Description of the LED terminal strips X04 and X05 MTC2 Calibration and Settings
Student Guide (FSE) SIPLACE X Series and X4I
Edition 01/2009 EN MTC2
603
14.3.7 Description of the LED terminal strips X04 and X05
LED No. Designation Not actuated Actuated
X04-1 Neutral position light barrier, lifting axis, tower 1 Off On
X04-2 Limit switch, lifting axis, tower 1, max. position On Off
X04-3 Limit switch, lifting axis, tower 1, min. position On Off
X04-4 Proximity switch, toothed belt, tower 1 On Off
X04-5 Neutral position light barrier, feed axis, tower 1 Off On
X04-6 Limit switch, feed axis, tower 1, min. position On Off
X04-7 Limit switch, feed axis, tower 1, max. position On Off
X04-8 Crash light barrier for tower 1, low trays On Off
X04-9 Crash light barrier for tower 1, high trays On Off
X04-10 Crash light barrier for tower 1, very high trays On Off
X04-11 Safety query "WTC in cassette", tower 1 On Off
X04-12 Driver disengaged, tower 1 Off On
X04-13 Driver engaged, tower 1 Off On
X04-14 WTC interlock locked, tower 1 On Off
X04-15 WTC interlock open, tower 1 On Off
X04-16 WTC handle sensor, tower 1 Off On
X04-17 Guide rail closed, tower 1 Off On
X04-18 Disengage driver, tower 1 Off On
X04-19 Engage driver, tower 1 Off On
X04-20 Unlock WTC unlock device, tower 1 Off On
+24 V Control voltage Off On
-24 V Control voltage Off On
LED No. Designation Not actuated Actuated
X05-1 Neutral position light barrier, lifting axis, tower 2 Off On
X05-2 Limit switch, lifting axis, tower 2, max. position On Off
X05-3 Limit switch, lifting axis, tower 2, min. position On Off
X05-4 Proximity switch, toothed belt, tower 2 On Off
X05-5 Neutral position light barrier, feed axis, tower 2 Off On
X05-6 Limit switch, feed axis, tower 2, min. position On Off
X05-7 Limit switch, feed axis, tower 2, max. position On Off
X05-8 Crash light barrier for tower 2, low trays On Off
X05-9 Crash light barrier for tower 2, high trays On Off
X05-10 (not used)
X05-11 Safety query "WTC in cassette", tower 2 On Off
X05-12 Driver disengaged, tower 2 Off On
X05-13 Driver engaged, tower 2 Off On
X05-14 WTC interlock locked, tower 2 On Off
X05-15 WTC interlock open, tower 2 On Off
MTC2
MTC2 Calibration and Settings Spare parts list for MTC1
Student Guide (FSE) SIPLACE X Series and X4I
MTC2 Edition 01/2009 EN
604
14.3.8 Spare parts list for MTC1
X05-16 WTC handle sensor, tower 2 Off On
X05-17 Guide rail closed, tower 2 Off On
X05-18 Disengage driver, tower 2 Off On
X05-19 Engage driver, tower 2 Off On
X05-20 Unlock WTC unlock device, tower 2 Off On
+24 V Control voltage Off On
-24 V Control voltage Off On
LED No. Designation Not actuated Actuated
Artikelnummer/
Part number
Description Description
00373473-01 Abdeckkappe Vorzentrierung SLIDING DISC FOR
PRECENTERING
1ST1ST
00372620-01 AC-Motor Hubachse m.
