7 Conveyor 7.7 Boards Service Manual SIPLACE TX Series 06/2017 183 Fig.244: 03087640-02
7 Conveyor
7.7 Boards
182 Service Manual SIPLACE TX Series 06/2017
Installation
► Follow the removal instructions in reverse order for installation. Also observe the following in-
structions:
CAUTION
Installation instructions
► Check the embedded software and perform a download if needed (see 7.7.2 "eSW
Download (SW 70x)" [}186]).
► Check the jumper setting: jumper 1 and 2 must be set correctly for both TSP420 (see
table).
Jumper Setting for machine
Up to serial no. TA500 Serial no. TA500 or later
Lane 1 Lane 2 Lane 1 Lane 2
1 For MCAN 2-3 1-2 2-3 2-3
2 For internal CAN 1-2 1-2 1-2 1-2
See also: 7.7.1.1 "Conveyor Control TSP420 [03087642-xx]" [}182]
See also
2 eSW Download (SW 70x) [}186]
7.7.1.1 Conveyor Control TSP420 [03087642-xx]
Two TSP420 are fitted in SIPLACE TX-Series machines.
The conveyor control "TSP420 assembly" [03087642-xx] comprises the following components:
●
Main board: TSP420-M [ 03087640-xx ]
●
I/O board: TSP420-IO [ 03087641-xx ]
CAUTION
These two boards may not be separated!
NOTICE
Terminating resistor (cable set PCB dual conveyor [03110653‑xx])
The terminating resistor is set for the "Shuttle Option" by default.
7 Conveyor
7.7 Boards
Service Manual SIPLACE TX Series 06/2017 183
Fig.244: 03087640-02
7 Conveyor
7.7 Boards
184 Service Manual SIPLACE TX Series 06/2017
Fig.245: 03087641-02
