User Manual SIPLACE D3 6 Station extensions From software version SR.605.xx 07/2008 EN Edition 6.3 Waffle-pack changer 309 6.3.3 T echnical data 6.3.3.1 Dimensions, weight 6.3.3.2 Electrical ratings Dimensions (L x W) 15…
6 Station extensions User Manual SIPLACE D3
6.3 Waffle-pack changer From software version SR.605.xx 07/2008 EN Edition
308
6.3 Waffle-pack changer
Item no. 00119825-xx WPC4 on the SIPLACE D-series
6.3.1 Safety instructions
WARNING 6
→ Never reach into the gaps between the waffle-pack changer and the machine base while the
machine is running.
→ The waffle-pack changer control cable must only then be connected to the connecting socket
or taken from this if the waffle-pack changer is docked into the machine.
→ The power supply cable must not be plugged into or unplugged from the external power supply
unless the waffle-pack changer is docked into the machine.
→ The waffle-pack changer must NOT be operated unless it is docked into the machine.
6.3.2 Description
The waffle-pack changer makes components available in the waffle-pack trays to avoid unneces-
sary loss of time during storage and automatic changing of the waffle-pack trays. Programmable,
random access to up to 28 waffle-pack trays also increases the range of components that can be
made available.
The waffle-pack changer has an integral chassis, and is easy to move to other locations. It is
supplied with the PCB conveyor height implemented for the machines, but can also be adapted
for the 830, 900, 930 and 950 mm PCB conveyor heights with just a few simple operations.
There are 4.5 locations for 30 mm width S feeder modules available on the component table.
Both the TwinHead and the 6 and 12 segment Collect&Place head can pick up components from
the waffle-pack tray.
User Manual SIPLACE D3 6 Station extensions
From software version SR.605.xx 07/2008 EN Edition 6.3 Waffle-pack changer
309
6.3.3 Technical data
6.3.3.1 Dimensions, weight
6.3.3.2 Electrical ratings
Dimensions (L x W) 1560 x 360 mm²
Height
830 mm ± 15 mm PCB conveyor height
900 mm ± 15 mm PCB conveyor height
930 mm ± 15 mm PCB conveyor height
950 mm ± 15 mm PCB conveyor height
1360 mm ± 15 mm
1430 mm ± 15 mm
1460 mm ± 15 mm
1480 mm ± 15 mm
Weight approx. 240 kg
Load per unit area 4.19 kN/m²
Dimensions of the waffle-pack tray carrier (L x W x H) 360 x 260 x 6 mm³
Weight of the waffle-pack tray carrier 0.8 kg
Dimensions of the waffle-pack tray, including components 341 x 235 x 15 mm³
max. 341 x 235 x 23 mm³
Weight of the waffle-pack tray carrier, including waffle-pack tray
and components max. 1.2 kg
Storage capacity max. 28 WTC
Total weight of the 28 waffle-pack tray carriers 27.6 kg
Weight of magazine storage unit, waffle-pack tray carrier, waffle-
pack trays and components max. 50 kg
Changeover time for waffle-pack tray carriers
over 1 level
over 10 levels
over 27 levels
1.9 s
2.3 s
2.9 s
Supply voltage 3 x 200 VAC ± 5 %; 50/60 Hz (Japanese version)
3 x 208 VAC ± 5%; 50/60 Hz (U.S.A. version)
3 x 230 VAC ± 5%; 50/60 Hz
3 x 380 VAC ± 5%; 50/60 Hz
3 x 400 VAC ± 5%; 50/60 Hz (European version)
3 x 415 VAC ± 5%; 50/60 Hz
Nominal apparent power 800 VA
Rated current 0.7 A for 3 x 400 VAC
Fuse 3 x 10 or 3 x 16 A
6 Station extensions User Manual SIPLACE D3
6.3 Waffle-pack changer From software version SR.605.xx 07/2008 EN Edition
310
6.3.3.3 Noise emissions
6.3.3.4 Permitted environmental factors
6.3.4 Installation notes for the WPC
On D3 machines, the WPC can be docked at location 2 in place of a component trolley.
The docking unit for the SIPLACE component trolley was modified slightly to do this and the up-
grade kit for the waffle-pack changer docked in. Only then is the WPC docked in. If you use the
WPC at another location, the free location may be set up with a component trolley once more.
PLEASE NOTE 6
It is not possible for a nozzle changer to be installed at locations with a WPC.
Max. noise emissions 74 dB (A)
Room temperature Between 15°C and 35°C
Atmospheric humidity 30 - 90% at 20°C