Zahnriemenscheibe
AC motor lifting axis 1 ST 1 ST
00372639-01 Anschlusskabel Leistung MTC Connecting cable: power MTC 1 ST 1 ST
00354917-02 Ausrückung Mitnehmer kpl. Disengaging driver, complete 1 ST 1 ST
00372636-01 Crash-Lichtschranke konf.MTC2 Crash light barrier, configured MTC2 1 ST 1 ST
00372640-01 Durchlichtschranke FMT in Kassette
MTC2
WTC in cassette light barrier 1 ST 1 ST
00372616-01 Einführschienen Kassettentisch Guide rails cassette table 1 ST 1 ST
00372622-01 Endschalter max. Position konf. Max. position limit switch, configured 1 ST 1 ST
00372625-01 Endschalter min. Position konf. Min. position limit switch, configured 1 ST 1 ST
00372606-01 Entriegelung FMT MTC2 Unlock device WTC 1 ST 1 ST
00372614-01 FMT XL mit Haltemagnete WTC XL with RETAINING MAGNET 3 ST 1 PA
K
00372615-01 Halteleiste für JEDEC-Magazin Holder JEDEC tray 1 ST 1 ST
00372629-01 Kabel Ausrückung Mitnehmer
Turm 1
Cable: disengaging driver tower 1 1 ST 1 ST
00372633-01 Kabel Ausrückung Mitnehmer
Turm 2
Cable: disengaging driver tower 2 1 ST 1 ST
00372610-01 Kabel Crashsens. Zuführa. 1 Cable: Crash light barrier tower 1 1 ST 1 ST
00372653-01 Kabel Crashsens. Zuführa. 2 Cable: Crash light barrier tower 2 1 ST 1 ST
00372641-01 Kabel Entrieg. FMT Turm 1 Cable: unlock device WTC tower 1 1 ST 1 ST
00372643-01 Kabel Entriegelung FMT Turm2 Cable: unlock device WTC tower 2 1 ST 1 ST
00372644-01 Kabel Hubachse Cable: lifting axis 1 ST 1 ST
00372632-01 Kabel Zuführachse Cable: feed axis 1 ST 1 ST
00372607-01 Kassette XL CASSETTE XL 1 ST 1 ST
00372612-01 Kurbel kpl. MTC2 Crank, complete MTC2 1 ST 1 ST
00372635-01 Lichtschranke Ruheposition
Hubachse
Neutral position light barrier lifting axis 1 ST 1 ST
MTC2
Spare parts list for MTC1 MTC2 Calibration and Settings
Student Guide (FSE) SIPLACE X Series and X4I
Edition 01/2009 EN MTC2
605
00372637-01 Lichtschranke Ruheposition
Zuführachse
Neutral position light barrier feed axis 1 ST 1 ST
00372611-01 Linearführung Zuführachse MTC2 Linear guide feed axis MTC2 1 ST 1 ST
00372648-01 Maschinenfuss mit Mutter Machine foot 1 ST 1 ST
00372624-01 Microschalter Turm 1 Micro switch tower 1, configured 1 ST 1 ST
00372628-01 Microschalter Turm 2 konf. Micro switch tower 2, configured 1 ST 1 ST
00372617-01 Mitnehmer Hebel Lever driver 1 ST 1 ST
00372608-01 Mitnehmer kpl. MTC2 DRIVER COMPLETE MTC2 1 ST 1 ST
00373139-01 MTC2 Controllerboard kp C167-CONTROLLERBOARD
COMPLETE
1ST1ST
00372621-01 Netzteil 24 V DC MTC2 Power supply 24 V DC MTC2 1 ST 1 ST
00372638-01 Not-Aus-Taster Emergency stop button 1 ST 1 ST
00372649-01 NOT-HALT-Schaltgerät Emergency stop switchgear 1 ST 1 ST
00372651-01 Sensor Griffabfrage WTC handle sensor 1 ST 1 ST
00372645-01 Sensor Riemenabfrage Hubachse Toothed belt sensor lifting axis 1 ST 1 ST
00372647-01 Stecker mit Kabel (MTC2) Plug with cables MTC2 1 ST 1 ST
00372646-01 Stecker mit Kabel (Zenrierrahmen) Plug with cables docking station 1 ST 1 ST
00372609-01 Umlenkrolle vorne kpl. MTC2 Front deflection roll, complete MTC2 1 ST 1 ST
00372652-01 Universal-Anpass.-Spartransf. Transformer power supply 1 ST 1 ST
00372613-01 Verriegelung FMT XL MTC2 Interlock WTC MTC2 1 ST 1 ST
00372627-01 Zahnriemen AC-Motor Toothed belt AC motor 1 ST 1 ST
Artikelnummer/
Part number
Description Description
