F2-82M (B type) P 3 No. Code No. Parts Name Q'ty Parts No. LG4-M1A30-500 HOLD LEVER ASSY 1 AS -E08-8590-B LG4-M1A30-501 HOLD LEVER ASSY 1 AS2-E08-8590-B 1 K87-M111G-100 PUSH PIN 1 CTF-M08- 325 2 LG4-M1A1K-000 LEVER …
F2-82M (B type)
P 3
No. Code No. Parts Name Q'ty Parts No.
LG4-M1A30-500
HOLD LEVER ASSY
1 AS -E08-8590-B
LG4-M1A30-501
HOLD LEVER ASSY
1 AS2-E08-8590-B
1 K87-M111G-100 PUSH PIN 1
CTF-M08- 325
2 LG4-M1A1K-000 LEVER AXIS PIN 1
FTA-A08-8130-B
3 LG4-M1A1A-001
COVER PLATE
1
FTA-A08-8149-C
4 LG4-M1A3M-000 SCREW COIL SPRING 1
FTA-A08-8191-SCSp
LG4-M1A3A-000
HINGE PIN 1
1
FTA-A08-8191-1
LG4-M1A3A-001
HINGE PIN 1
1
FTA-A08-8191-1C
6 LG4-M1A35-001
CLANK ARM
1 FTA-A08-8192-B
7 LG4-M1A3B-000
HINGE PIN 2
1
FTA-A08-8192-1
8 LG4-M1A36-000
ARM
1
FTA-A08-8193
9 LG4-M1A3L-000
CLANK ARM AXIS PIN
1
FTA-A08-8195
10 LG4-M1A37-010 ADJUST CLAMP PIN 1
FTA-A08-8196
11
LG4-M1A3K-001
CLAMP LEVER AXIS PIN
1 FTA-A08-8197-B
12 LG4-M1A38-000
LINK PIN T
1
FTA-A08-8198
13
LG4-M1A17-500 STOPPER PIN 1 FTA-E08-8513
14
LG4-M1AA2-510
SP.CONNECTOR ASSY
1 FTA-E08-8551-1B
15 LG4-M1AAB-510 SENSOR HARNESS ASSY 1 FTA-E08-8551-3B
16
LG4-M1A1B-500 SENSOR PLATE
1
FTA-E08-8567
17 LG4-M1A1C-500 COVER 1 FTA-E08-8581-B
18
LG4-M1A32-500 HOLD LEVER S 1
FTA-E08-8590-1
19 LG4-M1A31-500 HOLD LEVER M 1
FTA-E08-8590-B
20 LG4-M1A34-500
CLAMP LEVER
1
FTA-E08-8591
21 LG4-M1A33-500
LINK PLATE
1
FTA-E08-8594
22 LG4-M1A39-500
LINK PIN U
1
FTA-E08-8599
23 LG4-M1AHD-530 BOARD ITHB 1
24 LG4-M1ADC-000
SCREW,PAN HEAD+ 2 3MC-7-P
25 K87-M111S-000
SCREW,FLAT HEAD+
2
3MK-6-P
26 K87-M111R-000 SCREW,SET 4
3MY-5-F
27 K87-M111U-000
SCREW FLANGE NUT
2
3MH-FS
28 K87-M21BN-000
SCREW NUT
2
3MH-P
29 K87-M21BM-000
SPRING LOCK WASHER
1
3MU-P
30
LG4-M1ADG-100 SCREW,PAN HEAD+
2
P2MC-4-P
31 K87-M111N-000 SCREW,PAN HEAD+ 4
3MC-3-P
※1…F2-82M-811B～
※1
※1 5
LG4-M2A40-510
