4-13 4 <S10_4. Hi11 (IN)> 地址 位数 名称 0027h 6 Air Pressure: Head A8 Bit 14 0027h 7 Air Pressure: Head A8 Bit 15 0028h 0 Air Pressure: Head A9 / Air Pressure: Head A9 Bit 0 0028h 1 Air Pressure: Head A9 Bit 1 0028h 2 A…
4-12
4
<S10_4. Hi11 (IN)>
地址 位数 名称
000Ch 6 Air Pressure: Head A5 Bit 6
000Ch 7 Air Pressure: Head A5 Bit 7
000Dh 0 Air Pressure: Head A5 Bit 8
000Dh 1 Air Pressure: Head A5 Bit 9
000Dh 2 Air Pressure: Head A5 Bit 10
000Dh 3 Air Pressure: Head A5 Bit 11
000Dh 4 Air Pressure: Head A5 Bit 12
000Dh 5 Air Pressure: Head A5 Bit 13
000Dh 6 Air Pressure: Head A5 Bit 14
000Dh 7 Air Pressure: Head A5 Bit 15
000Eh 0 Air Pressure: Head A6 / Air Pressure: Head A6 Bit 0
000Eh 1 Air Pressure: Head A6 Bit 1
000Eh 2 Air Pressure: Head A6 Bit 2
000Eh 3 Air Pressure: Head A6 Bit 3
000Eh 4 Air Pressure: Head A6 Bit 4
000Eh 5 Air Pressure: Head A6 Bit 5
000Eh 6 Air Pressure: Head A6 Bit 6
000Eh 7 Air Pressure: Head A6 Bit 7
000Fh 0 Air Pressure: Head A6 Bit 8
000Fh 1 Air Pressure: Head A6 Bit 9
000Fh 2 Air Pressure: Head A6 Bit 10
000Fh 3 Air Pressure: Head A6 Bit 11
000Fh 4 Air Pressure: Head A6 Bit 12
000Fh 5 Air Pressure: Head A6 Bit 13
000Fh 6 Air Pressure: Head A6 Bit 14
000Fh 7 Air Pressure: Head A6 Bit 15
0010h 0 Measured Height / Laser Sensor1 Data Bit0
0010h 1 Laser Sensor1 Data Bit1
0010h 2 Laser Sensor1 Data Bit2
0010h 3 Laser Sensor1 Data Bit3
0010h 4 Laser Sensor1 Data Bit4
0010h 5 Laser Sensor1 Data Bit5
0010h 6 Laser Sensor1 Data Bit6
0010h 7 Laser Sensor1 Data Bit7
0011h 0 Laser Sensor1 Data Bit8
0011h 1 Laser Sensor1 Data Bit9
0011h 2 Laser Sensor1 Data Bit10
0011h 3 Laser Sensor1 Data Bit11
0011h 4 Laser Sensor1 Data Bit12
0011h 5 Laser Sensor1 Data Bit13
0011h 6 Laser Sensor1 Data Bit14
0011h 7 Laser Sensor1 Data Bit15
0012h 0 Laser Sensor2 / Laser Sensor2 Data Bit0
0012h 1 Laser Sensor2 Data Bit1
0012h 2 Laser Sensor2 Data Bit2
0012h 3 Laser Sensor2 Data Bit3
0012h 4 Laser Sensor2 Data Bit4
0012h 5 Laser Sensor2 Data Bit5
0012h 6 Laser Sensor2 Data Bit6
地址 位数 名称
0012h 7 Laser Sensor2 Data Bit7
0013h 0 Laser Sensor2 Data Bit8
0013h 1 Laser Sensor2 Data Bit9
0013h 2 Laser Sensor2 Data Bit10
0013h 3 Laser Sensor2 Data Bit11
0013h 4 Laser Sensor2 Data Bit12
0013h 5 Laser Sensor2 Data Bit13
0013h 6 Laser Sensor2 Data Bit14
0013h 7 Laser Sensor2 Data Bit15
0014h 0 Teach Camera Illumi
0014h 4 Fan(Head Unit) Lock
0022h 0 AZ-axis 7 OR+
0022h 1 AZ-axis 8 OR+
0022h 2 AZ-axis 9 OR+
0022h 3 AZ-axis 10 OR+
0022h 4 AZ-axis 11 OR+
0022h 5 AZ-axis 12 OR+
0022h 6 FAN1 LOCK
0022h 7 FAN2 LOCK
0024h 0 Air Pressure: Head A7 / Air Pressure: Head A7 Bit 0
0024h 1 Air Pressure: Head A7 Bit 1
0024h 2 Air Pressure: Head A7 Bit 2
0024h 3 Air Pressure: Head A7 Bit 3
