Operational Safety Warning Labels Warning Label W205 on the Tap e Cutter S tudent Guide (FSE) SI PL ACE X Series and X4I Operational Safety Edition 01/2009 EN 28 2.2.3.1 W arning Label W205 on the T op 2-4: Warning label…
Operational Safety
Warning Label W205 on the Tape Cutter Warning Labels
Student Guide (FSE) SIPLACE X Series and X4I
Edition 01/2009 EN Operational Safety
27
2.2.3 Warning Label W205 on the Tape Cutter
WARNING: DANGER OF CRUSHING
Danger of crushing for persons with passive metal implants (e.g. plates, screws). Do not reach
or lean over into the machine when the protective cover is open.
Do not bring any metal objects into the area.
RISK OF CUTTING!
Danger of cutting is present even when the machine is switched off
Item no. [03009344-01] (quantity per machine: 16)
WARNING:
If you wish to do work on the tape cutter, you must disconnect the machine from the mains
supply and the compressed air supply.
Wait until the operating pressure has dropped to 0 MPa.
Wear robust protective gloves when working on the tape cutter.
Operational Safety
Warning Labels Warning Label W205 on the Tape Cutter
Student Guide (FSE) SIPLACE X Series and X4I
Operational Safety Edition 01/2009 EN
28
2.2.3.1 Warning Label W205 on the Top
2-4: Warning label W205 on the top of the tape cutter
WARNING:
If you wish to do work on the tape cutter, you must disconnect the machine from the mains
supply and the compressed air supply.
Wait until the operating pressure has dropped to 0 MPa.
DANGER:
Wear robust protective gloves when working on the tape cutter.
Operational Safety
Warning Label W205 on the Tape Cutter Warning Labels
Student Guide (FSE) SIPLACE X Series and X4I
Edition 01/2009 EN Operational Safety
29
2.2.3.2 Warning Label W205 on the Underside of the Component Trolley Docking Unit (HF-Series)
2-5: Warning label W205 on the bottom of the tape cutter
