User Manual SIPLACE D3 2 Operational safety From software version SR.605.xx 07/2008 EN Edition 2.2 Warning labels 41 2.2.1.1 W arning label W201 2 Pos. W201 in Fig. 2.2 - 1 , page 39 , item no. 0 3009338-01 (number per m…
2 Operational safety User Manual SIPLACE D3
2.2 Warning labels From software version SR.605.xx 07/2008 EN Edition
40
Fig. 2.2 - 2 Warning labels W203, W204 and W210 on the machine - part 2
Pos. W203, item no. 03009342-01
Pos. W204, item no. 03009343-01
Pos. W210, item no. 03009350-01
(T) PCB direction of travel
WARNING 2
→ Do not use abrasive cleaners or solvents for cleaning warning labels.
→ Replace any damaged or illegible warning labels.
User Manual SIPLACE D3 2 Operational safety
From software version SR.605.xx 07/2008 EN Edition 2.2 Warning labels
41
2.2.1.1 Warning label W201
2
Pos. W201 in Fig. 2.2 - 1, page 39, item no. 03009338-01 (number per machine: 1)
2.2.1.2 Warning label W203
2
Pos. W203 in Figs. 2.2 - 1, page 39, and 2.2 - 2, page 40, item no. 03009342-01 (number per ma-
chine: 4)
2.2.1.3 Warning label W204
2
Pos. W204 in Fig. 2.2 - 1, page 39, and 2.2 - 2, page 40, item no. 03009343-01 (number per ma-
chine: 8)
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
SAFE OPERATION OF THE MACHINE
Safe operation of the machine depends absolutely on
the operator being familiar with the user manual and
safety instructions and putting them into effect.
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