0024h 4 Air Pressure: Head A7 Bit 4
0024h 5 Air Pressure: Head A7 Bit 5
0024h 6 Air Pressure: Head A7 Bit 6
0024h 7 Air Pressure: Head A7 Bit 7
0025h 0 Air Pressure: Head A7 Bit 8
0025h 1 Air Pressure: Head A7 Bit 9
0025h 2 Air Pressure: Head A7 Bit 10
0025h 3 Air Pressure: Head A7 Bit 11
0025h 4 Air Pressure: Head A7 Bit 12
0025h 5 Air Pressure: Head A7 Bit 13
0025h 6 Air Pressure: Head A7 Bit 14
0025h 7 Air Pressure: Head A7 Bit 15
0026h 0 Air Pressure: Head A8 / Air Pressure: Head A8 Bit 0
0026h 1 Air Pressure: Head A8 Bit 1
0026h 2 Air Pressure: Head A8 Bit 2
0026h 3 Air Pressure: Head A8 Bit 3
0026h 4 Air Pressure: Head A8 Bit 4
0026h 5 Air Pressure: Head A8 Bit 5
0026h 6 Air Pressure: Head A8 Bit 6
0026h 7 Air Pressure: Head A8 Bit 7
0027h 0 Air Pressure: Head A8 Bit 8
0027h 1 Air Pressure: Head A8 Bit 9
0027h 2 Air Pressure: Head A8 Bit 10
0027h 3 Air Pressure: Head A8 Bit 11
0027h 4 Air Pressure: Head A8 Bit 12
0027h 5 Air Pressure: Head A8 Bit 13
4-13
4
<S10_4. Hi11 (IN)>
地址 位数 名称
0027h 6 Air Pressure: Head A8 Bit 14
0027h 7 Air Pressure: Head A8 Bit 15
0028h 0 Air Pressure: Head A9 / Air Pressure: Head A9 Bit 0
0028h 1 Air Pressure: Head A9 Bit 1
0028h 2 Air Pressure: Head A9 Bit 2
0028h 3 Air Pressure: Head A9 Bit 3
0028h 4 Air Pressure: Head A9 Bit 4
0028h 5 Air Pressure: Head A9 Bit 5
0028h 6 Air Pressure: Head A9 Bit 6
0028h 7 Air Pressure: Head A9 Bit 7
0029h 0 Air Pressure: Head A9 Bit 8
0029h 1 Air Pressure: Head A9 Bit 9
0029h 2 Air Pressure: Head A9 Bit 10
0029h 3 Air Pressure: Head A9 Bit 11
0029h 4 Air Pressure: Head A9 Bit 12
0029h 5 Air Pressure: Head A9 Bit 13
0029h 6 Air Pressure: Head A9 Bit 14
0029h 7 Air Pressure: Head A9 Bit 15
002Ah 0
Air Pressure: Head A10 / Air Pressure: Head A10 Bit 0
002Ah 1 Air Pressure: Head A10 Bit 1
002Ah 2 Air Pressure: Head A10 Bit 2
002Ah 3 Air Pressure: Head A10 Bit 3
002Ah 4 Air Pressure: Head A10 Bit 4
002Ah 5 Air Pressure: Head A10 Bit 5
002Ah 6 Air Pressure: Head A10 Bit 6
002Ah 7 Air Pressure: Head A10 Bit 7
002Bh 0 Air Pressure: Head A10 Bit 8
002Bh 1 Air Pressure: Head A10 Bit 9
002Bh 2 Air Pressure: Head A10 Bit 10
002Bh 3 Air Pressure: Head A10 Bit 11
002Bh 4 Air Pressure: Head A10 Bit 12
002Bh 5 Air Pressure: Head A10 Bit 13
002Bh 6 Air Pressure: Head A10 Bit 14
002Bh 7 Air Pressure: Head A10 Bit 15
002Ch 0
Air Pressure: Head A11 / Air Pressure: Head A11 Bit 0
002Ch 1 Air Pressure: Head A11 Bit 1
002Ch 2 Air Pressure: Head A11 Bit 2
002Ch 3 Air Pressure: Head A11 Bit 3
002Ch 4 Air Pressure: Head A11 Bit 4
002Ch 5 Air Pressure: Head A11 Bit 5
002Ch 6 Air Pressure: Head A11 Bit 6
002Ch 7 Air Pressure: Head A11 Bit 7
002Dh 0 Air Pressure: Head A11 Bit 8
002Dh 1 Air Pressure: Head A11 Bit 9
