

Ea07801

Ea07802

Ea07803

Ea07804

Ea07805

Ea07806

Ea07807

Ea07808

Ea07809

Ea07810

Ea07811

Ea07812

Ea07813

Ea07814

Ea07850

Ea07870

Ea07871

Ea07872

Ea07873

Ea07874

Ea07875

Ea07876

Ea07877

Ea07900

Ea07901

MACHINE DATA ERROR

Specification of camera number is incorrect. Please set

up parameters in [CameraCoordinate] again

Correct specification on SML88Super (tentative name)

is as followings.

MACHINE DATA ERROR

Specification of camera number is incorrect. Please set

up parameters in [CameraCoordinate] again

Correct specification on SM100Twin (tentative name) is

as followings.

VICS HARDWARE ERROR

Please insert the vision board with following part num-

ber.KM5-M441H-020 (Bottom 3 numbers should be after

020.)

SOME COMPONENTS ARE NOT POSSIBLE TO PICK

The OPT-FLAG prevents the machine to pick up next

component.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENTS ARE NOT POSSIBLE TO PICK

The head is already occupied by another component, and

the indicated picking action is not possible.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENTS ARE NOT POSSIBLE TO PICK

A picking up group without rotation-action could not in-

clude a mounting data with some rotation.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENT COULD NOT BE PICKED UP

By picking up this component, depending on the pick up

accuracy, the component could hit the component on

neighbor nozzle.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENT COULD NOT BE PICKED UP

By picking up this component, depending on the pick up

accuracy, the component could hit the neighbor nozzle

with component.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENTS ARE NOT POSSIBLE TO PICK

A picking up group without rotation-action could not in-

clude the FINE type component. Check the data.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENT COULD NOT BE PICKED UP

Because the machine had picked up a component of FINE

type, the machine could not pickup another of FINE type.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENT COULD NOT BE PICKED UP

By picking up this component, depending on the pick up

accuracy, the component could hit the neighbor nozzle

without component.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENT COULD NOT BE PICKED UP

By picking up this component, depending on the pick up

accuracy, the component could hit the neighbor nozzle

without component during the rotating the component.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENT COULD NOT BE PICKED UP

The machine had tryed to pickup components blongs dif-

ferent blocks.

Mount data ***

Component data *** Name ***

Head ***

NO COMPONENT FOR USE

A component is not available at this moment. Please con-

firming the component to be ready, and run again.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENTS ARE NOT POSSIBLE TO PICK

If the head picks up the component, the component might

hit the lighting unit for fiducial mark. Please confirming

the data and run again.

Mount data ***

Component data *** Name ***

Head ***

SOME COMPONENT IS NOT MOUNTED YET

Because of too much mounting data, the searching op-

eration had been terminated by time-out. If this message

appears often, call up your agent.

NO COMPONENT FOR USE

A component is not available at this moment. Please con-

firming the component to be ready, and run again.

Mount data ***

Component data *** Name ***

Head ***

NO COMPONENT FOR USE

A component is not available at this moment. Please con-

firming the component to be ready, and run again.

Mount data ***

Component data *** Name ***

Head ***

ILLEGAL INTERNAL COUNTER

Hit key to re-calculate and continue.

Not Mounted data ***

Components left ***

Left in Blocks ***

It has been stopped resetting. Please try the RESET com-

mand again, and finish it.

CAN NOT EXECUTE COMMAND

Can not execute this command , because RESET is not

finished completely. Please try the RESET command

again, and finish it.

Processing mount data.

Please wait a moment.......

Mount data

Please set PCB.

Now adjusting correction of fiducial. Please wait a mo-

ment.......

Type of fiducial recognition is not selected. Please set

PCB Fiducial to “Use” in the PCB information.

CAN NOT EXECUTE COMMAND

Failed to execute this command, because the push-up

unit’s position is not enough low. Please execute this com-

mand after moving it down again,

Finished to change the active TABLE for Vision or Servo

System.

PROGRAMABLE PUSH PIN FILE READ ERROR.

Please check programable push pin file format.

Machine ***

File NO?\PPUDATA.STS

PCB DATA ERROR

There is a pin beyond the PCB X size.

Pin Pos.Row ***

Col ***

Ea -38

ERROR MESSAGES LIST

Ea07902

PCB DATA ERROR

There is a pin beyond the PCB Y size.

