KV5_YTF80W-PL - 第4页
1 2 Cover Assy . Cover 1 KV5-090901 12 8 19 14 4 7 17 3 22 20 11 15 13 19 9 21 23 5 10 6 1 1 2 2 3 18 37 32 35 30 35 35 35 31 35 35 35 36 35 35 35 35 26 27 28 29 25 33 33 35 35 35 35 34 No. Part No. Part Name Q'ty R…
KV5-9906
7
14
15
10
6
18
18
29
28
20
20
25
2
3
1
13
31
9
5
5
12
26
11
4
16
16
22
19 21 24 23
FROM THE
MAIN MACHINE
TO THE VALVE
FOR TRAVERSER ASSY
TO THE VALVE
FOR X AXIS ASSY
TO THE VALVE
FOR HOOK ASSY
TO THE VALVE
FOR RACK AXIS ASSY
ø8 ORANGE
ø8
ø6
ø6
ø4
ø8
7
29
27
27
10
6
25
29
29
29
31
29
30
Base Assy.
11
Base
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 K33-M2698-00X BOLT LEVELING 4
2 K33-M2699-00X CASTER (FUJ75) 4
3 K33-90M28-00X NUT HEX. 4
4 KH2-M1125-01X PLATE DOOR 1
5 KH2-M1129-01X STAY DUCT 2
6 KV5-M1130-00X CATCH MG. 2
7 KH2-M1131-01X LOCK SOLENOID 2
9 KH2-M1112-00X PLATE E/L 1
10 KV5-M1118-00X STAY LOCK 2
11 KH6-M1124-00X PLATE HINGE 1
12 KV5-M1101-00X BASE 1
13 KV5-M1113-00X PLATE E/L BASE 1
14 KV5-M1114-00X BRACKET PANEL RACK 1
15 KV5-M1116-00X STAY 1 HARNESS 1
16 KV5-M1119-00X STAY CONVEYOR PANEL 2
18 KV5-M1123-00X BRACKET HINGE 2
19 $UY8 JOINT 1
20 KV5-M1139-01X DUCT PLATE 2
21 $TE6-R URETHANE TUBE 1
22 $USD6-4 JOINT 1
23 $UY6 JOINT 3
24 $UYD8-6 JOINT 1
25 K16-90103-00X BOLT 4
26 97004-08012 BOLT HEXAGON 1 6
27 91317-03016 BOLT HEX. SOCKET HEAD 4
28 91317-04010 BOLT HEX. SOCKET HEAD 4
29 91317-05010 BOLT HEX. SOCKET HEAD 72
30 97007-04010 BOLT HEXAGON 4
31 97601-04310 SCREW BINDING HEAD 64
1
2
Cover Assy.
Cover 1
KV5-090901
12
8
19
14
4
7
17
3
22
20
11
15
13
19
9
21
23
5
10
6
1
1
2
2
3
18
37
32
35
30
35
35
35
31
35
35
35
36
35
35
35
35
26
27
28
29
25
33
33
35
35
35
35
34
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 K46-M1374-10X HINGE 2 2
1-1 K46-M1374-11X HINGE 2 2 (2009/7/13) MF70096 OK
1-2 K46-M1374-12X HINGE 2 2 (2013/2/13) MK20039 OK
2 KH2-M1319-00X NUT OPEN COVER 2
3 KH2-M1320-00X STAY OPEN COVER 2
4 KH2-M1324-00X GRIP 1
5 KH2-M1115-80X PANEL, RACK 1
6 KH6-M1121-80X PANEL CONVEYOR 1
7 KV5-M1304-00X COVER FRONT 1
8 KV5-M1305-00X COVER L 1 1
9 KV5-M1306-00X COVER R 1 1
10 KV5-M1307-00X COVER L 2 1
11 KV5-M1308-00X COVER TOP 1
12 KV5-M1309-00X COVER REAR 1 1
13 KV5-M1311-00X COVER R 2 1
14 KV5-M1317-00X COVER OPEN 1
15 KV5-M1318-00X PLATE OPEN COVER 1
17 KVS-M1120-00X BRACKET PANEL CONVEYOR 1
18 KV5-M1350-00X COVER CABLE 1
19 KV5-M1351-00X COVER TRAVERSE 2
20 KV5-M1352-00X BRACKET MONITOR 1
21 KV5-M1353-00X PANEL MONITOR 1
22 KV5-M1354-00X COVER MONITOR 1
23 91C00-03210 SPACER 8
25 KM0-M1319-00X COVER 19 1
26 KM0-M1320-01X COVER 20 1
27 KG2-M1335-00X BRKT 1 GATE COVER 1
28 KG2-M1336-00X BRKT 2 GATE COVER 1
29 KG2-M1346-00X PLATE 1
30 91317-03006 BOLT HEX. SOCKET HEAD 4
31 91317-03010 BOLT HEX. SOCKET HEAD 4
32 97007-04010 BOLT HEXAGON 4
33 98907-05010 SCREW B/H 1 0
34 91317-05010 BOLT HEX. SOCKET HEAD 2
35 90159-04J01
SCREW BINDING HEAD (+) W/WASHER
90
36 K16-90101-00X BOLT 1 3
37 98707-03006 SCREW, FLAT HEAD 8
KV5-9906
1
2
1
2
4
3
5
1
16
17
17
2
1
2
13
13
3
18
16
5
14
14
18
18
7
8
18
18
15
18
17
15
6
11
18
18
9
10
12
Cover Assy.
22
Cover 2
No. Part No. Part Name Q'ty Remarks Date Revised No.
1 KG2-M1372-00X PIECE B HINGE 1
2 K46-M1373-00X SHAFT HINGE 1
3 KH2-M1341-00X PLATE LOCK DOOR 2
4 KH6-M1348-00X COVER HINGE 1
5 KV5-M1301-00X DOOR RACK 2
6 KV5-M1310-00X COVER REAR 2 1
7 KV5-M1312-00X COVER L 3 1
8 KV5-M1313-00X COVER R 3 1
9 KV5-M1314-00X COVER EL 1 1
10 KV5-M1321-00X COVER Z AXIS 1
11 KV5-M1322-00X COVER L 4 1
12 KV5-M1323-00X COVER R 4 1
13 KV5-M1347-00X PLATE PALLET GUIDE 2
14 KV5-M1356-00X SPACER DOOR 3
15 91317-03006 BOLT HEX. SOCKET HEAD 4
16 91317-05010 BOLT HEX. SOCKET HEAD 4
17 91317-04008 BOLT HEX. SOCKET HEAD 15
18 90159-04J01 SCREW BINDING HEAD (+) W/WASHER 70
