3 Technical data for the machine User Manual SIPLACE D3
3.7 PCB conveyor system From software version SR.605.xx 07/2008 EN Edition
128
Function 3
PCBs on conveyor tracks 1 and 2 are moved synchronously onto the conveyor sections (i.e. the
conveyors are controlled synchronously, but independently of one another). The components to
be placed on conveyor tracks 1 and 2 must be organized into a panel via two subpanels. (See the
SIPLACE Pro user manual).
If only one conveyor track (or center conveyor) is full when the placement sequence starts, the
subpanel on this section will be identified as “not for placement”.
Restrictions 3
If the dual conveyor is operated in synchronous mode, the ‘PCB whispering down the line’ option
is deactivated. PCB barcode operation is not supported in this mode. The "Global bad fiducial"
option cannot be used.
3.7.4 Controlling and width adjustment
3.7.4.1 Controlling using the Single Functions menu
The online help contains information on controlling the PCB conveyor and on the Single Functions
menu.
3.7.4.2 Automatic width adjustment
When the command is received, the conveyors are set to the desired width one after another. Dif-
ferent widths are possible.
See the Online Help for detailed information about changing the conveyor track width.
3.7.5 Technical data
3.7.5.1 Technical data for a PCB single conveyor
3
Fixed conveyor side Right or left
PCB format
Standard (LxW)
Wide board configuration
Long board option
a
Long board option in
Wide board configuration
50 x 50 mm² to 450 x 460 mm²
b
50 x 50 mm² to 450 x 508 mm²
b
50 x 80 mm² to 610 x 460 mm²
b
50 x 80 mm² to 610 x 508 mm²
b
PCB thickness
Standard 0.3 mm to 4.5 mm ± 0.2 mm
(thicker PCBs available on request)
User Manual SIPLACE D3 3 Technical data for the machine
From software version SR.605.xx 07/2008 EN Edition 3.7 PCB conveyor system
129
3.7.5.2 Technical data of the flexible PCB dual conveyor
3
PCB warpage see Section 3.7.7, page 131
PCB weight max. 3 kg
Clearance on PCB underside
Standard
Option
25 mm ± 0.2 mm
max. 40 mm ± 0.2 mm
Component-free PCB handling edge 3 mm
PCB changeover time < 2.5 s
PCB positioning accuracy ± 0.5 mm
PCB conveyor height 830mm ± 15mm (standard)
900mm ± 15mm (optional)
930mm ± 15mm (optional)
950mm ± 15mm (SMEMA: optional)
Type of interface SMEMA / Siemens
Bad fiducial detection possible
Automatic width adjustment possible
a) See Long board option, Section 6.11, page 327
b) With PCB widths > 450 mm make sure that the peripheral modules are also able to process these widths.
Fixed conveyor side Right or left
PCB format
Standard (length x width)
Wide board configuration
Long board option
a
Long board option in
Wide board configuration
Dual conveyor in
Single conveyor mode
Standard (length x width)
Wide board configuration
Long board option
Long board option in
Wide board configuration
50 x 50 mm² to 450 x 216 mm²
50 x 50 mm² to 450 x 250 mm²
50 x 80 mm² to 610 x 216 mm²
50 x 80 mm² to 610 x 250 mm²
50 x 50 mm² to 450 x 380 mm²
50 x 50 mm² to 450 x 450 mm²
50 x 80 mm² to 610 x 380 mm²
50 x 80 mm² to 610 x 450 mm²
PCB thickness
Standard 0.3 mm to 4.5 mm ± 0.2 mm
(thicker PCBs available on request)
PCB warpage see Section 3.7.7
, page 131
PCB weight max. 3 kg
3 Technical data for the machine User Manual SIPLACE D3
3.7 PCB conveyor system From software version SR.605.xx 07/2008 EN Edition
130
3.7.6 Configuration options
3.7.6.1 PCB single conveyor
Item no. 00119625-xx D3 modular single conveyor
Item no. 00119626-xx Stationary conveyor side on the right, HF/X/D-series
Item no. 00119628-xx Stationary conveyor side on the left, HF/X/D-series
Item no. 00119629-xx Conveyor width 250/508 mm (Wide board), X-series/D3
Item no. 00119631-xx Conveyor width 242/508 mm (Wide board), D1/D2/D3/D4
3.7.6.2 Flexible PCB dual conveyor
Item no. 00119627-xx D3 modular dual conveyor
Item no. 00119626-xx Stationary conveyor side on the right, HF/X/D-series
Item no. 00119628-xx Stationary conveyor side on the left, HF/X/D-series
Item no. 00119629-xx Conveyor width 250/508 mm (Wide board), X-series/D3
Item no. 00119631-xx Conveyor width 242/508 mm (Wide board), D1/D2/D3/D4
Clearance on PCB underside
Standard
Option
25 mm ± 0.2 mm
max. 40 mm ± 0.2 mm
PCB conveyor height 830mm ± 15mm (standard)
900mm ± 15mm (optional)
930mm ± 15mm (optional)
950mm ± 15mm (SMEMA: optional)
Type of interface SMEMA / Siemens
Component-free PCB handling edge 3 mm
PCB changeover time < 2.5 s
PCB positioning accuracy ± 0.5 mm
Conveyor mode synchronous or asynchronous (selected via the soft-
ware)
Components on each conveyor same or different
PCB width on each conveyor same or different
Bad fiducial detection synchronous: possible, no global ink spot
asynchronous: possible
Automatic width adjustment synchronous: possible, asynchronous: possible
a) See Long board option, Section 6.11, page 327
