4.アウトコンベア Out conveyor(WQC)
CP-642ME PARTS LIST ver05
4-3
4.アウトコンベア(WQC)
4.Out conveyor(WQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. QTY Description Rating Remarks
53MQC3630 1 BKT, SENSOR BKT ｾﾝｻ
54MQC1510 1 BKT, SENSOR BKT ｾﾝｻ
56S3122Z 1 SW, PHOTOELECTRIC SW 光電 E3S-LS3RC4
57S3122A 2 SW, PHOTOELECTRIC SW 光電 E3S-LS3C1D
58WQC5591 2 BELT ﾍﾞﾙﾄ
59H4451A 4 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1680ZZ
60H4440A 5 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ L-1910ZZ
61H4445A 8 BEARING, MINIATURE ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ LF-1050ZZ
62H2059A 1 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 4ﾟX20L
63H2056A 1 PIN, SPRING ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 4ﾟX14L
64W10022 2 WASHER ﾜｯｼｬ TL182-No2
65S1022A 5 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-4
66N1014A 1 NUT, FINE U ﾅｯﾄ ﾌｧｲﾝU AN00
67H4001T 2 HEAD, GEAR ﾍｯﾄﾞ ｷﾞﾔ 6GHA7.5A-Y-1
68M5063H 2 MOTOR, REVERSIBLE ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ RM-H6A06ZMR244
69JQC3672 4 NUT, HEX ﾅｯﾄ 六角
70H4123A 1 BEARING ﾍﾞｱﾘﾝｸﾞ UFL000
71S3033A 3 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 1 Type
72S3034A 5 SPROCKET ｽﾌﾟﾛｹｯﾄ RS25-13T 2 Type
73T2023A 1 CHAIN ﾁｪｰﾝ RS25NP88 Link
74T2040K 1 CHAIN ﾁｪｰﾝ RS25NP416 Link
75T2034K 1 CHAIN ﾁｪｰﾝ RS25NP284 Link
76H4429H 2 BEARING, BALL ﾍﾞｱﾘﾝｸﾞ ﾎﾞｰﾙ LMK16UU
77MQC4092 1 BKT, SENSOR BKT ｾﾝｻ
78GVC2182 1 BKT, SENSOR BKT ｾﾝｻ
79N4026A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X4L
80N4027A SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M4X5L
81W1025A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M
82W1024A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M
83W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
84W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
85W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6
86W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
87W1013A WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H
88W1012A WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L
89W1011A WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L
90N1092A NUT, HEX ﾅｯﾄ 六角 M10 P=1.5
91N1085A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0
92N1080A NUT, HEX ﾅｯﾄ 六角 M4 P=0.7
93W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4
94H5342A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L
95H5330A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X40L
96H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L
97H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L
Drg.No. & Code No.
4.アウトコンベア Out conveyor(WQC)
CP-642ME PARTS LIST ver05
4-4
4.アウトコンベア(WQC)
4.Out conveyor(WQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. QTY Description Rating Remarks
98H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
99H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L
100H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L
101H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
102H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
103H5296Z BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X100L
104H5292A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X20L
105H5288A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L
106H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L
107K5261A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L
108K5208A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L
109. SCREW, COUNTERSUNK 小ﾈｼﾞ 皿 M4X6L
110K5177A SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M2.5X14L
111WQC0120 2 HOLDER 受け
112MQC1160 4 PULLEY ﾌﾟｰﾘ
113MQC1170 4 BOLT ﾎﾞﾙﾄ
114MQC1181 4 COLLAR ｶﾗｰ
115H4129A 8 BEARING ﾍﾞｱﾘﾝｸﾞ LF950ZZ
116GVC2420 1 BKT, COVER BKT ｶﾊﾞｰ
118WQC4090 1 BKT BKT
122MQC1430 3 BKT BKT
125MQC1420 1 PLATE ﾌﾟﾚｰﾄ
127MQC2111 1 BKT BKT
128MQC2200 1 DOG ﾄﾞｯｸﾞ
129MQC3303 1 BKT BKT
130MQC3471 1 PLATE ﾌﾟﾚｰﾄ
132GVC1141 1 DOG ﾄﾞｯｸﾞ
133GVC1151 1 DOG ﾄﾞｯｸﾞ
134GVC1160 1 NUT ﾅｯﾄ
135WQC4810 1 BKT BKT
136WQC4800 1 HOUSING ﾊｳｼﾞﾝｸﾞ
137WQC4820 1 SHAFT ｼｬﾌﾄ
138GQC7020 2 BKT, SW BKT SW
140CLC9550 1 BKT BKT
141CLC9560 1 COVER ｶﾊﾞｰ
143M5058H 1 MOTOR, REVERSIBLE ﾓｰﾀ ﾘﾊﾞｰｼﾌﾞﾙ PB425-401-E3
144H4012A 1 HEAD, GEAR ﾍｯﾄﾞ ｷﾞﾔ 4GN15K
145K1011A 1 COUPLING, HELICAL ｶｯﾌﾟﾘﾝｸﾞ ﾍﾙｶﾙ ACRM-100-10-8
146K1012T 1 COUPLING, HELICAL ｶｯﾌﾟﾘﾝｸﾞ ﾍﾙｶﾙ ARM-075-6-6
147A4095A 1 ENCODER ｴﾝｺｰﾀﾞ LBJ-007-2000
148S1025A 2 CIR-CLIP ｻｰｸﾘｯﾌﾟ ST-EW-7
149S4040Z 2 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SPX406-W2A
150. BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X5L
151H5297A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X8L
Drg.No. & Code No.
4.アウトコンベア Out conveyor(WQC)
CP-642ME PARTS LIST ver05
4-5
4.アウトコンベア(WQC)
4.Out conveyor(WQC)
152H5319H BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X8L
153H5332A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X50L
154K5178T SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X12L
155W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
156WQL0082 1 BKT BKT
157WGA0350 1 BKT BKT
158GVC3201 1 PLATE ﾌﾟﾚｰﾄ
159GVC2311 2 SHAFT ｼｬﾌﾄ
160H5321A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L
161IQC6291 1 NUT ﾅｯﾄ
162WQC4330 1 BRIDGE ﾌﾞﾘｯｼﾞ
163WQC4120 1 BKT BKT
164WQC4180 1 BKT BKT
165WQC4430 1 BKT BKT
166S3130T 1 SW, PHOTOELECTRIC SW 光電 PS-49
167. SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X15L
168H5279A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X20L
169A1040H 1 AMPLIFIER ｱﾝﾌﾟ PS2-61
170WQC4830 1 COVER, CHAIN ｶﾊﾞｰ ﾁｪｰﾝ
171H5324A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L
172M5017H 2 MOTOR, INDUCTION ﾓｰﾀ ｲﾝﾀﾞﾝｼｮﾝ 2IK6RGN-A-K1 注1.Note.1
注1. 正逆流れ
Note.1 : For board flow changeover manual.
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
