User Manual SIPLACE D3 2 Operational safety
From software version SR.605.xx 07/2008 EN Edition 2.1 Safety instructions
33
2 Operational safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This user manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk:
DANGER or
as used in this user manual means that death, severe injury or considerable damage to equipment
will occur if the danger instructions are not followed.
WARNING or
as used in this user manual means that death, severe injury or considerable damage to equipment
may occur if the warning instructions are not followed.
CAUTION or
as used in this user manual means that slight injury or damage to equipment may occur if the cau-
tion instructions are not followed.
PLEASE NOTE
as used in this user manual provides information on the product or indicates a part of the user
manual that requires particular attention.
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and preventive maintenance of automatic placement machines and add-on devices and
are suitably qualified, e.g.
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify
electrical circuits and system components in accordance with normal safety standards.
– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-
cordance with normal safety standards.
– have received first aid training.
2 Operational safety User Manual SIPLACE D3
2.1 Safety instructions From software version SR.605.xx 07/2008 EN Edition
34
2.1.3 Important notes on operational safety
The following points MUST be observed in order to maintain operational safety:
2.1.3.1 General
→ The operational safety of SMD automatic placement machines can be guaranteed only if the
system is used as prescribed and in accordance with the instructions in the user/service man-
uals.
→ Always follow any safety regulations specific to your country.
→ Make sure that the warning labels are always clearly identifiable and always easily readable.
→ Replace any damaged warning or notice labels. Replace any labels that are missing.
→ The machine key for releasing the covers on the machine must be kept in a safe place where
it is only accessible to qualified personnel.
PLEASE NOTE
The machine owner, and only the machine owner, is responsible for the safekeeping of the
machine key and for ensuring that it is handed over to authorized persons. 2
→ If it is necessary to work on the machine and you do not have adequately trained personnel
within your operation, always call in a SIPLACE service engineer. SIPLACE will not accept
liability for any damage or consequential damage that is the result of incorrect work.
→ If particularly hazardous situations are identified while the machine is in use, the machine
owner must immediately notify the manufacturer in writing so that appropriate action can be
taken to reduce the potential danger.
WARNING
In spite of all the safety precautions taken by the manufacturer, failure to use the system as pre-
scribed can result in severe physical injury (e.g. from the moving gantry or lifting table) and/or con-
siderable damage to equipment. For the machine to be safe, it must be used correctly by qualified
personnel and all warnings must be observed. Some work on the machine (e.g. setting up) re-
quires training that goes beyond the scope of this manual. 2
