CO Component
DC Dual conveyor
DCA Direct chip attach
EMC Electromagnetic compatibility
ESD Electrostatically-sensitive group of components
ESD Electrostatic sensitive device
FC Flip chip
GND Ground
IC Integrated circuit
MC Machine controller
MTC Matrix tray changer
OSC Odd shaped components
P&P Pick&Place
PA Placement area
PCB Printed circuit board
SC Single conveyor
SC Station computer
SM Dual conveyor in Single conveyor mode
SMD Surface mounted device
TH TwinHead
VS Vision system
WLAN Wireless Local Area Network
WT Waffle-pack tray
WTC Waffle-pack tray carrier
1 Introduction User Manual SIPLACE D3
1.5 Important notes on the user manual From software version SR.605.xx 07/2008 EN Edition
32
User Manual SIPLACE D3 2 Operational safety
From software version SR.605.xx 07/2008 EN Edition 2.1 Safety instructions
33
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This user manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk:
DANGER or
as used in this user manual means that death, severe injury or considerable damage to equipment
will occur if the danger instructions are not followed.
WARNING or
as used in this user manual means that death, severe injury or considerable damage to equipment
may occur if the warning instructions are not followed.
CAUTION or
as used in this user manual means that slight injury or damage to equipment may occur if the cau-
tion instructions are not followed.
PLEASE NOTE
as used in this user manual provides information on the product or indicates a part of the user
manual that requires particular attention.
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and preventive maintenance of automatic placement machines and add-on devices and
are suitably qualified, e.g.
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify
electrical circuits and system components in accordance with normal safety standards.
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
– have received first aid training.
