7
DEK Galaxy APi DL
Machine Productivity Options
Process
Specification
Print Method
Paste Dispenser
Paste roll height monitor
ProActiv
ProFlow® ATx
ProFlow® Tx
ProFlow®*
Printing Environment Control
Temperature – Temperature Control Module (TCM)
Stencil Frame
VectorGuard®
Universal screen frame adaptor
Under Stencil Cleaning
Cyclone Duo. Specify length (300mm, 400mm, 460mm, 515mm)
* For head size over 300mm contact the Product Manager
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Software & Communications
Off Line Editor (OLE)
GEM on TCP/IP
Transport
Specification
Substrate Support
Vacuum Tooling Capability
Vacuum Tooling Sensor
Vacuum Cups
HD Grid-Lok#
Substrate Fixture
Snuggers (edge clamping)
Foil-less clamps
# Manifold cannot be located under the pass through lane
Vision
Specification
HawkEye® 1700 Functionality
Enabled (camera included)
HawkEye®
HawkEye® Bridging
2Di Inspection
Basic stencil and board
Advanced stencil and board
8
DEK Galaxy APi DL
ASM Assembly Systems Switzerland GmbH Disclaimer
In line with ASM Assembly Systems Switzerland GmbH Policy of continual improvement, this specification is periodically up-issued to
reflect the latest DEK platform enhancements and it is provided with an issue state, which is displayed at the bottom of each hard copy
page.
Please note the following:
This information is provided in good faith; it is believed to be accurate and sufficient for the intended purpose
This information remains the property of ASM Assembly Systems Switzerland GmbH
ASM Assembly Systems Switzerland GmbH are not liable for the consequences of applying this information
ASM Assembly Systems Switzerland GmbH are free to alter this information without notice
The legal form of this notice can be read at http://www.dek.com/disclaimer
