F2-82M (B type) P 4 No. Code No. Parts Name Q'ty Parts No. LG4-M2A40-501 T.G.PLATE ASSY 1 AS-E08-8519-05B LG4-M2A40-510 T.G.PLATE ASSY 1 AS-E08-8519-05C 1 LG4-M3A42-000 SHUTTER PLATE 1 FTA-A08-8120-63 2 LG4-M1A45-00…
LG4-M2A40-510
F2-82M (B type)
P 4
No. Code No. Parts Name Q'ty Parts No.
LG4-M2A40-501 T.G.PLATE ASSY 1 AS-E08-8519-05B
LG4-M2A40-510 T.G.PLATE ASSY 1 AS-E08-8519-05C
1 LG4-M3A42-000 SHUTTER PLATE 1 FTA-A08-8120-63
2 LG4-M1A45-000 SHUTTER GUIDE PIN 2 FTA-A08-8121
3 LG4-M1A44-001 SHUTTER PUSH SPRING 1 FTA-A08-8122-B
4 LG4-M1A4L-000 T.G.GUIDE SCREW 1 FTA-A08-8124
5 LG4-M1A47-000 T.G.GUIDE PIN 1 FTA-A08-8125
LG4-M1A48-001
T.G.PUSH SPRING 1 FTA-A08-8127-50
LG4-M1A48-500
T.G.PUSH SPRING 1 FTA-E08-8527-30
7 LG4-M3A49-000 ADJUST PLATE 1 FTA-A08-8126-63
LG4-M2A41-501 TAPE GUIDE PLATE 1 FTA-E08-8519-05B
LG4-M2A41-510 TAPE GUIDE PLATE 1 FTA-E08-8519-05C
9 LG4-M2A43-500 SHUTTER GUARD PLATE 1 FTA-E08-8523-05
10 LG4-M1A46-500 LOCK LEVER 1 FTA-E08-8527
11 LG4-M1A4K-500 T.G.A. GUIDE PIN 1 FTA-E08-8529
12 K87-M1547-000 SCREW,TRUSS HEAD 2 T2M-2.5-P
13 LG4-M3AD3-000 SPRING LOCK WASHER 2 2MU-P
14
15
16
17
18
19
20
21
22
23
24
25
8
6
