Articles of Consumption
NO. PART NO. PART NAME Old No. Supply Reference
J9055134C NOZZLE CN040 ASSY[J9055134C] Only Indication
J9055136C NOZZLE CN065 ASSY[J9055136C] Only Indication
J9055256A NOZZLE CN140 ASSY[J9055256A] Only Indication
J9055351A NOZZLE CN220 ASSY(CERAMIC) [J9055351A] J9055257A Only Indication
J90550258B NOZZLE CN400 ASSY J90550258B
J9055259B NOZZLE CN750 ASSY[J9055259B]
J9055260B NOZZLE CN110 ASSY[J9055260B]
AM03-011252A ASSY,CALIBRATION TOOL-PLATE J9068024A Only Indication
AM03-011252A ASSY,CALIBRATION TOOL-PLATE J9068024A Only Indication
EP10-900438 FUSE[250V 5A] Only Indication
EP10-900439 FUSE[250V 10A] Only Indication
J72550021C SILICON TUBE(BLACK) J72550021C J7255076A /J7255021B 6 months
HP04-900036 SUCTION_FILTER VYF44-M-50M Only Indication
J7500003B BACK UP PIN[J7500003B] Only Indication
CM01-900472 STICKER REMOVER SPRAY [450ML] Only Indication
CM01-900473 TRI-FLOW [59ML] Only Indication
AM03-900053 CLEANING KIT Only Indication
J9064035B TOOL SET [J9064035B] Only Indication
TO03-900168 DRIVER (+,-) [KL 207(6), 150mm] Only Indication
CD03-900060 CD-R (RECORDABLE) [MMI BACKUP CD] Only Indication
J9055249A LIGHT MAPPING TOOL ASSY[J9055249A] - FLY Only Indication
J9055250A LIGHT MAPPING TOOL ASSY[J9055250A] - FIX Only Indication
AM03-006935A SOLENOID VALVE VA01PEP34A-1U-F HP14-900037 2 years
AM03-006936A SOLENOID VALVE[RCS242-M3-D24NP] 2 years
MC05-900068 BELT_410_1 Inspect and replace (6 months)
MC05-900069 BELT_410_F MAM-5P-1517-7W Inspect and replace (6 months)
MC05-900070 BELT_410_R Inspect and replace (6 months)
AM03-019772A ASSY,ETC,IMS-V_BACK_UP_PIN
J9053333A BACK UP PIN [LONG OPTION]
Page
HANWHA TECHWIN
203
SM482(L)
Articles of Consumption
NO. PART NO. PART NAME Old No. Supply Reference
CM02-000059 GREASE (SPINDLE, MIRROR CAM, CONV LM GUDIE) GADUS_S2 V220 2
CM02-000083 GREASE (X,Y FRAME LM GUIDE, X,Y BALL SCREW) AFE-CA+70_THK;SYNTHETIC,OLIVE,UREA
CM02-000084 GREASE (X,Y FRAME LM GUIDE, X,Y BALL SCREW) AFE-CA+400_THK;OIL
CM02-000092 GREASE (CONV LEAD SCREW) FLOIL G-146K
HP09-000258 SUPPLY,OIL-GREASE-GUN_MG70_THK 70g GREASE ONLY
