2 Basic Machine 2.5 Replacing the Machine Feet [03120976-xx] 32 Service Manual SIPLACE TX Series 06/2017
2 Basic Machine
2.5 Replacing the Machine Feet [03120976-xx]
Service Manual SIPLACE TX Series 06/2017 31
2.5 Replacing the Machine Feet [03120976-xx]
Parts, equipment and tools
●
Machine foot D 90mm [03120976-xx]
●
Operating manual for your machine
Removal / Installation
► Please read the relevant chapter of the user manual:
– "Setting the conveyor height and aligning the machine"
2 Basic Machine
2.5 Replacing the Machine Feet [03120976-xx]
32 Service Manual SIPLACE TX Series 06/2017
3 SMPS
2.5 Replacing the Machine Feet [03120976-xx]
Service Manual SIPLACE TX Series 06/2017 33
3 SMPS
DANGER
Observe User Manual
► Please observe the safety instructions in the user manual for all work!
DANGER
Checking for absence of voltage!
► Before you start working, check the power supply for absence of voltage and observe
the waiting times!
NOTICE
Observe the detailed circuit diagrams!
For more detailed information refer to the circuit diagrams folder of your machine.
●
Detailed circuit diagrams folder for SIPLACE TX-Series (up to no. 499) [DE+EN: 00197933-xx]
●
Detailed circuit diagrams folder for SIPLACE TX-Series (from no. 500) [DE+EN: 00198274-xx]
