Assembly Instructions 1 Assembly Instructions
SIPLACE X-Series Productivity Shuttle Type I/II 1.4 Abbreviations
1.4 Abbreviations
DC Dual conveyor
ESD Electrostatic sensitive devices
EMC Electromagnetic compatibility
ESD Electrostatic sensitive device
SC Single conveyor
GND Ground
IC Integrated circuit
PCB Printed-circuit board
MC Machine controller
SMD Surface-mounted device
WLAN Wireless local area network
XPL X-Series Productivity Lane
XPS X-Series Productivity Shuttle
1.5 Requirements
Assembly may only be performed by a service technician of Siemens AG. 1
– Station software SW 701 and Line Control SIPLACE Pro 5.1 or SW 605 and Line Control
SIPLACE Pro 5.0
– The fixed walls of the SIPLACE X-Series must be set to outside-outside position.
– The width of the SIPLACE X-Series must be se to 100 mm.
– Installation of the SIPLACE X-Series Productivity Lane
– Mounting of the SIPLACE X-Series Productivity Shuttle
– Setting up the system
1.5.1 Additional Documentation Required
– Operating instructions for the SIPLACE placement system
– Assembly instructions for the SIPLACE placement machine
– Operating instructions for the SIPLACE X-Series Productivity Shuttle
1 Assembly Instructions Assembly Instructions
1.6 Overview of Required Work Steps SIPLACE X-Series Productivity Shuttle Type I/II
4
1.5.2 Required Tools and Supplies
– Socket wrench set, 1/4” with bits, hexagon socket-head, sizes 2.5 mm, 3 mm, and 4 mm
– Open-end wrench, sizes 18 and 24
– Hexagon socket-head wrench set
– Precision spirit level
– Lift truck, if necessary
1.6 Overview of Required Work Steps
1. Removal of the lifting table plates in placement area 2 (BB2) of the SIPLACE X-Series.
2. Removal of the cover over the main distributor of the conveyor control for the SIPLACE X-
Series.
3. Preparation of the cable connection for the limit switch of the transport walls of the XPL.
4. Mounting of the cover over the main distributor of the conveyor control for the SIPLACE X-
Series.
5. Installation of the lifting table plates in placement area 2 (BB2) of the SIPLACE X-Series.
6. Installation of the SIPLACE X-Series Productivity Lane (XPL) in the SIPLACE X-Series.
7. Aligning the XPL.
8. Mounting of the SIPLACE X-Series Productivity Shuttle (XPS) upstream and downstream of
the SIPLACE X-Series.
9. Making the Interface Connections.
5
Assembly Instructions 1 Assembly Instructions
SIPLACE X-Series Productivity Shuttle Type I/II 1.7 Safety Information
1.7 Safety Information
DANGER
The SIPLACE Station and the XPS are electrically driven. Therefore, parts of this equipment
conduct dangerous voltages – even when the main switch is switched off! Comply with all
applicable VDE, VDI, and VGB provisions.
Always switch off the main switches of the equipment and disconnect the equipment from the
power supply system if you are performing work on live parts. Failure to comply with any of these
notices can result in death, serious bodily injury, and/or significant property damage!
Comply with all accident prevention regulations and operating instructions applicable to operation
of the equipment. This applies, in particular, to the traversing ranges of lifting and feeding axes.