Pin Pos.Row ***

Col ***

Ea -39

ERROR MESSAGES LIST

Ea10000

Ea10001

Ea10002

Ea10003

Ea10004

Ea10005

Ea10006

Ea10007

Ea10008

Ea10009

Ea10100

Ea10101

Ea10102

Ea10103

Ea11000

Ea11001

Ea11002

Z AXIS START TIMEOUT ERROR

Z axis start routine was interrupted by time out error.

X,Y,R AXIS START TIMEOUT ERROR

X,Y and Y axis start routine was interrupted by time out

error.

SY AXIS START TIMEOUT ERROR

SY axis start routine was interrupted by time out error.

AXIS START TIMEOUT ERROR

SOFTLIMIT OVER

INVALID TARGET COORDINATE

INVALID AXIS DATA

PTP TIMEOUT ERROR

PROCESSING PTPCOMMAND.

ENABLE TO RESET

It is enable to reset the machine.

Followings are possible as the reason.

(1) EMERGENCY STOP key is pushed.

(2) "UPPER DOOR" switch is turned to "OPEN".

(3) Origin return has not completed yet.

SY AND SZ SERVO ON

The servo of the SY ans SZ axes have been active.

PREPARATIN FOR OPENING COMPLETED

It is able to open the cover.

UPPER DOOR SWITCH IS STILL "CLOSE".

When "UPPER DOOR" switch is "CLOSE", upper cover

was opened

Please turn "UPPER DOOR" switch to "OPEN” then open

the upper cover.

UPPER DOOR IS STILL OPEN.

When upper door is open, "UPPER COVER" switch be-

come "CLOSE".

Plese turn "UPPER DOOR" switch to "OPEN", then close

the upper cover and trun "UPPER DOOR" switch to

"CLOSE".

FLAP UP INTERLOCK

The axis cannot moves when flap is in upper position.

BACKUP PIN INTERLOCK

The axis cannot moves because backup pin will attach to

the conveyor.

CLEANER UP INTERLOCK

The axis cannot moves when cleaner is in upper posi-

tion.

(E10009 Cause and Solution)This cannot be executed when the

status area in the machine status display reads “Emergency Stop”.

(1) Close the top cover, cancel the Emergency Stop button, and

press the Ready button to resume execution.

(2) Close the top cover and set the “UPPER DOOR” switch to

“CLOSE”. Then execute again.

(3) Press the “Origin Return” button on the “Setup” screen to return

to the home position. Then execute again.

(E10102 Cause and Solution)Always carry out this procedure when

opening the top cover.

(1) With the top cover closed, change the “UPPER DOOR” switch

from “CLOSE” to “OPEN”.

(2) Make sure the status machine display reads “Top Safe” and

then open the top cover.

If the display still reads “B340”, the top cover open/close sensor

may be malfunctioning or defective.

(E11000 Cause and Solution)When the flap is ascending, there

may be mechanical interference, so axis movement is inhibited.

Use the “Flap Front” and “Flap Back” buttons on the “Conveyor”

screen to lower both flaps. Then execute again.

If the error still occurs, there may be a mechanical problem with the

flap operation, or the “Flap Front Operate”, “Flap Front Cancel”,

“Flap Back Operate”, or “Flap Back Cancel” sensor may be mal-

functioning or defective. Check the sensor input status on the “Con-

veyor” screen.

(E11001 Cause and Solution)The “Pin Detect” sensor has detected

a backup pin or other object, so the conveyor width cannot be

changed.

Position the backup pin correctly, or remove the object detected by

the sensor, and try again.

If the error still occurs, the “Pin Detect” sensor may be malfunction-

ing or defective.

Check the sensor input status on the “Conveyor” screen.

(E11002 Cause and Solution)When the cleaner is ascending, there

may be mechanical interference, so axis movement is inhibited.

Use the “Up” button on the “Cleaner” screen to lower the cleaner,

and try again.

If the error still occurs, there may be a mechanical problem with the

vertical movement of the cleaner, or the “Cleaner Up Right”, “Cleaner

Up Left”, “Cleaner Down Right”, or “Cleaner Down Left” sensor may

be malfunctioning or defective. Check the sensor input status on

the “Cleaner” screen.

Ea11003

Ea11004

Ea11005

Ea11006

Ea11007

Ea11008

Ea12000

FAIL TO FIX CLEANER

Output for cleaner fixation is ON but input for it is OFF.

