4.6.4.1 Error Messages TQM Module (Excerpt)
The error messages are shown on the 7 segment display and in
Caccia
.
Error message TQM module
E = Error
Description
E A0 (general) No HW found with the correct ID ( Vision, C600, C500, adapter or
intermediate distributor)
E 0b (general) Actual - Application does not match target application (Vision,
C600, C500, adapter or intermediate distributor) --> download
the correct application
E 10 (Vision environment) No Vision Board ID
E 11 (Vision environment) EEPROM data not plausible
E 12 (Vision environment) EEPROM not available
E 20 (Twin head environment) No Twin head HW found
E 61 (Twin head environment) EEPROM data not plausible
E 62 (Twin head environment) EEPROM not available
E 68 (Twin head environment) On the head interface (C500) TQM module available --> remove
TQM from the C600 or set to RESET.
E 30 (C500 Head interface environment) No C500 board found (HW)
E 50 (C500 Head interface environment) more than one EEPROM‘s not available
E 51 (C500 Head interface environment) EEPROM Data not plausible ( board type recognition data
Adapter and Intermediate distributor not conform)
E 52 (C500 Head interface environment) board type recognition head interface (C500) not correct
E 53 (C500 Head interface environment) board type recognition head adapter not correct
E 54 (C500 Head interface environment) board type recognition intermediate distributor not correct
E 55 (C500 Head interface environment) EEPROM not available head interface (C500)
E 56 (C500 Head interface environment) EEPROM not available head adapter
E 57 (C500 Head interface environment) EEPROM not available or TQM on head interface (C500) not
available
E 58 (C500 Head interface environment) 8 bit processor on head adapter available or remove the 8 bit
processor
E 59 (C500 Head interface environment) board type recognition head interface and head adapter are not
conform --> programming the correct board type.
E 5A (C500 Head interface environment) unknown head adapter --> programming the correct board type.
E 5b (C500 Head interface environment) unknown head interface and head adapter --> programming the
correct board type.
E 5C (C500 Head interface environment) unknown head interface --> programming the correct board type.
E 5d (C500 Head interface environment) unknown intermediate distributor --> programming the correct
board type.
E 5E (C500 Head interface environment) unknown Head adapter and intermediate distributor -->
programming the correct board type.
E 5F (C500 Head interface environment) Unknown head adapter and intermediate distributor EEPROM.
