11 Cutter
10.7 Replacing Component Deposit [03117664-xx]
Service Manual SIPLACE TX Series 06/2017 249
11 Cutter
DANGER
Observe User Manual
► Please observe the safety instructions in the user manual for all work!
WARNING
Risk of injury when working near the tape cutter.
When working in the area of the tape cutter, move the component trolley out of the machine
and disconnect the machine from the mains supply and the compressed air supply.
► Wait until the operating pressure has dropped to 0 MPa.
► Always secure the machine against unauthorized reactivation.
► Do not reach into the tape cutter.
CAUTION
Risk of injury when performing service work on the tape cutter.
Never support the tape cutter on your body, e.g., on your knees or thighs. Do not place
your feet under the tape cutter.
► Wear appropriately thick protective gloves.
► When removing/fitting the tape cutter, hold it only outside on the left and right.
11 Cutter
11.1 Cutter overview
250 Service Manual SIPLACE TX Series 06/2017
11.1 Cutter overview
Fig.342: Cutter parts
1. Waste tape chute
11.2 "Replacing the Waste Tape Chute
[03125182-xx]" [}251]
2. Cutter
11.3 "Replacing the Cutter on the COT Insert
[03066690-xx]" [}252]
3. Baffle plate
11.5 "Replacing the Baffle Plate [03019896-
xx]" [}257]
4. Short-stroke cylinder with articulated joint
11.8 "Replacing the Short-Stroke Cylinder
[03038587-xx]" [}262]
11.7 "Replacing the Articulated Joint on the
Short-Stroke Cylinder [03000518-xx]" [}259]
5. Throttle valve
11.13 "Replacing the Throttle Valve [03000600-
xx]" [}274]
6. Cutter blades
11.9 "Replacing the Cutter Blades" [}264]
7. Solenoid valves and silencer
11.14 "Replacing the Solenoid Valves [03000630-
xx]" [}276]
11.15 "Replacing the Silencer [00310744-
xx]" [}277]
8. Wiper
11.10 "Replacing Wiper [03000491-xx]" [}270]
9. Wiper clips
11.11 "Replacing Wiper Clip" [}271]
10. Metal buffer and spacer distance piece
11.4 "Replacing the Metal Buffer/Spacer Distance
Piece" [}255]
11.12 "Replacing the Cutter Cable
[03063590‑xx]" [}273]
11 Cutter
11.2 Replacing the Waste Tape Chute [03125182-xx]
Service Manual SIPLACE TX Series 06/2017 251
11.2 Replacing the Waste Tape Chute [03125182-xx]
Parts, equipment and tools
●
Waste chute welding assembly [03125182‑xx]
Removal
CAUTION
Risk of cutting
The cutter is located under the tape channel. The blades there have very sharp edges.
► Do not reach into the tape cutter.
► Make sure that the cutter is not freely accessible to unauthorized persons.
Fig.343: Waste tape chute
► Loosen the two safety screws(1) on the waste
tape chute and unhook the waste tape chute.
Installation
► Follow the removal instructions in reverse order for installation.