FAIL TO CONNECT CLEANER

Output for cleaner connection is ON but input for it is OFF.

CLEANER FREE INTERLOCK

Cleaner is not fixed and not connected.

MASK CAMERA LIGHT UP INTERLOCK

The axis cannot moves when mask camera light is in

upper position.

CLEANER FIXED AND CONNECTED INTERLOCK

Cleaner is fixed and connected.

CONVEYOR WIDTH INTERLOCK

To keep safty you cannot change conveyor width.

SQUEEGEE UP ERROR

Failed to move squeegee up.

(E11003 Cause and Solution)If the cleaner has not been properly

secured to the base, there may be mechanical interference, so axis

movement is inhibited. Use the Emergency Stop button to turn off

the servo, and then use the “Cancel” button on the “Cleaner” screen

to secure the cleaner properly to the base.

If the message “Cleaner is not stored. Store cleaner?” appears when

operating axes, always presses “OK” to automatically store the

cleaner.

If the error still occurs, there may be a mechanical problem with the

cleaner securing pin, or the “Cleaner Fixing Upper Limit” or “Cleaner

Fixing Lower Limit” sensor may be malfunctioning or defective.

Check the sensor input on the “Cleaner” screen.

(E11004 Cause and Solution)If the cleaner has not been properly

linked to the PCB table, mechanical interference may result, so the

axis cannot move.

Use the Emergency Stop button to turn off the servo, and then use

the “Cancel” and “Link” buttons on the “Cleaner” screen to secure

the cleaner to the base.

If the message “Cleaner is not stored. Store cleaner?” appears when

operating axes, always presses “OK” to automatically store the

cleaner.

If the error still occurs, there may be a mechanical problem with the

cleaner securing pin or coupling pin, or the “Cleaner Coupling Up-

per Limit” or “Cleaner Coupling Lower Limit” sensor may be mal-

functioning or defective.

Check the sensor input on the “Cleaner” screen.

(E11005 Cause and Solution)If the cleaner has not been properly

secured to the base or connected to the PCB table, mechanical

interference may result, so the axis cannot move.

Use the Emergency Stop button to turn off the servo, and then use

the “Cancel” and “Connect” buttons on the “Cleaner” screen to se-

cure the cleaner to the base.

If the message “Cleaner is not stored. Store cleaner?” appears when

operating axes, always presses “OK” to automatically store the

cleaner.

If the error still occurs, there may be a mechanical problem with the

cleaner securing pin or coupling pin, or the “Cleaner Fixing Upper

Limit”, “Cleaner Fixing Lower Limit”, “Cleaner Connect Upper Limit”

or “Cleaner Connect Lower Limit” sensor may be malfunctioning or

defective.

Check the sensor input on the “Cleaner” screen.

(E11006 Cause and Solution)If the mask camera light is in the “Up”

position, mechanical interference may result, so the axis cannot

move.Use the “Mask Camera Light Up” button to lower the mask

camera light, and then try again.

If the error still occurs, there may be a mechanical problem with the

vertical movement of the mask camera light, or the “Mask Camera

Light Upper Limit” or “Mask Camera Light Lower Limit” sensor may

be malfunctioning or defective.

Check the sensor input on the “Mask” screen.

(E11007 Cause and Solution)If the cleaner has been improperly

secured to the base or connected to the PCB table, mechanical

interference may result, so the axis cannot move.

Use the Emergency Stop button to turn off the servo, and then use

the “Cancel” and “Connect” buttons on the “Cleaner” screen to se-

cure the cleaner properly to the base.

If the message “Cleaner is not stored. Store cleaner?” appears when

operating axes, always presses “OK” to automatically store the

cleaner.

If the error still occurs, there may be a mechanical problem with the

cleaner securing pin or connecting pin, or the “Cleaner Fixing Up-

per Limit”, “Cleaner Fixing Lower Limit”, “Cleaner Connect Upper

Limit” or “Cleaner Connect Lower Limit” sensor may be malfunc-

tioning or defective.

Check the sensor input on the “Cleaner” screen.

(E12000 Cause and Solution)There may be a mechanical problem

with the vertical movement of the squeegee, or the “Squeegee Up-

per Limit” sensor may be malfunctioning or defective.

Check the sensor input on the “Squeegee” screen.

YV88Xabcabcabc
