User Manual - Productivity Lift Soko 00166631-01 / 12031477 5 Configuration
Software version V 43.140 Edition April 2006 5.11 ALT protection
53
5.11 ALT protection
With this function (adjustment „switched on”) the input possibilities in the configuration menu („V”
and „ALT” - cursor) and in the adjustment mode („ALT” - cursor) are locked. Input is only possible
when the interlock is used.
Fig. 5 - 11 ALT protection
ALT
Enter
Start
Stop
ALT protection
Turned on
5 Configuration User Manual - Productivity Lift Soko 00166631-01 / 12031477
5.12 Width adjustment 1 Software version V 43.140 Edition April 2006
54
5.12 Width adjustment 1
This menu can be used to set the mode for operation of the automatic tracking facility (option) for
width adjustment for the lift belt.
The following are possible:
turned off : The device has no electrical width adjustment (standard).
manual : The device has an electrical width adjustment facility but no automatic track-
ing facility. The width must be adjusted in the manual-operating mode using
the corresponding function.
automatic : The device has an automatic tracking facility. This setting is then used to con-
stantly check the transport width of the device, which prescribes the width.
only at start : The device has an automatic tracking facility. This setting is then used to
check the transport width of the device, which prescribes the width, but only
at the start of the lift.
Fig. 5 - 12 Width adjustment 1
ALT
Enter
Start
Stop
Width adjust 1
manual
User Manual - Productivity Lift Soko 00166631-01 / 12031477 5 Configuration
Software version V 43.140 Edition April 2006 5.13 Width adjustment 2
55
5.13 Width adjustment 2
This menu has to be used to set the mode for operation of the automatic tracking facility for width
adjustment of the Underfloor Conveyor. This menu isn't active, if the unit is an output module.
The following are possible:
turned off : The device has no electrical width adjustment (standard).
manual : The device has an electrical width adjustment facility but no automatic track-
ing facility. The width must be adjusted in the manual-operating mode using
the corresponding function.
automatic : The device has an automatic tracking facility. This setting is then used to con-
stantly check the transport width of the device, which prescribes the width.
only at start : The device has an automatic tracking facility. This setting is then used to
check the transport width of the device, which prescribes the width, but only
at the start of the lift.
Fig. 5 - 13 Width adjustment 2
ALT
Enter
Start
Stop
Width adjust 2
manual