002Dh 2 Air Pressure: Head A11 Bit 10
002Dh 3 Air Pressure: Head A11 Bit 11
002Dh 4 Air Pressure: Head A11 Bit 12
002Dh 5 Air Pressure: Head A11 Bit 13
002Dh 6 Air Pressure: Head A11 Bit 14
地址 位数 名称
002Dh 7 Air Pressure: Head A11 Bit 15
002Eh 0
Air Pressure: Head A12 / Air Pressure: Head A12 Bit 0
002Eh 1 Air Pressure: Head A12 Bit 1
002Eh 2 Air Pressure: Head A12 Bit 2
002Eh 3 Air Pressure: Head A12 Bit 3
002Eh 4 Air Pressure: Head A12 Bit 4
002Eh 5 Air Pressure: Head A12 Bit 5
002Eh 6 Air Pressure: Head A12 Bit 6
002Eh 7 Air Pressure: Head A12 Bit 7
002Fh 0 Air Pressure: Head A12 Bit 8
002Fh 1 Air Pressure: Head A12 Bit 9
002Fh 2 Air Pressure: Head A12 Bit 10
002Fh 3 Air Pressure: Head A12 Bit 11
002Fh 4 Air Pressure: Head A12 Bit 12
002Fh 5 Air Pressure: Head A12 Bit 13
002Fh 6 Air Pressure: Head A12 Bit 14
002Fh 7 Air Pressure: Head A12 Bit 15
4-14
4
■7.FrontLeft(OUT)
地址 位数 名称
0008h 0 SSIDOBit0
0008h 1 SSIDOBit1
0008h 2 SSIDOBit2
■8.FrontLeft(IN)
地址 位数 名称
0000h 0 Device No. Bit0
0000h 1 Device No. Bit1
0000h 2 Device No. Bit2
0000h 3 Device No. Bit3
0000h 4 Device Added Information Bit0
0000h 5 Device Added Information Bit1
0000h 6 Device Added Information Bit2
0000h 7 Output Register Value Bit0
0001h 0 Output Register Value Bit1
0001h 1 Output Register Value Bit2
0001h 2 Output Register Value Bit3
0001h 3 Output Register Value Bit4
0001h 4 Input Register Value Bit0
0001h 5 Input Register Value Bit1
0001h 6 Input Register Value Bit2
0001h 7 Input Register Value Bit3
0002h 0 BOARD (F / Right Front) ID0
0002h 1 BOARD (F / Right Front) ID1
0002h 2 BOARD (F / Right Front) ID2
0002h 3 BOARD (F / Right Front) ID3
0002h 4 BOARD (F / Right Front) ID4
0002h 5 BOARD (F / Right Front) ID5
0002h 6 BOARD (F / Right Front) ID6
0002h 7 BOARD (F / Right Front) ID7
0003h 0 BOARD (F / Right Front) ID8
0003h 1 BOARD (F / Right Front) ID9
0003h 2 BOARD (F / Right Front) ID10
0003h 3 BOARD (F / Right Front) ID11
0003h 4 BOARD (F / Right Front) ID12
0003h 5 BOARD (F / Right Front) ID13
0003h 6 BOARD (F / Right Front) ID14
0003h 7 BOARD (F / Right Front) ID15
000Ch 4 SSI DI Bit4
■9.RearLeft(OUT)
地址 位数 名称
0000h 0 CTF(Right Rear) Cover Lock
0000h 1 CTF(Right Rear) Shutter Open
0000h 2 CTF(Right Rear) Setup Switch
0000h 3 CTF(Right Rear) Safety Relay Reset
0000h 4 CTF(Right Rear) Servo ON Permission
0000h 5
CTF(Right Rear) Pallet Height Detection Sensor(L)
Permit
0000h 7
CTF(Right Rear) Pallet Height Detection Sensor(R)
Permit
0001h 0 CTF(Right Rear) Barcode Reader Trigger On
0001h 1 CTF(Right Rear) Barcode Reader Timeout Set Bit0
0001h 2 CTF(Right Rear) Barcode Reader Timeout Set Bit1
0001h 3 CTF(Right Rear) Barcode Reader Timeout Set Bit2
0001h 4
CTF(Right Rear) Barcode Reader Receive Counter
Clear
