1 . ノズル一覧 N o z z l e s ( W P H ) CP-642ME P AR TS LIST ver05 1 - 2 1 . ノズル一覧( W P H ) 1 . N o z z l e s ( W P H ) 番号 図番 & ｺ ｰ ﾄ ﾞ 番号 個数 品名 規格 備考 N o . D r g . N o . & C o d e N o . Q T Y D e s c r i p t i o n R …

100%1 / 162
1.ノズル一覧 Nozzles(WPH)
CP-642ME PARTS LIST ver05
1-1
1.ノズル一覧(WPH)
1.Nozzles(WPH)
x1.5
R012-007
M012-013
φ1.3
φ0.41
φ7.0
φ3.75
44
45
43
11
12
10
R012-010
φ1.0
5
6
4
R012-013
φ1.3
8
9
7
φ0.71
2
3
1
47
48
46
R012-004
φ2.5
R016-025
17
18
16
φ3.75
R016-037
20
21
19
φ2.5
R020-025
23
24
22
φ2.5
M020-025
26
27
25
R020-037
B022-070
29
30
28
φ5.0
32
33
31
S020-050
φ7.0
41
42
40
S022-070
φ5.0
38
39
37
B022-050
φ5.0
35
36
34
S022-050
φ1.81
14
15
13
R012-018
φ20
φ12φ12
□22
φ12
φ12
φ12
φ16
φ16
φ20
φ20
□20
□22
□22
□22
φ12
1.ノズル一覧 Nozzles(WPH)
CP-642ME PARTS LIST ver05
1-2
1.ノズル一覧(WPH)
1.Nozzles(WPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1AWPH9514 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-007
2AWPH9011 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-007
3WPH8291 20 SEAL ｼｰﾙ R012-007
4AWPH9524 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-010
5AWPH9021 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-010
6WPH8301 20 SEAL ｼｰﾙ R012-010
7AWPH9534 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-013
8AWPH9031 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-013
9WPH8311 20 SEAL ｼｰﾙ R012-013
10AWPH9545 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY M012-013
11AWPH9088 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し M012-013
12WPH8311 20 SEAL ｼｰﾙ M012-013
13AWPH9554 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-018
14AWPH9077 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-018
15WPH8320 20 SEAL ｼｰﾙ R012-018
16AWPH9563 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R016-025
17AWPH9125 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R016-025
18WPH8201 20 SEAL ｼｰﾙ R016-025
19AWPH9572 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R016-037
20AWPH9135 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R016-037
21WPH8211 20 SEAL ｼｰﾙ R016-037
22AWPH9583 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R020-025
23AWPH9041 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R020-025
24WPH8081 20 SEAL ｼｰﾙ R020-025
25AWPH9593 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY M020-025
26AWPH9098 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し M020-025
27WPH8081 20 SEAL ｼｰﾙ M020-025
28AWPH9602 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R020-037
29AWPH9051 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R020-037
30WPH8121 20 SEAL ｼｰﾙ R020-037
31AWPH9612 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S020-050
32AWPH9060 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し S020-050
33WPH8101 20 SEAL ｼｰﾙ S020-050
34AWPH9662 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S022-050
35AWPH9154 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し S022-050
36WPH8231 20 SEAL ｼｰﾙ S022-050
37AWPH9672 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B022-050
38AWPH9154 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し B022-050
39WPH8221 20 SEAL ｼｰﾙ B022-050
40AWPH9682 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY S022-070
41AWPH9164 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し S022-070
42WPH8181 20 SEAL ｼｰﾙ S022-070
43AWPH9694 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY B022-070
44AWPH9176 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し B022-070
1.ノズル一覧 Nozzles(WPH)
CP-642ME PARTS LIST ver05
1-3
1.ノズル一覧(WPH)
1.Nozzles(WPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
45WPH8171 20 SEAL ｼｰﾙ B022-070
46AWPH9701 20 NOZZLE ASSY ﾉｽﾞﾙ ASSY R012-004
47AWPH9181 20 NOZZLE ASSY ,NO SEAL ﾉｽﾞﾙ ASSY ｼｰﾙ無し R012-004
48WPH8330 20 SEAL ｼｰﾙ R012-004
